Allen-Bradley 1756-M08SE/B
Allen-Bradley 1756-M08SE/B
Allen-Bradley 1756-M08SE/B
Allen-Bradley 1756-M08SE/B
Allen-Bradley 1756-M08SE/B
Allen-Bradley 1756-M08SE/B
Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail sales1@apterpower.com

1756-M08SE/B

/ 4.9
1001 reviews | Need a Specific Revision?
The 1756-M08SE/B is a ControlLogix Sercos interface module supporting up to 16 drives at 4/8 Mbps, 0.5–2 ms cycle times, position/velocity/torque control, and 760 mA backplane current draw.
Get a quick price for 1756-M08SE/B
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1756-M08SE/B

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1756-M08SE/B
  • Product Family:
    ControlLogix
  • Product Type:
    ControlLogix Sercos Interface Module
  • Maximum Drives:
    16
  • Sercos Data Rates:
    4 Mbps, 8 Mbps
  • Cycle Time @ 8 Mbps:
    0.5 ms (4 drives), 1 ms (8 drives), 2 ms (16 drives)
  • Drive Control Modes:
    Position, velocity, torque
  • Backplane Current (24V):
    2.5 mA
  • Power Dissipation:
    5.0 W
  • Operating Temperature:
    0 to 60°C
  • Key Benefit:
    Solves high-density synchronized motion control with deterministic Sercos communication for up to 16 drives—reduces hardware count and enables coordinated multi-axis motion.
  • Weight:
    0.22 kg
  • Estimated shipping dimensions:
    3.5x14x14.8cm
  • Tariff Code:
    8517795000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Performance Application Scenarios

Features:

  • Sercos interface with selectable 4 Mbps or 8 Mbps data rates for high-speed deterministic communication.
  • Supports up to 16 drives with cycle times as low as 0.5 ms for coordinated multi-axis motion.
  • Position, velocity, and torque control modes with 760 mA backplane current draw and 5.0 W power dissipation.
The 1756-M08SE/B controls up to 16 drives from a single module. At 8 Mbps, four drives run at 0.5 ms cycle times—fast enough for printing and packaging lines. This reduces hardware count compared to single-axis modules.

Choose your speed. At 4 Mbps, run two drives at 0.5 ms or eight drives at 2 ms. At 8 Mbps, run four drives at 0.5 ms or 16 drives at 2 ms. Match cycle time to application needs without over-provisioning.

Operates from 0 to 60°C, stores from -40 to 85°C. Conformal-coated versions handle moisture and corrosion. The 1756-M08SE/B meets IEC radiated RF immunity at 10V/m, keeping communication reliable in electrically noisy plants.

The 1756-M08SE/B Allen-Bradley Interface Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Allen-Bradley 1756-M08SE/B Interface Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Allen-Bradley 1756-M08SE/B Interface Module Specs

General

  • Manufacturer Allen-Bradley
  • Model 1756-M08SE/B
  • Condition New Original ready stock
  • Product Family 1756-M08SEK/B,1756-M03SE/A,1756-M03SEK/A
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • High-speed packaging machinery: Utilizes extremely short cycle times for high-speed cigarette packaging, bottling, and sealing.
  • Precision material handling: Applied to automated warehousing systems, multi-axis robotic arms for coordinate conversion and precise positioning.
  • Semiconductor and electronic assembly: Transmits signals via fiber optics in environments requiring high cleanliness and electromagnetic interference (EMI) protection.
  • Machine tools and metal processing: Supports flying shears, rotary cutting, and precision CNC coordinate control.
  • High-bandwidth digital communication: Supports SERCOS data rates of 4 Mbps and 8 Mbps.
  • Extremely low cycle time: At 8 Mbps, the cycle time is only 0.5 ms when controlling 4 axes; the cycle time is 1 ms when controlling 8 axes at full load.
  • Versatile control modes: Supports closed-loop control modes for position, velocity, and torque, which can be switched in real time according to process requirements.
  • Efficient cabling: Utilizes fiber optic loop connections, reducing up to 18 cables per axis compared to traditional analog wiring, significantly lowering installation costs and maintenance complexity.
  • Multi-axis Synchronous Collaboration: In complex production lines, the 1756-M08SE/B integrates eight servo drives (such as Kinetix 6000 or Ultra3000 series) into a single fiber optic loop, ensuring complete synchronization of all axes.
  • Harsh Electromagnetic Environments: Utilizing fiber optic transmission, it completely eliminates positional deviations caused by electrical noise when operating near large motors or high-frequency heating equipment.
  • System Diagnosis and Maintenance: Through Studio 5000 software, engineers can remotely monitor the real-time current, speed, and fault codes of the servo drives, significantly reducing downtime for troubleshooting.
Description
The 1756-M08SE/B is a high-performance Sercos interface module for Allen-Bradley ControlLogix platforms, supporting up to 16 drives with selectable data rates of 4 Mbps or 8 Mbps. Cycle times range from 0.5 ms to 2 ms depending on drive count and data rate.

This module operates in any ControlLogix chassis slot and draws 760 mA from the 5.1V backplane and 2.5 mA from 24V, with 5.0 W power dissipation. The 1756-M08SE/B uses plastic or glass fiber-optic cables for Sercos communication, with various jacket options including non-jacketed, PVC, and nylon.

The 1756-M08SE/B operates from 0 to 60°C and stores from -40 to 85°C, meeting IEC 61000-4-3 radiated RF immunity standards at 10V/m. Conformal-coated versions (K suffix) are available for harsh environments.

This module solves the pain point of high-density synchronized motion control. The 1756-M08SE/B’s Sercos interface provides deterministic communication for up to 16 drives, reducing hardware count compared to single-axis modules.
Revisions

Revision Part #

Also known as

1756-M08SE Ser A
1756-M08SE/A, Series A, Rev A
1756-M08SE Ser B
1756-M08SE/B, Series B, Rev B
Alternative Names
1756-M08SEK/B 1756-M03SE/A 1756-M03SEK/A 1756-M16SE/A
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How many drives can the 1756-M08SE/B control?
It supports up to 16 drives with Sercos communication at 4 or 8 Mbps.
What are the cycle time options for the 1756-M08SE/B?
At 4 Mbps: 0.5 ms (2 drives), 1 ms (4 drives), 2 ms (8 drives). At 8 Mbps: 0.5 ms (4 drives), 1 ms (8 drives), 2 ms (16 drives).
What is the backplane current draw of this module?
It draws 760 mA from the 5.1V backplane and 2.5 mA from 24V, with 5.0 W power dissipation.
What control modes does the 1756-M08SE/B support?
It supports position, velocity, and torque control modes for versatile motion applications.
