    Apter Power supplies fully verified ABB SAFT 175 RDO (58101290) relay output boards, giving plant engineers a trusted source for essential industrial control spares.

SAFT175RDO

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB SAFT175RDO is a legacy relay output card for compatible ABB/Strömberg SAMI STAR adjustable frequency AC drive systems, providing four potential-free relay contact output channels, driven by four digital output signals from the compatible SAMI STAR control system.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for SAFT175RDO
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SAFT175RDO

  • Manufacturer:
    ABB
  • Part Number:
    SAFT175RDO
  • Product Family:
    ABB Drives
  • Product Type:
    Relay Output Card
  • Stock:
    1
  • Product Type:
    Relay Output Card
  • Relay Outputs:
    4 programmable independent relay contact outputs
  • Contact Configuration:
    NO / NC selectable
  • Relay Contact Rating:
    250 V AC, 5 A continuous
  • Inrush Rating:
    10 A
  • Available Drive Power:
    200 VA
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    15x10x2.7cm
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Monitoring & Control Performance & Efficiency

Features:

  • Four Programmable Relay Contact Outputs
  • Four Additional 24 V DC Digital Outputs
  • Configurable Relay Transient Suppression
The ABB SAFT175RDO provides four programmable independent relay contact outputs for compatible SAMI STAR drives. The contacts can be selected as normally open or normally closed and are rated up to 250 V AC, 5 A continuous and 10 A inrush, making the card suitable for potential-free external control and status interfaces.

In addition to its relay contacts, the ABB SAFT175RDO provides four 24 V DC digital outputs. This combination gives compatible SAMI STAR systems both relay-based potential-free signaling and conventional digital output capability within the same dedicated output card.

The ABB SAFT175RDO includes S5–S8 switch settings for relay-output transient suppression. This feature allows the output configuration to be matched more appropriately to connected loads, while the final switch settings and wiring should follow the applicable SAMI STAR installation documentation.

The SAFT175RDO ABB Relay Output Card may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB SAFT175RDO Relay Output Card Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB SAFT175RDO Relay Output Card

General

  • Manufacturer ABB
  • Model SAFT175RDO
  • Condition New Original ready stock
  • Product Family SAFT183 VMC,SAFT171PAC,SAFT172POW
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Legacy SAMI STAR Drive Maintenance: The ABB SAFT175RDO is primarily valuable for maintaining existing ABB/Strömberg SAMI STAR drive installations. It provides a practical replacement option when an original relay-output function needs to be restored without immediately redesigning the complete drive control architecture.
  • Potential-Free External Control Signals: The ABB SAFT175RDO is suited to applications requiring relay-based potential-free contacts from the SAMI STAR digital output system. These outputs can interface with external control circuits, status circuits and compatible field devices within their specified electrical limits.
  • Drive Status and Interlock Interfaces: The ABB SAFT175RDO can be used where relay outputs are required to interface drive-related commands, permissives, interlocks or status indications with external control equipment. The actual signal assignment depends on the SAMI STAR application software and system wiring.
  • Legacy Plant Reliability and Spare-Part Support: The ABB SAFT175RDO supports long-life industrial installations in which replacing one output card is preferable to redesigning an entire control system. Maintaining an appropriate spare inventory can help reduce troubleshooting and recovery time for aging SAMI STAR equipment.
  • Relay-Based Status and Command Signaling: The ABB SAFT175RDO converts compatible SAMI STAR digital-output functions into relay contact states that can be used by external control circuits. NO/NC selection provides flexibility when designing or maintaining existing signal logic.
  • Four-channel relay-output interface: The ABB SAFT175RDO combines four relay contact outputs with four additional 24 V DC digital outputs. This allows different types of external signal interfaces to be handled through the same dedicated SAMI STAR output-card architecture.
  • Centralized Drive-Level Diagnostics: The ABB SAFT175RDO itself is an output interface rather than a standalone diagnostic controller. Engineers should therefore evaluate output behavior together with SAMI STAR control-panel indications, drive fault information, parameter settings and electrical measurements during troubleshooting.
  • Transient-Suppression Configuration: The ABB SAFT175RDO provides S5–S8 switch settings associated with relay transient suppression. Correct configuration can be important when the relay outputs operate external loads with significant switching transients, and settings should follow the applicable ABB wiring and application documentation.
  • Defined Relay Switching Capacity: The ABB SAFT175RDO provides a clearly defined relay interface with contacts rated for 250 V AC, 5 A continuous and 10 A inrush. This gives maintenance engineers a concrete electrical limit for evaluating compatible external circuits rather than relying on generic relay-output assumptions.
  • Output Architecture: four potential-free relay-contact output channels controlled by the SAMI STAR digital-output system. his four-channel relay-output architecture provides potential-free interfaces for external control and status circuits.
  • Practical Legacy Replacement: The ABB SAFT175RDO can reduce the scope of maintenance work when the existing SAMI STAR drive remains serviceable and only the relay-output function requires replacement. Using a matching card can avoid unnecessary rewiring or changes to the established drive control architecture.
  • Application-Dependent Reliability: The ABB SAFT175RDO is designed for industrial drive interface duties, but actual service life depends on contact loading, switching frequency, environmental conditions, wiring quality and maintenance practices. Staying within the specified relay ratings and using the appropriate transient-suppression configuration is important for reliable long-term operation.
Description
The ABB SAFT175RDO is a dedicated relay output card used within the ABB/Strömberg SAMI STAR adjustable frequency drive architecture. It provides four programmable independent relay contact outputs, with contacts selectable as normally open (NO) or normally closed (NC), making it suitable for interfacing the drive with external control circuits and field devices.

The ABB SAFT175RDO converts four SAMI STAR digital output channels into four potential-free relay-contact output channels. The relay contacts are rated at up to 250 V AC, 5 A continuous and 10 A inrush, providing a practical interface for potential-free control and status signals in compatible legacy drive installations.

The ABB SAFT175RDO incorporates S5–S8 switch settings associated with transient suppression for the relay outputs. This provides installation flexibility when the card is connected to external loads that may generate switching transients, while the actual suppression configuration should follow the applicable SAMI STAR wiring and application documentation.

The ABB SAFT175RDO is particularly relevant to maintenance teams supporting long-service SAMI STAR equipment. As a dedicated hardware output card rather than a modern networked I/O module, it allows compatible legacy drive systems to retain their existing control architecture without requiring an immediate complete drive replacement.
Alternative Names
SAFT 175 RDO SAFT175 RDO SAFTI75RDO SAFT175RD0 SAFTI75RD0 SAFT183 VMC SAFT171PAC SAFT172POW
Technical notes
The ABB SAFT175RDO should be installed and wired according to the applicable SAMI STAR documentation, with particular attention to relay contact ratings, external load characteristics, and transient-suppression settings.
