1756-RIO

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1756-RIO is a discontinued ControlLogix Universal Remote I/O scanner/adapter for scheduled legacy RIO communication.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1756-RIO
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1756-RIO

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1756-RIO
  • Product Family:
    ControlLogix
  • Product Type:
    ControlLogix Universal Remote I/O Scanner/Adapter Module
  • Stock:
    1
  • Network function:
    Universal Remote I/O scanner and adapter
  • Remote I/O channels:
    1
  • Supported network roles:
    scanner mode and adapter mode
  • Data transfer:
    digital, block-transfer, analog, and specialty data without MSG instructions
  • System configuration:
    scheduled connections
  • Rack capacity:
    up to 32 racks in any combination of rack size or block transfers
  • Communication Rate:
    57.6 Kbps, 115.2 Kbps, 230.4 Kbps
  • Maximum Connections:
    10 scheduled I/O connections
  • Current Draw at 5.1 V DC:
    450 mA
  • Current Draw at 24 V DC:
    5 mA
  • Power Dissipation:
    2.5 W
  • Thermal Dissipation:
    8.5 BTU/hr
  • Isolation Voltage:
    50 V continuous, basic insulation, RIO communication lines to backplane
  • Isolation Test Voltage:
    500 V AC for 60 seconds
  • Operating Temperature:
    0…60 °C (32…140 °F)
  • Storage Temperature:
    -40…+85 °C (-40…+185 °F)
  • Relative Humidity:
    5…95%, noncondensing
  • Tariff Code:
    8471605000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Network Record Remote I/O Commissioning Scanner & Adapter Modes Application
  • Operates in documented Universal Remote I/O scanner or adapter mode
  • Uses scheduled connections for digital, block-transfer, analog, and specialty data
  • Supports up to 32 racks and is discontinued with no planned Rockwell Automation replacement

1756-RIO is an Allen-Bradley ControlLogix Universal Remote I/O scanner/adapter module.

In scanner mode it exchanges scheduled data with remote adapters; in adapter mode it emulates one or more racks for an installed scanner and can monitor other racks.

Preserve the Logix project, scanner/adapter mode, rack map, block-transfer definitions, baud rate, cable route, termination, and adapter inventory before replacement or migration.

Availability, condition, price, and shipping time for 1756-RIO are confirmed during quotation.

Allen-Bradley 1756-RIO ControlLogix Remote I/O Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Record every remote adapter, rack address, and network segment before exchange
  • Preserve the approved scanner schedule in the controller project archive
  • Identify cable routing and termination at each serviced network section
  • Verify scanner and adapter communication before machine-output operation
  • Test the installed rack inventory against the accepted Remote I/O project
  • Investigate a missing rack from its address, adapter, cable, and schedule records
  • Configure scanner mode when 1756-RIO owns scheduled connections to installed Remote I/O adapters
  • Configure adapter mode when the ControlLogix chassis must emulate one or more racks for an existing scanner
  • Use the accepted rack map and scheduled connection definitions instead of MSG instructions
  • ControlLogix scanner-mode systems communicating with legacy Remote I/O adapters
  • Adapter-mode systems emulating one or more Remote I/O racks for an installed scanner
  • PLC-5, PLC-3, or SLC migration projects retaining existing Universal Remote I/O wiring
Description
1756-RIO is a discontinued Allen-Bradley ControlLogix Universal Remote I/O communication module that can operate as either a scanner or an adapter.

Scanner mode exchanges scheduled data with legacy Remote I/O adapters. Adapter mode lets a ControlLogix chassis emulate one or more racks for an existing scanner and monitor additional racks on the network.

Before replacement or migration, preserve the operating mode, Logix project, rack map, block-transfer definitions, baud rate, cable route, termination, adapter inventory, firmware, and observed network state.
Revisions

Revision Part #

Also known as

1756-RIO Ser A
1756-RIO/A, Series A, Rev A
1756-RIO Ser B
1756-RIO/B, Series B, Rev B
Alternative Names
1756-RIO 1756 RIO 1756RIO Allen-Bradley 1756-RIO Rockwell Automation 1756-RIO ControlLogix 1756-RIO
Technical notes
1756-RIO is a discontinued Remote I/O scanner; preserve the complete network drawing, controller project, adapter identities, addresses, schedule, and termination records before replacement.
