    Apter Power specializes in sourcing verified, hard-to-find Rockwell Automation 1492-CABLE025TBCH interface cables, providing manufacturing plants with a dependable hardware lifeline to sustain legacy systems.

1492-CABLE025TBCH

/ 4.9
1001 reviews | Need a Specific Revision?
The Allen Bradley 1492-CABLE025TBCH is 2.5-meter digital I/O module-ready connectivity solution featuring a pre-wired 36-point 1756-TBCH terminal block on one end and raw flying leads on the other.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1492-CABLE025TBCH
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1492-CABLE025TBCH

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1492-CABLE025TBCH
  • Product Family:
    Flex I/O
  • Product Type:
    Digital I/O Module-Ready Pre-Wired Cable
  • Stock:
    1
  • Cable Length:
    2.5 Meters / 8.2 Feet
  • Number of Total Conductors:
    40 Conductors
  • Active / Idle Line Allocation:
    36 Active Pin Lines, 4 Lines Not Connected
  • Conductor Wire Gauge Size:
    #18 AWG (0.823 mm²)
  • Chassis End Connector Type:
    36-Point 1756-TBCH Removable Terminal Block (RTB)
  • Field End Connector Type:
    Free Flying Leads / Color-Coded Stripped Wires
  • Cable Jacket Outer Diameter:
    Nominal 11.4 mm to 14.1 mm
  • Rated Insulation Voltage (AC):
    300 V AC
  • Rated Insulation Voltage (DC):
    300 V DC
  • Insulation Temperature Rating:
    80°C (176°F)
  • Storage Temperature Limits:
    Minimum: -20°C (-4°F) / Maximum: 80°C (176°F)
  • Relative Ambient Humidity:
    5% to 95% Non-condensing RH
  • Environmental Pollution Degree:
    Pollution Degree 2
  • Global Product Compliance:
    CE, c-UL-us Listed, UL, FM Approved
  • Weight:
    0.65 kg
  • Estimated shipping dimensions:
    28x25x3.5cm
  • Tariff Code:
    8544421900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Operating Environment Monitoring & Control

Features:

  • Pre-Wired 1756-TBCH Integration Defeats Commissioning Delays
  • Heavy-Duty #18 AWG Multi-Conductor Core Safeguards Signals
  • Open-Architecture Flying Leads Provide Ultimate Adaptation
The Allen Bradley 1492-CABLE025TBCH features a factory-terminated 36-point removable terminal block that mounts natively onto ControlLogix digital modules. This completely eliminates manual pin-crimping, terminal sorting, and individual conductor label checking on the chassis end, shortening the labor overhead of panel construction by up to 75%.

Built with high-grade copper conductors across a 40-wire matrix, the Allen Bradley 1492-CABLE025TBCH provides exceptional cross-sectional electrical density. The #18 AWG gauge minimizes signal attenuation and resistance over 2.5 meters, ensuring crisp digital logic transitions and resilient operation when exposed to severe localized electromagnetic fields.

While the controller end of the Allen Bradley 1492-CABLE025TBCH is specialized for Rockwell chassis, the field end provides raw, color-coded flying leads. This gives engineers complete freedom to interface with generic terminal distribution strips, custom relays, barrier blocks, or third-party junction hardware without buying restrictive proprietary interfaces.

The 1492-CABLE025TBCH Allen Bradley ControlLogix Digital I/O Module-Ready Pre-Wired Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen Bradley 1492-CABLE025TBCH ControlLogix Digital I/O Module-Ready Pre-Wired Cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Allen Bradley 1492-CABLE025TBCH ControlLogix Digital I/O Module-Ready Pre-Wired Cable

General

  • Manufacturer Allen Bradley
  • Model 1492-CABLE025TBCH
  • Condition New Original ready stock
  • Product Family 1492-IFM40F,1492-IFM20F,1492-XIM4024-16R
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • High-Density Manufacturing Panels: The Allen Bradley 1492-CABLE025TBCH is widely utilized in high-density automotive assembly control panels where rapid chassis swaps and organized wire management are mandatory to preserve uptime.
  • Petrochemical and Energy Control Rooms: Deployed within remote marshalling enclosures in oil, gas, and power distribution systems, interfacing complex 1756 ControlLogix digital input cards to field-isolated safety barriers.
  • Water/Wastewater Processing Infrastructure: Chosen for municipal pump controls and filtration networks where its heavy insulation jacket resists damp environments and localized vibration from heavy pumping machinery.
  • Legacy Automation Retrofitting: Functions as an active component in brownfield automation modernization programs, converting old PLC platforms over to 1756 frameworks without rewriting physical field wiring arrays.
  • Elevated Thermal Thresholds: Designed with high-performance insulation compound allowing safe execution alongside warm switching equipment under constant temperatures up to 80°C.
  • Industrial Micro-Climate Mitigation: Possesses a structural rating suited for Pollution Degree 2 environments, guarding the core against non-conductive dust accumulation and moderate moisture conditions.
  • Thermal Shock Stabilization: Survives abrupt cabinet climate variations due to its robust storage limits spanning from -20°C up to 80°C, maintaining flexibility without cracking.
  • Sub-Chassis Condensation Resilience: Prevents micro-current leakage across neighboring terminal blocks under high-humidity circumstances, operating seamlessly up to 95% non-condensing RH.
  • Lossless Discrete Processing Link: Preserves sharp signal rising-and-falling edge logic states for high-speed digital counters or proximity sensors routed to ControlLogix processors.
  • Electronic Protection Mapping: Fully supports the routing of output card metrics from diagnostic module variants (like short-circuit detection or open-wire flags) down to external marshalling lines.
  • Structured Multi-Point Distribution: Isolates 36 concurrent digital control pathways in a single trunk line, reducing the cross-talk potential that often compromises adjacent loose terminal wiring configurations.
  • Optimized Voltage Retention: Heavy-gauge #18 AWG copper content suppresses internal impedance, ensuring low voltage drop over its 2.5m run, keeping field relay coils powered within design specification.
Description
Engineered as a high-density wiring asset, the Allen Bradley 1492-CABLE025TBCH enables immediate, secure coupling to 36-point ControlLogix digital I/O modules. By deploying a factory-fused, pre-wired 1756-TBCH removable terminal block (RTB), it bypasses the traditional manual pin-out phase, providing system integrators with an uncompromised electrical path from the processor chassis directly to field marshalling panels.

