ABB RB4C-355-170 3AXD50000006934 is the 230 V cooling fan specified for selected 400 mm and 800 mm IP54 ACS880 cabinet configurations.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for RB4C-355-170 3AXD50000006934
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for RB4C-355-170 3AXD50000006934

  • Manufacturer:
    ABB
  • Part Number:
    RB4C-355-170 3AXD50000006934
  • Product Family:
    ABB Drives
  • Product Type:
    230 V IP54 Cabinet Cooling Fan
  • Stock:
    1
  • Official fan designation:
    RB4C-355/170
  • Auxiliary supply:
    230 V, 50/60 Hz
  • Current at 50 Hz:
    1.1 A
  • Input at 50 Hz:
    240 W
  • Current at 60 Hz:
    1.45 A
  • Input at 60 Hz:
    350 W
  • 400 mm IP54 cabinet:
    1 fan
  • 800 mm IP54 cabinet:
    2 fans
  • Required capacitor:
    6 µF, 600 V; order code 3AXD50000006959
  • Plug connector:
    3AXD50000000723
  • Socket connector:
    3AXD50000000724
  • Tariff Code:
    8414593000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Cabinet Match Electrical Fit Replacement Checks Application
  • 230 V, 50/60 Hz RB4C-355/170 cabinet cooling fan
  • One fan for the documented 400 mm IP54 cabinet and two for the 800 mm cabinet
  • Uses the specified 6 µF, 600 V capacitor and ABB connector pair

ABB RB4C-355-170 3AXD50000006934 is the documented fan assembly for selected ACS880-904 IP54 cabinet air-outlet arrangements.

Replacement work must retain the correct capacitor, plug, socket, auxiliary supply and number of fans for the applicable cabinet width.

Before returning the drive cabinet to service, verify airflow direction, impeller clearance, connector condition and cabinet temperature under load.

Availability, condition, price, and shipping time for RB4C-355-170 3AXD50000006934 are confirmed during quotation.

ABB RB4C-355-170 3AXD50000006934 Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use one fan in the documented 400 mm IP54 arrangement
  • Use two fans in the documented 800 mm IP54 arrangement
  • Do not substitute the different 600 mm IP54 fan code
  • Provide the documented 230 V 50/60 Hz auxiliary source
  • Match the 6 µF 600 V capacitor and approved connectors
  • Check actual line frequency against the published current and power values
  • Confirm airflow direction and impeller clearance before energizing
  • Inspect capacitor, plug, socket and cable condition with the fan
  • Verify cabinet airflow and temperature after the replacement run
  • ACS880-904 400 mm IP54 cabinet air-outlet cooling
  • ACS880-904 800 mm IP54 cabinet air-outlet cooling
  • ACS880-04 R10/R11 IP54 cabinet cooling arrangements documented for this fan
Description
ABB RB4C-355-170 3AXD50000006934 is the 230 V cooling fan specified for selected 400 mm and 800 mm IP54 ACS880 cabinet configurations.

Selection and replacement must follow the exact RB4C-355-170 3AXD50000006934 official data, wiring and accessory requirements.

Before commissioning, verify identity, installation, configuration, protection behavior and the connected field circuit.
Alternative Names
RB4C-355/170 RB4C-355-170 RB4C 355/170 RB4C 355 170 3AXD50000006934 RB4C-355/170 3AXD50000006934 RB4C-355-170 3AXD50000006934 ABB RB4C-355/170 ABB RB4C-355-170 ABB 3AXD50000006934 ABB RB4C-355/170 3AXD50000006934 ABB Drives RB4C-355/170
Technical notes
The exact ABB order code, fan type and electrical/cabinet data are verified. Exact product net weight and complete body W×H×D were not found in the official record and remain blank.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is ABB RB4C-355-170 3AXD50000006934 the fan for every ACS880 cabinet width?
No. ABB documents it for selected 400 mm and 800 mm IP54 arrangements; the 600 mm IP54 arrangement uses another fan code.
How many ABB RB4C-355-170 3AXD50000006934 fans are required?
The official table specifies one for a 400 mm IP54 cabinet and two for an 800 mm IP54 cabinet.
Is the run capacitor included with ABB RB4C-355-170 3AXD50000006934?
Do not assume so. ABB lists the 6 µF, 600 V capacitor separately as 3AXD50000006959.
Which connectors match ABB RB4C-355-170 3AXD50000006934?
ABB lists plug 3AXD50000000723 and socket 3AXD50000000724; confirm they are present and undamaged in the quoted assembly.
Can a 115 V cabinet fan replace ABB RB4C-355-170 3AXD50000006934?
No. This exact fan is documented for a 230 V, 50/60 Hz auxiliary supply; voltage, capacitor and cabinet configuration must all match.
Why can a new ABB RB4C-355-170 3AXD50000006934 run but provide weak cabinet airflow?
Check rotation and airflow direction, line frequency and voltage, capacitor value, blocked ducts, impeller clearance and whether the cabinet requires two fans.
What should be verified after installing ABB RB4C-355-170 3AXD50000006934?
Measure supply and running current, confirm smooth rotation and airflow direction, inspect vibration and noise, then verify cabinet temperature under representative drive load.
