21000-16-10-00-120-04-02

/ 4.9
1001 reviews | Need a Specific Revision?
The 21000-16-10-00-120-04-02 is a 21000 Series Proximity Probe Housing Assembly designed for use with 3300 XL 8 mm probes. This model features a 1.0 m (39 in) probe cable length, no standoff adapter, and 2.0 in probe penetration.
Get a quick price for 21000-16-10-00-120-04-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 21000-16-10-00-120-04-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    21000-16-10-00-120-04-02
  • Product Family:
    21000, 24701, and 164818 Proximity Probe Housing A
  • Product Type:
    21000 Series Proximity Probe Housing Assembly
  • Compatible Probe:
    3300 XL 8 mm probe with connector
  • Probe Cable Length:
    1.0 m (39 in)
  • Standoff Adapter:
    None
  • Probe Penetration:
    2.0 in
  • Mounting Thread:
    3/4-14 NPT
  • Fittings Included:
    One 3/4-14 NPT plug only
  • Housing Material:
    Aluminum
  • Standard Compliance:
    API 670
  • Key Benefit:
    Model 21000-16-10-00-120-04-02 provides CSA explosion-proof certification and CSA Type 4 enclosure rating for hazardous area compliance.
  • Weight:
    1.44 kg
  • Estimated shipping dimensions:
    60x8.5x8.5cm
  • Tariff Code:
    9030900090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Operating Environment Monitoring and Control

Features:

  • The 21000-16-10-00-120-04-02 features a compact aluminum housing with no standoff adapter for space-constrained installations.
  • This model includes CSA explosion-proof certification and CSA Type 4 enclosure rating for hazardous areas.
  • The 21000-16-10-00-120-04-02 is fully compliant with API 670 Standard for externally mounted proximity probe housings.
The 21000-16-10-00-120-04-02 includes essential mounting components that directly affect the proper installation of the monitoring system in hazardous environments. It comes with one 3/4-14 NPT plug only and utilizes a 3/4-14 NPT mounting thread for secure attachment to machinery casings. The 21000-16-10-00-120-04-02 is certified as a CSA Type 4 enclosure, ensuring protection against water and dust ingress while maintaining explosion-proof integrity.

For hazardous area compliance, the 21000-16-10-00-120-04-02 is rated explosion-proof and suitable for intrinsically safe applications. This housing assembly is fully compliant with the American Petroleum Institute's API 670 Standard for externally mounted proximity probe housings. The compact design with no standoff adapter makes the 21000-16-10-00-120-04-02 ideal for installations where clearance between machinery casing and surrounding equipment is limited.

The 21000-16-10-00-120-04-02 represents a complete solution for externally mounted probe installations requiring hazardous area approvals in space-constrained locations. This assembly addresses the pain point of probe protection in explosive environments through its CSA certification while the compact design solves clearance limitations. The 21000-16-10-00-120-04-02 ensures reliable vibration and position monitoring while meeting stringent API 670 requirements for petroleum industry applications.

The 21000-16-10-00-120-04-02 Bently Nevada Proximity Probe Housing Assemblies may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 21000-16-10-00-120-04-02 Proximity Probe Housing Assemblies Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 21000-16-10-00-120-04-02 Proximity Probe Housing Assemblies Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 21000-16-10-00-120-04-02
  • Condition New Original ready stock
  • Product Family 21000-30-10-00-120-04-02,21000-31-10-00-120-04-02,21000-32-10-00-120-04-02
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Radial Vibration Monitoring: Mounted on the bearing housing, it measures the dynamic displacement of the shaft relative to the bearing, used to identify imbalance, misalignment, or oil film instability.
  • Axial Displacement Protection: Monitors the thrust position of the rotor to prevent collisions between the rotor and stators (such as impeller and casing).
  • Phase Reference (Keyphasor®): Measures shaft speed and provides a phase reference point for Bode plot and polar coordinate analysis.
  • Extreme Temperature: The probe and cable operate within a temperature range of -51°C to +177°C (-60°F to +351°F).
  • Pressure and Sealing: The probe head and housing are sealed to withstand pressure differentials up to 7 bar (100 psi).
  • Chemical Resistance: Utilizing a polyphenylene sulfide (PPS) tip and stainless steel housing, it resists corrosion from most industrial lubricants, solvents, and process chemicals.
  • System Composition: Requires connection to a 3300 XL extension cable and a 3300 XL proximitor. The proximitor converts displacement changes into a stable analog voltage signal (standard sensitivity 7.87 V/mm or 200 mV/mil).
  • Monitoring Rack: Signal input to a Bently Nevada 3500 or 2300 series monitoring system.
  • Protection Functions: The monitoring system automatically compares the collected data with preset Alert and Danger limits. If a threshold is exceeded, the system outputs a control command (shutdown interlock) via relay to prevent major equipment damage.
Description
The 21000-16-10-00-120-04-02 features a rugged aluminum housing designed for use with 3300 XL 8 mm probes in hazardous area applications. This model includes a 1.0 m (39 in) probe cable length, no standoff adapter, and 2.0 in probe penetration for precise positioning in critical machinery.

The 21000-16-10-00-120-04-02 is CSA approved as explosion-proof for hazardous areas and certified as a CSA Type 4 enclosure, ensuring reliable operation in demanding environments. This 21000 series assembly is fully compliant with the American Petroleum Institute's API 670 Standard for externally mounted proximity probe housings.

The 21000-16-10-00-120-04-02 provides robust protection for 3300 XL 8 mm probes while maintaining accessibility for installation and maintenance. With no standoff adapter, this housing assembly offers a compact configuration for applications with limited space.

The 21000-16-10-00-120-04-02 represents a complete solution for externally mounted proximity probe installations in hazardous areas with space constraints. This assembly addresses the pain point of probe protection in explosive environments through its CSA explosion-proof rating and Type 4 enclosure certification.
Alternative Names
21000-30-10-00-120-04-02 21000-31-10-00-120-04-02 21000-32-10-00-120-04-02 21000-33-10-00-120-04-02
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What space-saving advantage does the 21000-16-10-00-120-04-02 offer compared to standard housings?
The absence of a standoff adapter reduces overall assembly length, making it ideal for installations with limited clearance between machinery casing and surrounding equipment.
How does the 21000-16-10-00-120-04-02 maintain hazardous area compliance with only one NPT plug?
The single 3/4-14 NPT plug provides proper sealing for the cable entry point, maintaining the CSA explosion-proof integrity while simplifying installation with fewer components.
What types of machinery benefit most from the 2.0 inch probe penetration of this housing?
Centrifugal compressors, steam turbines, and pumps with thinner casing walls benefit from the 2.0 inch penetration, providing adequate probe depth without excess protrusion into the measurement area.
Why choose the 21000-16-10-00-120-04-02 over stainless steel alternatives for offshore applications?
The aluminum construction offers weight savings for top-side installations while maintaining CSA Type 4 corrosion resistance, though stainless steel is recommended for submerged or highly corrosive environments.
