  • Lifecycle status

    End of Life
    Discontinued Date: December 31, 2027.
    Replacement: No planned Rockwell Automation replacement.

1756-BA2

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1756-BA2 is a lithium battery assembly for Series B ControlLogix 1756-L6x controllers, preserving controller memory during power loss.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 1756-BA2
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1756-BA2

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1756-BA2
  • Product Family:
    ControlLogix
  • Product Type:
    ControlLogix L6X Series B Lithium Battery Assembly
  • Stock:
    1
  • Controller compatibility:
    Series B 1756-L6x only
  • Chemistry:
    lithium
  • Operating temperature:
    0 - 60 ℃
  • Battery cell:
    One Duracell DL123A lithium cell
  • Lithium content:
    0.55 g
  • Short-term storage temperature:
    -45 to +85 °C for no more than 30 days
  • Recommended storage environment:
    25 °C; 40–60% relative humidity
  • Lithium Content:
    0.55 g
  • Function:
    Replacement Battery Backup
  • Battery Type:
    Hermetically sealed lithium battery assembly
  • Low-battery Indication:
    BAT indicator steady red
  • Low-battery Fault:
    Minor fault, Type 10, Code 10
  • Tariff Code:
    8507600090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Controller Match Battery Care Service Checks Application
  • Battery assembly specified for Series B 1756-L6x controllers
  • Supports retained controller memory during loss of normal power
  • Published operating range is 0–60 °C

Allen-Bradley 1756-BA2 is a controller battery assembly, not a replacement controller or power supply.

Verify the installed controller Series before ordering because Rockwell publishes this battery for Series B 1756-L6x use.

Battery condition should be maintained under the controller documentation and the site's approved shutdown procedure.

Availability: Exact condition, stock, price, and shipping time are confirmed during quotation.

Allen-Bradley 1756-BA2 ControlLogix Series B Lithium Battery Assembly Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Confirm the 1756-L6x controller catalog number
  • Confirm the Series B marking
  • Do not substitute a battery by appearance alone
  • Use the controller's approved battery procedure
  • Observe the published environmental limits
  • Inspect controller battery status during maintenance
  • Check controller status before beginning battery service
  • Confirm the battery assembly is correctly seated and connected
  • Verify controller operation and retained memory after service
  • Memory-retention support for installed Series B controllers
  • Planned maintenance of legacy ControlLogix systems
  • Controller spare-parts planning where exact series compatibility is verified
Description

1756-BA2 is the lithium battery assembly specified by Rockwell Automation for Series B ControlLogix 1756-L6x controllers. It supports retention of controller memory when normal chassis power is unavailable.

The official product record identifies 1756-BA2 as a ControlLogix L6X Series B-only battery assembly. The published operating-temperature range is 0–60 °C.

Confirm the controller catalog number, Series B marking, installed battery condition, and maintenance procedure before replacement. Do not treat this battery as an approved substitute for other ControlLogix controller series.

Revisions

Revision Part #

Also known as

1756-BA2 Ser A
1756-BA2/A, Series A, Rev A
Alternative Names
1756-BA2 1756 BA2 1756BA2 Allen-Bradley 1756-BA2 Rockwell Automation 1756-BA2 ControlLogix 1756-BA2
Technical notes
1756-BA2 fits Series B 1756-L6x controllers only; verify the controller label before replacement and follow the approved battery-maintenance procedure.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is Allen-Bradley 1756-BA2 suitable for every ControlLogix controller?
No. It is specified for Series B 1756-L6x controllers. Confirm the controller catalog number and its Series marking before ordering.
Does Allen-Bradley 1756-BA2 retain the whole control system during a power failure?
It provides controller backup support, not chassis or field-device power. Determine separately how the application handles loss of power to I/O and external equipment.
Can Allen-Bradley 1756-BA2 be exchanged while the controller is energized?
Follow the controller's official battery-replacement procedure and the site's electrical-safety rules. Do not assume live replacement is permitted for every installation.
Why is the controller Series important when ordering Allen-Bradley 1756-BA2?
The published compatibility is Series B-only. A similar battery can have different fit, connector, or support status on another controller series.
What symptom can indicate that Allen-Bradley 1756-BA2 needs attention?
Treat a controller low-battery indication or loss of retained information as a maintenance event and inspect the battery and controller documentation before service.
Is Allen-Bradley 1756-BA2 supplied with a controller?
Confirm the quotation line by line. A controller, battery, and spare battery are separate supply items unless the offer explicitly says otherwise.
Is there an official planned Rockwell replacement for Allen-Bradley 1756-BA2?
Rockwell Automation lists no planned RA replacement. Confirm the installed controller strategy before a long-term modernization decision.
