Bently Nevada 21000-16-10-15-057-03-02 is a 21000 probe housing assembly configured for a 3300 XL 8 mm probe, with 5.7 in penetration, 1.0 m probe cable and 3/4-14 NPT mounting.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 21000-16-10-15-057-03-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 21000-16-10-15-057-03-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    21000-16-10-15-057-03-02
  • Product Family:
    21000, 24701, and 164818 Proximity Probe Housing A
  • Product Type:
    Probe Housing Assembly
  • Stock:
    1
  • Probe Configuration:
    3300 XL 8 mm probe
  • Probe Cable Option:
    1.0 m
  • Minimum Standoff (C):
    1.5 in (38 mm)
  • Probe Penetration (D):
    5.7 in
  • Fittings Option:
    3/4-14 NPT plug, 3/4-to-1/2 NPT reducer, cable seal grip and grommets
  • Mounting Thread:
    3/4-14 NPT
  • Housing Materials:
    Aluminum body; 304 stainless steel sleeve
  • Weight:
    1.3 kg
  • Estimated shipping dimensions:
    37 x 8.5 x 8.5 cm
  • Tariff Code:
    7307910000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Probe & Cable Fittings & Thread Mounting Geometry Product Applications

Features:

  • Probe arrangement: The 16 option specifies a 3300 XL 8 mm probe configuration.
  • Penetration: The 057 option denotes 5.7 in of probe penetration.
  • Mounting: The 02 option selects a 3/4-14 NPT thread.
Bently Nevada 21000-16-10-15-057-03-02 is a 21000 housing assembly for a 3300 XL 8 mm proximity probe.

The complete configuration includes a 1.0 m probe-cable option and the documented fittings package.

The selected penetration and minimum standoff define the installed mounting geometry.

Apter Power can quote the Bently Nevada 21000-16-10-15-057-03-02 Probe Housing Assembly and provide the housing data sheet for its 5.7 in penetration option.
Bently Nevada 21000-16-10-15-057-03-02 21000 Probe Housing Manuals,Datasheets,Link Important Notice: Accessories, manuals and cables are included only when specified in the stock-item description. Prices are shown in USD.
  • Probe option: Code 16 identifies the 3300 XL 8 mm probe configuration.
  • Cable option: Code 10 selects a 1.0 m probe cable.
  • Penetration: Code 057 selects a 5.7 in D dimension.
  • Fittings code 03: The package lists a 3/4-14 NPT plug and a 3/4-to-1/2 NPT reducer.
  • Cable sealing: The listed cable seal grip includes grommets for the documented cable ranges.
  • Mounting code 02: The housing uses a 3/4-14 NPT mounting thread.
  • Standoff C: The code specifies a minimum 1.5 in (38 mm) standoff.
  • Penetration D: This assembly specifies 5.7 in from the housing geometry.
  • Support threshold: At minimum C, C+D is 7.2 in; longer installed standoff options may change the support requirement.
  • External probe mounting: The 21000 housing positions a 3300 XL 8 mm probe at a machinery measurement point.
  • Threaded machinery ports: The specified 3/4-14 NPT thread defines the mounting interface.
  • Configured depth: The 5.7 in penetration option serves the corresponding installed probe position.
Description
For a 3300 XL 8 mm probe at a shorter machinery access point, Bently Nevada 21000-16-10-15-057-03-02 provides a 5.7 in probe-penetration option. With the specified minimum 1.5 in standoff, the combined C and D dimensions total 7.2 in.

At that minimum standoff, 21000-16-10-15-057-03-02 remains below the series drawing’s 12 in sleeve-support threshold. A longer installed standoff can change the support requirement, so the actual opening and sleeve arrangement still matter.

The 21000-16-10-15-057-03-02 code includes a 1.0 m probe-cable option, 3/4-14 NPT mounting and the specified fitting package. Apter Power can quote this exact assembly and provide the Bently Nevada series drawing for comparing the installed cable route and housing geometry.
Alternative Names
Technical notes
Bently Nevada gives the 21000 probe-penetration setting a ±0.5 in adjustment range. On this 5.7 in configuration, that adjustment is for final probe positioning rather than a substitute for selecting the correct housing depth. Apter Power can provide the series drawing to help compare the nominal ordered reach with the machine’s required sensing position.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Our case opening needs 5.7 in of probe penetration. Is 21000-16-10-15-057-03-02 the matching housing length?
Yes. The 057 penetration option is 5.7 in. The separate 15 standoff option adds 1.5 in to the housing geometry, so compare both dimensions with the installed drawing.
At its ordered standoff, does 21000-16-10-15-057-03-02 trigger the manufacturer’s over-12-in sleeve-support guidance?
The 1.5 in standoff plus 5.7 in penetration totals 7.2 in, below that specific threshold. Other machine-support needs still depend on the installation.
We are sourcing only the individual probe sleeve for 21000-16-10-15-057-03-02. Which sleeve-length code follows the manufacturer’s formula?
For the documented non-NSv, non-11 mm probe configuration, the series formula adds 015 + 057 + 045, giving 117 for the 44382 sleeve option.
Our cable seal needs to accommodate a 1/4–5/16 in cable. Does 21000-16-10-15-057-03-02 include a matching grommet range?
Yes. Its 03 fittings option lists a cable seal grip with a 1/4–5/16 in grommet range, plus the reducer and plug. Compare the actual cable outside diameter.
Does fitting hardware make 21000-16-10-15-057-03-02 a CSA-rated explosion-proof housing?
The fittings alone do not confer that rating. Bently Nevada reserves the stated CSA explosion-proof housing rating for specified CA versions; this standard 21000 code is different.
Our machine port is 1/2-14 BSP. Can 21000-16-10-15-057-03-02 thread into it directly?
This configuration uses a 3/4-14 NPT mounting thread, so it does not directly match a 1/2-14 BSP port. Apter Power can help identify the appropriate housing option.
