    Apter Power provides quotations, official manuals, procurement support, and system-matching guidance for PU410 3BSE056478R1.

PU410 3BSE056478R1

/ 4.9
1001 reviews | Need a Specific Revision?
External RTA unit for point-to-point Ethernet integration between an 800xA Connectivity Server and MasterBus 300.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for PU410 3BSE056478R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PU410 3BSE056478R1

  • Manufacturer:
    ABB
  • Part Number:
    PU410 3BSE056478R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Real-Time Accelerator Unit
  • Stock:
    1
  • Network Protocol:
    MasterBus 300 (MB300)
  • Connectivity Server Interface:
    Ethernet, 100 Mbit/s, full duplex
  • MasterBus 300 Interface:
    RJ45 Ethernet, 10 Mbit/s, half duplex
  • Power Supply:
    24 VDC ±10%
  • Mounting:
    Standalone desktop or 19-inch cabinet
  • Connection Topology:
    Point-to-point; switches/hubs not supported
  • Weight:
    0.4 kg
  • Estimated shipping dimensions:
    17.8 cm x 4.6 cm x 24.9 cm
  • Tariff Code:
    8517623990
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Interfaces System Integration Installation

Features:

  • Connects a System 800xA Connectivity Server with an Advant Master AC 400 system through MasterBus 300.
  • Uses point-to-point Ethernet links: 100 Mbit/s full duplex on the Connectivity Server side and 10 Mbit/s half duplex on the MB300 side.
  • Supports standalone placement beside the server computer or installation in a 19-inch cabinet.
The PU410 3BSE056478R1 is an external Real-Time Accelerator Unit used as the communication interface between an 800xA Connectivity Server and MasterBus 300. It connects to the server through Ethernet and to MB300 through RJ45 Ethernet connections.

The documented links are point-to-point connections; Ethernet switches or hubs are not supported in the connection path. System architecture and replacement suitability should be checked before installation.

Current OEM lifecycle classification is not stated in the available ABB documentation. Availability is confirmed during quotation.
ABB PU410 3BSE056478R1 Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB PU410 3BSE056478R1 Real-Time Accelerator Unit Specs

General

  • Manufacturer ABB
  • Model PU410 3BSE056478R1
  • Condition New Original ready stock
  • Product Family PU410, 3BSE056478R1, System 800xA, MasterBus 300
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Connectivity Server Link: Ethernet interface at 100 Mbit/s, full duplex.
  • MasterBus 300 Link: RJ45 Ethernet interface at 10 Mbit/s, half duplex.
  • Connection Topology: The communication paths use point-to-point connections; switches and hubs are not supported.
  • System Role: The external RTA unit connects an 800xA Connectivity Server with an Advant Master AC 400 system through MasterBus 300.
  • Separate Interfaces: One Ethernet interface connects to the Connectivity Server, while the other interface connects to MasterBus 300.
  • Replacement Check: Confirm the target 800xA, AC 400, and MasterBus 300 architecture before selecting or replacing the unit.
  • Mounting: The unit can be placed as a standalone device beside the server computer or installed in a 19-inch cabinet.
  • Power Supply: The specified supply is 24 VDC ±10%.
  • Connection Check: Confirm the required point-to-point cabling and the interfaces on both connection sides before installation.
Description
ABB PU410 3BSE056478R1 is an external Real-Time Accelerator (RTA) Unit used to integrate an 800xA Operator Workplace with an Advant Master AC 400 system through MasterBus 300.

The unit connects to the Connectivity Server through Ethernet and to MasterBus 300 through RJ45 connections. These interfaces are intended for point-to-point links, and Ethernet switches or hubs are not supported in the connection path.

The unit can be placed as a standalone device beside the server computer or installed in a 19-inch cabinet. Selection and configuration should be checked against the target 800xA and AC 400 architecture before replacement.
Alternative Names
ABB PU410 3BSE056478R1 ABB PU410-3BSE056478R1 PU410 3BSE056478R1 PU410-3BSE056478R1 3BSE056478R1 PU4103BSE056478R1
Technical notes
ABB PU410 3BSE056478R1 is an external RTA Unit for point-to-point Ethernet integration between an 800xA Connectivity Server and MasterBus 300. Confirm system architecture and availability during quotation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is ABB PU410 3BSE056478R1 used for?
It is an external RTA Unit used to integrate an 800xA Operator Workplace with an Advant Master AC 400 system through MasterBus 300.
Which systems are associated with ABB PU410 3BSE056478R1?
The available ABB documentation describes its use between an 800xA Connectivity Server and an AC 400 system through MasterBus 300.
How does ABB PU410 connect to the server and MasterBus 300?
It connects to the Connectivity Server through Ethernet and to MasterBus 300 through RJ45 Ethernet connections.
Can an Ethernet switch or hub be used with ABB PU410 3BSE056478R1?
No. The documented connections are point-to-point, and Ethernet switches or hubs are not supported in the connection path.
How can ABB PU410 be mounted?
The unit can be placed as a standalone device beside the server computer or installed in a 19-inch cabinet.
Is technical documentation available for ABB PU410 3BSE056478R1?
Relevant technical documentation can be supplied with a quotation request. Confirm the target system architecture when requesting documents.
How can I request price and availability for ABB PU410 3BSE056478R1?
Send the full model and required quantity to Apter Power. Availability, documentation, and delivery details are confirmed during quotation.
