  • Lifecycle status

    Superseded
    Engineering replacement: 1336F-MCB-SP1M

1336F-MCB-SP1C

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1336F-MCB-SP1C is a main-control PCB for 1336F Frames B–G; Rockwell lists 1336F-MCB-SP1M as its latest-FRN successor.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1336F-MCB-SP1C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1336F-MCB-SP1C

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1336F-MCB-SP1C
  • Product Family:
    1336 Drives
  • Product Type:
    Incomplete main-control-board catalog stem
  • Stock:
    1
  • Documented function:
    Main control PCB family
  • Drive family:
    1336F
  • Documented frames:
    B–G
  • Earlier complete numbers:
    1336F-MCB-SP1A through 1336F-MCB-SP1L
  • Documented latest-FRN successor:
    1336F-MCB-SP1M
  • Required verification:
    Installed board label and full drive catalog number
  • Tariff Code:
    8504909090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Identification Successor Review Service Preparation Application
  • Match the complete SP1C suffix shown on the installed main-control PCB
  • Verify that the host drive is a 1336F Frame B–G unit
  • Treat conversion to the latest-FRN SP1M board as an engineered successor review

1336F-MCB-SP1C is an Allen-Bradley main-control PCB for 1336F Frames B–G.

Rockwell’s spare-parts list places SP1C within the earlier SP1A–SP1L group and identifies 1336F-MCB-SP1M as the latest-FRN successor for these frames.

Before replacement, save the parameter set and record firmware, adapters, option boards, motor data, I/O configuration, and the complete drive nameplate.

Availability, condition, price, and shipping time for 1336F-MCB-SP1C are confirmed during quotation.

Allen-Bradley 1336F-MCB-SP1C Main Control PCB Manuals, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Confirm that the installed board label ends in the complete SP1C suffix
  • Record the full 1336F drive catalog number and verify Frame B–G hardware
  • Do not order from the incomplete SP1 stem or from enclosure appearance alone
  • Rockwell lists 1336F-MCB-SP1M as the latest-FRN successor for SP1A–SP1L
  • Compare firmware, adapters, option boards and parameter compatibility before conversion
  • Plan functional acceptance testing rather than assuming an automatic drop-in exchange
  • Back up parameters, motor data, I/O configuration and the fault queue before removal
  • Photograph connector positions, adapter boards and option-card settings
  • Inspect the host drive for power-stage or supply faults before condemning the control PCB
  • Replacement of an identified SP1C main-control PCB in a 1336F Frame B–G drive
  • Restoration of legacy 1336 PLUS II control electronics with the original board suffix
  • Engineered migration from an SP1C board to the documented latest-FRN SP1M successor
Description
1336F-MCB-SP1C is an Allen-Bradley main-control PCB for 1336F Frames B–G.

Rockwell places SP1C within the SP1A–SP1L group superseded by 1336F-MCB-SP1M, the latest-FRN main-control board for these frames. This successor relationship does not by itself establish a drop-in replacement.

Before ordering, record the installed SP1C label, complete drive catalog number and frame, firmware, option and adapter boards, parameter backup and machine I/O requirements.
Alternative Names
Allen-Bradley 1336F-MCB-SP1 AB 1336F-MCB-SP1 Rockwell Automation 1336F-MCB-SP1 1336F MCB SP1 1336F-MCB-SP1 Main Control PCB Family 1336F Frames B-G Main Control Board SP1 Family
Technical notes
1336F-MCB-SP1C is a suffix-specific 1336F main-control PCB for Frames B–G, not an incomplete catalog stem or a complete drive. Rockwell lists SP1M as its latest-FRN successor; verify firmware, adapters, parameters and machine behavior before conversion.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What information is required when ordering 1336F-MCB-SP1C?
Provide a clear photo of the SP1C board label, the complete 1336F drive catalog number, frame, input voltage, firmware, installed adapters and option boards.
Is 1336F-MCB-SP1M a direct replacement for 1336F-MCB-SP1C?
Rockwell lists SP1M as the latest-FRN successor for SP1A through SP1L, which includes SP1C. Still verify firmware, adapters, options, parameters and machine I/O before treating it as a direct exchange.
Is 1336F-MCB-SP1C a complete 1336 PLUS II drive?
No. It is the main-control PCB only. The power structure, enclosure, gate boards, HIM, adapters, communications hardware and other assemblies remain separate.
What must be backed up before removing 1336F-MCB-SP1C?
Save the full parameter set and record firmware, motor data, option boards, adapter settings, digital and analog I/O, feedback configuration and the current fault queue.
Why might a drive fail to start after replacing 1336F-MCB-SP1C?
Check firmware compatibility, restored parameters, adapter recognition, option-board configuration, enable inputs, motor data and the original fault that led to board replacement.
Can 1336F-MCB-SP1C be installed in any 1336 drive frame?
No. Rockwell identifies this main-control-board group for 1336F Frames B–G. Verify the complete host-drive catalog number and frame before installation.
How should 1336F-MCB-SP1C be tested after installation?
Verify HIM and adapter communication, restored parameters, I/O states, motor direction, speed regulation, current limits, controlled stopping, protective trips and supervised operation under load.