Featuring a robust 40-conductor construction utilizing #18 AWG copper wire gauge, the Allen Bradley 1492-CABLE025TBCH optimizes signal continuity while minimizing voltage drops across its 2.5-meter span. The premium formulation of the outer jacket ensures substantial mechanical tensile defense, shielding internal control lines from the geometric stress, friction, and electromagnetic interference typical of high-density industrial control cabinets.

n critical automation commissions, manual wiring errors during RTB population pose significant diagnostic delays; the Allen Bradley 1492-CABLE025TBCH mitigates this risk via rigid factory quality controls. The integration-ready flying leads permit seamless adaptation to proprietary terminal interfaces or customized terminal blocks, preserving custom panel layout preferences while enforcing a highly organized, professional cabinetry aesthetic.

Beyond clean-slate installations, the Allen Bradley 1492-CABLE025TBCH serves as a vital tool during system upgrades, accommodating effortless conversion pathways from legacy Modicon 800 or Allen-Bradley 1771 PLC-5® platforms over to modern 1756 ControlLogix automation frameworks. This cross-generation adaptability preserves capital investments while accelerating factory floor modernization.
Alternative Names
1492 CABLE025TBCH I492-CABLE025TBCH 1492-CABLEO25TBCH I492-CABLEO25TBCH 1492-IFM40F 1492-IFM20F 1492-XIM4024-16R 1492-IFM40F-FS-2
Technical notes
When installing the Allen Bradley 1492-CABLE025TBCH, note that out of its 40 total internal conductors, exactly 4 conductors are dedicated as "Not Connected" (flying leads end) to account for structural core balancing and spare routing paths. System engineers must verify that the field-side terminations map correctly to the standard 1492-series wiring table colors to maintain precise signal isolation across the 36 active lines mapped to the 1756-TBCH block.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which specific digital I/O modules are fully compatible with the Allen Bradley 1492-CABLE025TBCH?
The Allen Bradley 1492-CABLE025TBCH is designed to interface with 36-point digital I/O modules within the ControlLogix 1756 platform. Compatible input modules include the 1756-IA16I, 1756-IA32, 1756-IB16, 1756-IB16I, 1756-IB32, 1756-IH16I, 1756-IM16I, and 1756-IV32. Compatible output modules encompass the 1756-OA16I, 1756-OB8EI, 1756-OB16D, 1756-OB16I, 1756-OB16IS, 1756-OB32, 1756-OH8I, 1756-OV32E, 1756-OW16I, and 1756-OX8I.
How does the internal conductor layout of the Allen Bradley 1492-CABLE025TBCH map out relative to the 36 terminals on the 1756-TBCH arm?
The Allen Bradley 1492-CABLE025TBCH contains a total of 40 conductors, where 36 individual conductors are precisely bound to the corresponding numbered screw terminal positions (1 through 36) on the pre-wired 1756-TBCH connector. The remaining 4 conductors are left completely unassigned (Not Connected) at the flying lead bundle end, which serves as a safety tolerance or extension reserve for custom wiring modifications.
Does the Allen Bradley 1492-CABLE025TBCH include diagnostic signals or specialized parameter pins for firmware-level tracking?
No, the Allen Bradley 1492-CABLE025TBCH is a passive electro-mechanical interconnect system and does not contain microprocessor components or active firmware diagnostic monitoring. However, it fully carries deep diagnostic signals (such as wire-fault sensing, electronic fusing status, and short-circuit monitoring) from intelligent ControlLogix modules like the 1756-OB16D or 1756-OB8EI directly to field terminals without interference.
What is the conductor wire color coding convention applied across the flying leads end of the Allen Bradley 1492-CABLE025TBCH?
The Allen Bradley 1492-CABLE025TBCH utilizes Rockwell Automation’s standardized industry color code matrix for its 40-conductor lines to aid engineering identification. Leads 1 through 6 utilize solid base colors (Black, White, Red, Green, Orange, Blue), while pins 7 through 40 transition into complex dual and triple stripe combinations (e.g., White/Black, Red/Black/Green) to guarantee absolute clarity during field side commissioning.
What are the exact environmental limitations regarding temperature and humidity for deploying the Allen Bradley 1492-CABLE025TBCH?
The Allen Bradley 1492-CABLE025TBCH is rated for an insulation temperature threshold of up to 80°C (176°F). For storage and unpowered transport, it tolerates extreme environments ranging from -20°C to 80°C (-4°F to 176°F). The cable assembly operates reliably under non-condensing relative humidity bands between 5% and 95% RH and complies with standard industrial Pollution Degree 2 constraints.
Are there any specific safety certifications or hazardous location approvals verifying the Allen Bradley 1492-CABLE025TBCH for global trade?
Yes, the Allen Bradley 1492-CABLE025TBCH complies with stringent international quality metrics required by global engineering procurement. The cable assembly is officially CE marked, c-UL-us Listed (for the United States and Canada safety standards), and possesses FM (Factory Mutual) approval, confirming its structural integrity within safe-area industrial control enclosures.
