    Ensure synchronized performance and load balance in your high-power GTO drives with this original ABB parallel connection board, sourced by Apter Power for dependable legacy system maintenance.

SNAT620PCB

/ 4.9
1001 reviews | Need a Specific Revision?
ABB SNAT620PCB is a parallel connection board for GTO inverters that enables parallel operation of high-power inverter units while distributing synchronized control signals for stable system performance.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for SNAT620PCB
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SNAT620PCB

  • Manufacturer:
    ABB
  • Part Number:
    SNAT620PCB
  • Product Family:
    ABB Drives
  • Product Type:
    Parallel Connection Board (GTO)
  • Stock:
    3
  • Operating power supply:
    24V DC
  • Operating temperature:
    0°C to +55°C
  • Storage temperature:
    -40°C to +70°C
  • Protection rating:
    IP00
  • Series: ACV 700 Frequency Converters Series:
    ACV 700 Frequency Converters Series
  • Weight:
    0.28 kg
  • Estimated shipping dimensions:
    19.4x19.2x2.8cm
  • Tariff Code:
    8534001000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Protection Interoperability Application Scenarios

Features:

  • Provides the dedicated parallel connection required for high-power GTO inverter systems.
  • Distributes synchronized trigger and pulse control signals to parallel GTO driver boards.
  • Supports master drive architecture in the ABB ACV 700 Frequency Converters Series with unchanged external connections.
ABB SNAT620PCB is developed for industrial applications where higher output current and greater power capacity are achieved by operating multiple GTO inverter units in parallel. The board serves as the connection point between the master unit and parallel power stages, allowing the complete drive system to function as a coordinated whole. Its role is particularly valuable in large ACV 700 installations that demand reliable power sharing.

Signal synchronization is another important function of ABB SNAT620PCB. In addition to connecting the main power circuits, the board distributes trigger and pulse signals from the master control board to multiple GTO driver boards with consistent timing. Accurate signal distribution helps parallel inverter sections switch together, supporting stable operation under varying industrial loads.

ABB SNAT620PCB operates from a 24 V DC power supply and is suitable for operating temperatures between 0°C and +55°C, with storage temperatures from -40°C to +70°C. The IP00 protection rating makes the board appropriate for installation inside protected electrical cabinets. Combined with the master drive architecture of the ACV 700 Frequency Converters Series, ABB SNAT620PCB provides an effective solution for parallel GTO inverter applications.

The SNAT620PCB ABB Parallel Connection Board (GTO) may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB SNAT620PCB Parallel Connection Board (GTO) Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB SNAT620PCB Parallel Connection Board (GTO) Specs

General

  • Manufacturer ABB
  • Model SNAT620PCB
  • Condition New Original ready stock
  • Product Family SNAT607MCI,SNAT604IFS,SNAT602TAC
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Spike Absorption: Built-in RC absorption circuit suppresses high-frequency commutation overvoltage.
  • Electrical Isolation: Provides kilovolt-level optoelectronic and electromagnetic high-voltage safety isolation.
  • Insulating Coating: The entire board is coated with moisture-resistant and corrosion-resistant industrial-grade conformal coating.
  • Fault Lockout: Automatic cut-off of abnormal pulses to prevent GTO shoot-through damage.
  • Drive Linkage: Perfectly matches SNAT607MCI series pulse drive boards.
  • System Access: Hardware compatible with classic SAMI STAR main control board architecture.
  • Signal Distribution: Automatically adapts to synchronization of trigger signals from one-to-many parallel bridge arms.
  • Diagnostic Bus: Supports seamless communication with the upstream fault monitoring bus.
  • Mine Hoisting: 10. Large-scale asymmetrical load active inverter parallel expansion.
  • Water conservancy project: Current sharing in the ultra-high power speed regulation drive circuit of a giant pumping station.
  • Steel rolling mill: Sensorless bridging of multiple high-current rectifier units in the main drive.
  • Drive system upgrade: Maintenance of high-power frequency converter units in an aging ACV 700 system.
Description
ABB SNAT620PCB is a parallel connection board (GTO) used in the ABB ACV 700 Frequency Converters Series. The board supports parallel inverter configurations by providing the connection platform required for high-power GTO inverter systems. In a parallel drive arrangement, the interface board and the control board are located in the master unit, while the external connections remain the same as those of a single ACV 701 inverter. The master drive requires ABB SNAT620PCB to complete the parallel configuration.

In high-power industrial drives, multiple GTO inverter units are connected in parallel to increase output current and overall power capacity. ABB SNAT620PCB acts as the key connection and signal distribution bridge between these parallel power stages, helping establish efficient, low-impedance connections throughout the main circuit. This arrangement supports coordinated operation of multiple inverter units while maintaining reliable electrical performance during demanding industrial applications.

Besides connecting the parallel main power circuits, ABB SNAT620PCB distributes trigger and pulse control signals from the upper-level control board to the GTO driver boards, ensuring synchronized switching of parallel GTO devices. Uniform signal distribution helps all parallel inverter sections operate together with accurate timing, contributing to balanced load sharing and stable converter performance. Operating from a 24 V DC power supply, ABB SNAT620PCB is designed for environments with temperatures from 0°C to +55°C, storage temperatures from -40°C to +70°C, and an IP00 protection rating.
Alternative Names
SNAT62OPCB SNAT-620-PCB SNAT 620 PCB SNAT604IFS SNAT602TAC SNAT607MCI SNAT617CHC SNAT726INT
Technical notes
Featuring a low-inductance transient suppression layout, the ABB SNAT620PCB (61033513) protects GTO thyristors against dangerous commutation overvoltages under heavy load. This IP00-rated interface board delivers reliable synchronous balancing and essential gate-pulse clamping within a +55°C industrial environment.
