RINT-5611C

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB RINT-5611C is a high-precision, environmentally resistant MC interface board suitable for ACS800 R6 frequency converters, and integrates a matching cooling fan to ensure stable operation.
Get a quick price for RINT-5611C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for RINT-5611C

  • Manufacturer:
    ABB
  • Part Number:
    RINT-5611C
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Supply Voltage:
    24 VDC
  • Analog Inputs:
    ±0.1% FS
  • Operating Temperature:
    -25°C to +70°C
  • Storage Temperature:
    -40°C to +85°C
  • Humidity:
    5–95% (non-condensing)
  • Vibration:
    5–500 Hz
  • Compatible Drives:
    ACS800 series
  • Weight:
    0.7 kg
  • Estimated shipping dimensions:
    28.5x27.3x6.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
As a dedicated control interface component, the ABB RINT-5611C MC interface board is specifically designed for the ACS800-01/04/R6 380-500V driver, serving as a crucial bridge between the driver's core control unit and external signal devices. Its high-precision analog input accuracy of ±0.1%FS ensures reliable capture of subtle signal changes from field sensors, laying the foundation for precise motor speed and torque regulation in industrial applications. This interface board uses a 24VDC power supply, conforming to general industrial control power standards, eliminating the need for additional voltage conversion modules and simplifying system wiring.

The core design focus of the RINT-5611C is environmental durability. Its operating temperature range is -25°C to +70°C, enabling it to withstand extreme cold and heat in workshop environments. For storage and transportation, its operating temperature range is -40°C to +85°C, ensuring component stability during long-term storage or cross-regional logistics. The board can withstand 5-95% non-condensing humidity and vibration from 5-500Hz. It is suitable for harsh industrial environments such as mechanical shock and humid air, including control systems in mining equipment and drive units in heavy machinery. Its IP21 protection rating further protects the circuit board from dust and dripping water when mounted within the drive frame.

A notable feature of the RINT-5611C kit is its built-in cooling fan, a standard component of ACS800 R6 IP21 drives manufactured since February 2004. This fan plays a crucial role in heat dissipation during continuous operation of the interface board, preventing overheating and extending the lifespan of both the interface board and the drive. Maintenance requirements for the RINT-5611C are very stringent: the cooling fan must be replaced every time a circuit board is replaced to ensure stable heat dissipation. As an original ABB component, the RINT-5611C is seamlessly compatible with the ACS800 series inverters, avoiding communication errors and compatibility issues common with third-party replacement boards.
Alternative Names
R1NT-5611C RINT-56IIC RINT5611C R1NT5611C RINT56IIC RINT 5611C RINT-511C RINT-561IC
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is the RINT-5611C compatible with ACS800 drives?
Yes, it is designed for ACS800-01/04 R6 380–500 V drives.
How quickly can I receive the RINT-5611C?
It is typically shipped within 2–3 working days.
What is the supply voltage for RINT-5611C?
The module operates at 24 V DC.
Does the RINT-5611C come with a warranty?
Yes, it includes a 1-year warranty for peace of mind.
What is the operating temperature range?
It operates reliably from -25 °C to +70 °C.
What is the analog input accuracy?
±0.1% full scale (FS).
