ABB MPRC 086349-002 is the non-Ethernet MPRC board used in Smart Platform 1200 scanning-platform electronics. The manual documents processor-bus activity, terminal and host receive indications, startup controls and diagnostic behavior.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for MPRC 086349-002
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MPRC 086349-002

  • Manufacturer:
    ABB
  • Part Number:
    MPRC 086349-002
  • Product Family:
    ABB Accuray
  • Product Type:
    Smart Platform 1200 Non-Ethernet Measurement Processor Board
  • Stock:
    1
  • System Context:
    Smart Platform 1200 scanning-platform electronics
  • Board Role:
    Non-Ethernet MPRC measurement processor board
  • Processor Context:
    68332 external bus activity indicated by RUN LED
  • Front Indicators:
    ERROR, RUN, RX TERMINAL, RX HOST
  • Front Controls:
    START MODE switch and RESET
  • Normal:
    RUN Behavior RUN flashes with data-strobe / external-bus activity
  • ERROR Diagnostic:
    Steady after reset indicates replacement; flashing requires service-console diagnostics
  • Terminal Receive Check:
    RX TERMINAL should illuminate or flash with physical terminal activity
  • Host Receive Check:
    RX HOST should illuminate or flash with physical host activity
  • Dimensions:
    2.4 × 12.6 × 39.4 cm
  • Weight:
    0.36 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Processor Diagnostics Communication Paths Startup Control Application
  • Non-Ethernet measurement processor board for Smart Platform 1200 scanning-platform electronics
  • Front indications support processor-bus, terminal-receive, host-receive, run, and error diagnostics
  • Startup mode, host configuration, software parameters, and cable positions must be preserved during replacement

ABB MPRC 086349-002 is the non-Ethernet MPRC measurement processor board used in Smart Platform 1200 scanning-platform electronics.

The board supports platform processing and communications while providing diagnostic indications for terminal and host receive activity, processor-bus operation, running state, and detected errors.

Before replacement, record the start-mode setting, service-console configuration, installed software parameters, cable positions, indicator behavior, rack position, and complete 086349-002 assembly identity.

Availability, condition, price, and shipping time for ABB MPRC 086349-002 are confirmed during quotation.

ABB MPRC 086349-002 Smart Platform 1200 Non-Ethernet Measurement Processor Board Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • RUN flashes with 68332 external-bus activity
  • A steady ERROR indication after reset directs replacement of ABB MPRC 086349-002
  • A flashing ERROR indication requires service-console fault review
  • RX TERMINAL indicates physical terminal receive activity
  • RX HOST indicates physical host receive activity
  • Complete cable and connector checks before replacing ABB MPRC 086349-002
  • Record the START MODE setting before removing ABB MPRC 086349-002
  • Preserve all configuration and software parameters
  • Follow the documented console or host download sequence
  • Measurement processing in Smart Platform 1200 scanning systems
  • Host and service-terminal communication for scanning-platform electronics
  • Processor-bus supervision within documented ABB Accuray QCS cabinets
Description
ABB MPRC 086349-002 is a non-Ethernet measurement processor board used in Smart Platform 1200 scanning-platform electronics.

The front interface includes ERROR, RUN, RX TERMINAL and RX HOST indicators together with START MODE and RESET controls. The provided physical data lists dimensions of 2.4 × 12.6 × 39.4 cm and a product weight of 0.36 kg.

Before replacement, preserve the startup mode, software and configuration records, communication cabling and existing LED states. Match the complete 086349-002 assembly number and verify processor-bus, terminal and host communication before returning the scanning platform to service.
Alternative Names
MPRC 086349-002 ABB MPRC 086349-002 086349-002 MPRC-002 ABB MPRC-002 PWA MPRC-002 Smart Platform 1200 MPRC
Technical notes
MPRC 086349-002 is the non-Ethernet board; preserve startup mode, software/configuration, cabling and ERROR/RUN/RX diagnostic states before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can MPRC 086349-002 replace the Ethernet MPRC variant?
No. The Smart Platform manual identifies 086349-002 as the non-Ethernet MPRC; match the cabinet network architecture and complete assembly number.
What should be backed up before replacing MPRC 086349-002?
Record startup mode, host configuration, service-console settings, installed software parameters, cable positions and all ERROR/RUN/RX indicator behavior.
What does a steady ERROR indication after reset mean on MPRC 086349-002?
The manual's diagnostic procedure directs replacement when ERROR remains on after reset; a flashing ERROR instead calls for service-console fault review.
How can communication wiring be separated from a board fault on MPRC 086349-002?
Use RX TERMINAL and RX HOST activity to confirm physical receive paths, then check cables and service-console messages before replacing the board.
What should normal RUN behavior look like on MPRC 086349-002?
RUN is driven by the 68332 data strobe and should flash with external-bus activity; interpret it together with ERROR and receive indicators.
Can MPRC 086349-002 be restarted without following the startup procedure?
No. Preserve START MODE and use the documented console/host download sequence so that configuration and software are restored correctly.
What should be verified before returning MPRC 086349-002 to service?
Confirm that MPRC 086349-002 completes its startup sequence, clears the ERROR indication, shows expected RUN and receive activity, accepts service-console access and communicates correctly with the configured host before releasing the system for operation.
