ABB 3BHE022291R0101 PCD230 A101 is mapped in ABB UNITROL 6000 X-power material to the PC D230 CCM Communication Control Measurement unit.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 3BHE022291R0101 PCD230 A101
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3BHE022291R0101 PCD230 A101

  • Manufacturer:
    ABB
  • Part Number:
    3BHE022291R0101 PCD230 A101
  • Product Family:
    ABB UNITROL
  • Product Type:
    CCM Communication Control Measurement module
  • Stock:
    1
  • Function:
    CCM Communication Control Measurement
  • System family:
    UNITROL 6000
  • Variant context:
    X-power
  • Settings:
    system-dependent
  • Minimum order quantity:
    1 piece
  • Order multiple:
    1 piece
  • Dimensions:
    7.35 x 37.3 x 14.2 cm
  • A101 suffix:
    listing suffix requiring nameplate/configuration confirmation
  • Weight:
    1.53 kg
  • Tariff Code:
    8537109090
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Product identity Configuration Replacement check Application
  • ABB UNITROL 6000 X-power Communication Control Measurement module
  • Exact ABB identification number: 3BHE022291R0101, type PC D230 / PCD230 A101
  • System-dependent settings must be retained for the installed excitation-system configuration

3BHE022291R0101 PCD230 A101 is an ABB Communication Control Measurement module documented for the UNITROL 6000 X-power excitation platform.

The CCM module combines communication, control, and measurement functions within its installed UNITROL 6000 configuration. Its exact identification and system assignment must match the receiving excitation system.

Before replacement, preserve the existing system-dependent settings and record the installed connections and module position. After installation, restore the approved configuration and verify communication, control, and measurement operation.

Availability, condition, price, and shipping time for 3BHE022291R0101 PCD230 A101 are confirmed during quotation.

ABB 3BHE022291R0101 PCD230 A101 Communication Control Measurement Module Product Family, Service, Industry Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • ABB identification number: 3BHE022291R0101
  • ABB type designation: PC D230 / PCD230 A101
  • CCM Communication Control Measurement module for UNITROL 6000 X-power
  • Preserve the installed system-dependent settings before removing the PCD230 A101
  • Match the replacement module to the approved UNITROL 6000 X-power configuration
  • Restore the recorded parameters and verify communication, control, and measurement functions
  • Confirm the complete 3BHE022291R0101 and PCD230 A101 identity from the installed module label
  • Record the UNITROL 6000 system variant, module position, connections, and system-dependent settings
  • Do not substitute another PCD230 or later CCM execution without documented compatibility approval
  • Communication, control, and measurement functions in ABB UNITROL 6000 X-power excitation systems
  • Monitoring and coordination of the installed excitation-system operating data
  • Exact replacement of an existing PC D230 CCM module with its approved system-dependent settings
Description
ABB identifies 3BHE022291R0101 PCD230 A101 in the PC D230 A: PEC80-CCM product record for the UNITROL 6000 X-power platform, where it serves the communication, control and measurement function.

This is a configuration-dependent UNITROL execution rather than a generic standalone controller: the installed excitation-system project, cabinet position, connected interfaces and configured settings determine whether the offered unit is suitable.

Because the ABB record names the base execution as PC D230 A: PEC80-CCM while the requested listing carries the A101 suffix, procurement and replacement must reconcile the nameplate, project bill of materials and approved UNITROL configuration before the unit is accepted.
Alternative Names
PCD230 PC D230 PCD230 A101 3BHE022291R0101 3BHE022291R0101 PCD230 3BHE022291R0101 PCD230 A101 ABB PCD230 A101 ABB 3BHE022291R0101 ABB 3BHE022291R0101 PCD230 A101 UNITROL 6000 PCD230 UNITROL 6000 X-power PCD230
Technical notes
PC D230 settings are system-dependent. For 3BHE022291R0101 PCD230 A101, confirm A101 on the module label and retain the original UNITROL 6000 X-power parameter set.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What function is assigned to ABB 3BHE022291R0101 PCD230 A101 in the UNITROL system?
ABB identifies the execution as a CCM Communication Control Measurement unit for UNITROL 6000 X-power, so the installed control and measurement role must be preserved during replacement.
How can a buyer confirm that the ABB 3BHE022291R0101 PCD230 A101 offered by a supplier is the requested execution?
Request a clear nameplate photograph, compare the complete suffix with the project bill of materials, and reconcile the PC D230 A: PEC80-CCM identity with the approved UNITROL configuration before placing the order.
What should an engineer check before approving ABB 3BHE022291R0101 PCD230 A101 as a replacement in an operating excitation system?
Confirm the installed UNITROL variant, cabinet position, connected interfaces, project settings, wiring records and functional acceptance procedure, because the board identity alone does not prove system compatibility.
How can a customer confirm that ABB 3BHE022291R0101 PCD230 A101 will fit the existing UNITROL cabinet before ordering?
Compare the complete nameplate and project bill of materials with the installed slot, connector orientation, mounting arrangement, cable access and service clearance; do not approve the replacement from the PCD230 name alone.
Can any PC D230 board replace ABB 3BHE022291R0101 PCD230 A101?
No. Confirm the PEC80-CCM execution, the UNITROL 6000 X-power variant, system-dependent settings, revision and nameplate suffix before purchase.
What documentation should a buyer request before purchasing ABB 3BHE022291R0101 PCD230 A101?
Request a current quotation showing the complete suffix, an identity or nameplate photograph, the ABB PC D230 A: PEC80-CCM cross-reference, the intended UNITROL 6000 X-power application and confirmation that the supplied execution matches the project configuration.
What commissioning evidence should be kept for ABB 3BHE022291R0101 PCD230 A101?
Retain the nameplate photograph, UNITROL variant, installed slot, configured settings, wiring/interface record, firmware or revision information and the functional control/measurement test results.
