The ABB SDCS-POW-4 is a switch-mode power supply board specifically designed for the D5-D7 modules of the DCS800 frequency converter. It employs a flyback topology, supports a wide voltage adaptive input of 115-230VAC, and provides stable DC power to the SDCS-CON-4 and other electronic boards, compatible with the full power range of D5-D7 modules.
Discover how Apter Power helps customers source hard-to-find automation parts,overcome delivery challenges and keep production moving.VIEW OUR SUCCESS STORIES >>
Technical specifications for SDCS-POW-4
Manufacturer:
ABB
Part Number:
SDCS-POW-4
Product Family:
ABB Drives
Product Type:
3ADT315100R10001
Rated Operational Voltage:
115 – 230 V AC
Frequency Range:
45 Hz … 65 Hz
Power Consumption:
120 VA
Power Loss:
≤ 60 W.
Tolerance:
-15%/+10%
Powerfail:
95 V
Recommended fusing:
6 AT
Protection Class:
IP20
Mounting:
Electronic support board
Compatible Modules:
DCS800 converter modules D5…D7
Weight:
0.35 kg
Estimated shipping dimensions:
23x11x3.4cm
Tariff Code:
8537101190
Country of origin:
Sweden
Place of shipment:
Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
The ABB SDCS-POW-4 power supply board is a core power supply component for the D5-D7 modules of the DCS800 series frequency converters, playing a crucial role in providing stable power to the internal control circuits of the frequency converter. Its professional switch-mode flyback topology design provides highly efficient energy conversion capabilities, enabling it to continuously output stable DC voltage in complex industrial environments, ensuring the normal operation of the SDCS-CON-4 control board and all internal electronic boards of the frequency converter. This power supply board is highly versatile, requiring no model matching based on the current or voltage range of the D5-D7 modules; it can be directly adapted to all types of modules in this series, significantly improving the convenience of spare parts procurement and maintenance replacement.
In terms of electrical performance, the SDCS-POW-4 exhibits excellent adaptability and stability. It supports a wide input voltage range of 115-230VAC and features automatic detection and identification functions, eliminating the need for manual switching and flexibly adapting to different power supply environments and operating conditions. Its voltage tolerance reaches -15%/+10%, effectively addressing common voltage fluctuations in industrial settings. With a rated power consumption of 120VA and power loss ≤60W, it boasts high energy conversion efficiency and excellent energy consumption control. Furthermore, it features a 95V power failure detection threshold, coupled with recommended 6AT fuse protection, effectively handling abnormal situations such as voltage drops and overloads, providing reliable safety protection for the inverter's electronic system.
This power board's structural design and environmental adaptability are fully tailored to the needs of industrial scenarios. With an IP20 protection rating, it effectively prevents the intrusion of solid foreign objects and is suitable for the internal installation environment of the frequency converter. Utilizing an electronic support plate mounting method, it ensures precise installation and a perfect fit with the mechanical structure of the DCS800 frequency converter's D5-D7 modules, facilitating easy disassembly and assembly for convenient on-site maintenance.
