SPCIS22

/ 4.9
1001 reviews | Need a Specific Revision?
ABB SPCIS22 is a Symphony Plus mixed control I/O module combining analog inputs, analog outputs, digital inputs and open-collector outputs. It supports compact coordinated process-control functions in one rack position.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for SPCIS22
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SPCIS22

  • Manufacturer:
    ABB
  • Part Number:
    SPCIS22
  • Product Family:
    ABB Bailey
  • Product Type:
    control I/O module
  • Stock:
    1
  • I/O role:
    Harmony Rack control I/O module
  • Digital inputs:
    3
  • Digital outputs:
    4 open-collector outputs
  • Analog inputs:
    4 current inputs
  • Analog input range:
    4–20 mA
  • Analog outputs:
    2 current outputs
  • Analog output range:
    4–20 mA
  • Logic supply:
    +5 VDC
  • Analog positive supply:
    +15 VDC
  • Analog negative supply:
    -15 VDC
  • Field supply:
    +24 VDC
  • Operating temperature:
    0 to 70°C
  • Related module:
    SPQRS22
  • Relative response:
    SPQRS22 is approximately ten times faster
  • Noise rejection:
    SPCIS22 provides the documented standard rejection characteristic
  • Output construction:
    Open collector
  • Rack platform:
    Harmony Rack
  • Channel mix:
    Discrete and analog I/O in one module
  • Weight:
    0.4409 lbs (0.2 kg)
  • Estimated shipping dimensions:
    3.5 x 31 x 17.6 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Monitoring Diagnostics Performance

Features:

  • Handles four 4-20 mA inputs, two 4-20 mA outputs, three digital inputs and four digital outputs.
  • Allows each mixed I/O channel to be programmed individually
  • the module interfaces through the Harmony Rack I/O expander-bus architecture.
SPCIS22 is the ABB Harmony Rack control I/O module for four 4-20 mA inputs, two 4-20 mA outputs, three digital inputs and four digital outputs.

It interfaces field signals with the Symphony Plus controller architecture and allows each mixed I/O channel to be programmed individually.

For SPCIS22, confirm the four 4-20 mA inputs, two 4-20 mA outputs, three digital inputs and four digital outputs range, termination unit, I/O expander-bus position, function code and field wiring before installation.

Availability is subject to Apter Power inventory and sourcing confirmation.

Verified resources for ABB SPCIS22:

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

ABB SPCIS22 Control I/O Module Specs

General

  • ManufacturerABB
  • ModelSPCIS22
  • ConditionNew / Surplus / Refurbished
  • Product FamilySymphony Plus / Harmony
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Four analog inputs and three digital inputs collect process feedback and discrete states for the controller application.
  • Two analog outputs and four open-collector digital outputs deliver coordinated commands to compatible field circuits.
  • Channel scaling, status logic and alarm handling are assigned individually in the engineered mixed-I/O database.
  • Module and channel indications help separate rack communication faults from wiring, loop-power and field-device problems.
  • Analog loop checks should confirm polarity, live-zero response and output load before automatic control is restored.
  • Open-collector output tests require verification of field supply, common wiring and the connected load path.
  • The standard control-I/O response and noise-rejection characteristics suit coordinated process loops with mixed signal types.
  • ABB identifies SPQRS22 as the faster related option, so response requirements must be compared before substitution.
  • Loop load, channel update behavior and controller execution rate together determine the resulting control performance.
Description
SPCIS22 is the ABB Harmony Rack control I/O module for four 4-20 mA inputs, two 4-20 mA outputs, three digital inputs and four digital outputs.

It interfaces field signals with the Symphony Plus controller architecture and allows each mixed I/O channel to be programmed individually.

For SPCIS22, confirm the four 4-20 mA inputs, two 4-20 mA outputs, three digital inputs and four digital outputs range, termination unit, I/O expander-bus position, function code and field wiring before installation.
Alternative Names
SPCIS22 ABB SPCIS22 SPCIS22 control I/O module Symphony Plus Harmony Rack SPCIS22 ABB Symphony Plus Harmony Rack SPCIS22 ABB Symphony Plus Harmony Rack control I/O module
Technical notes
Before energizing SPCIS22, verify field wiring, power isolation and the validated Symphony Plus Harmony Rack configuration.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What mixed I/O allocation is provided by SPCIS22?
The module combines three digital inputs, four open-collector digital outputs, four 4–20 mA inputs and two 4–20 mA outputs.
How is SPCIS22 compatibility distinguished from a faster control-I/O option?
The faster option has different response and noise-rejection behavior, so control-loop requirements must be compared before substitution.
Which coordinated-control applications suit SPCIS22?
It supports compact functions that need discrete status, discrete commands and analog feedback and output signals together.
What is checked when sourcing an SPCIS22 for a mixed-I/O slot?
Apter Power confirms exact identity, condition, quantity and delivery timing against the installed rack and termination.
Why must SPCIS22 replacement work include loop verification?
Each analog loop and open-collector output must retain its range, polarity, load and terminal assignment after exchange.
What records are needed for SPCIS22 documentation and quotation matching?
Send the I/O list, termination details, power-rail information, nameplate, quantity and destination.
