          Apter Power supports 24701-28-05-XX-117-03-XX MOD 323933-00-02 identification, documentation review and quotation.

        24701-28-05-XX-117-03-XX MOD 323933-00-02

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02 is a stainless-steel probe housing with a 0.5 m probe provision, 11.7 in penetration and multi-fitting package 03. Configuration-controlled XX fields must be verified from the assembly.
        In Stock
        Ships by Friday, October 30
        Fast Shipping Available
        Get a quick price for 24701-28-05-XX-117-03-XX MOD 323933-00-02
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 24701-28-05-XX-117-03-XX MOD 323933-00-02

        • Manufacturer:
          Bently Nevada
        • Part Number:
          24701-28-05-XX-117-03-XX MOD 323933-00-02
        • Product Family:
          21000, 24701, and 164818 Proximity Probe Housing A
        • Product Type:
          Stainless-Steel Proximity Probe Housing Assembly
        • Stock:
          1
        • Probe family option:
          28; 3300 XL 8 mm with selectable approval option
        • Probe cable length:
          0.5 m / 20 in
        • Probe penetration:
          11.7 in / 297.2 mm
        • Fitting package:
          03; plug, NPT reducer and cable seal grip
        • Plug thread:
          3/4-14 NPT
        • Reducer:
          3/4-14 to 1/2-14 NPT
        • Cable-seal grommet ranges:
          1/8-3/16, 1/4-5/16 and 5/16-3/8 in
        • Housing body material:
          303 stainless steel
        • Sleeve material:
          304 stainless steel
        • Standoff field:
          XX; configuration controlled
        • MOD drawing reference:
          323933-00-02
        • Long-sleeve support threshold:
          Above 304 mm / 12 in
        • Probe operating and storage temperature:
          -51 to +177 °C
        • Probe mounting style:
          Reverse mount
        • Probe connector protection:
          Not included with probe option 28
        • Probe approval configuration:
          Selectable hazardous-area approval option
        • Housing cover:
          Threaded metal dome cover
        • Conduit connection:
          Threaded housing ports
        • Housing seals:
          O-rings and thread seal included
        • Penetration adjustment range:
          13 mm / ±0.5 in
        • Probe-sleeve support accessory:
          37948-01 probe support and oil seal for long sleeves
        • Weight:
          3.968 lbs (1.8 kg)
        • Tariff Code:
          Please confirm the destination before shipping.
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Applications Temperature & Humidity Range Compliance Monitoring & Control

        Features:

        • Provides an 11.7 in penetration for machinery with a deep probe access path.
        • Includes the package 03 plug, reducer and multi-range cable sealing components.
        • Uses a 0.5 m probe allowance within the 24701 stainless-steel housing architecture.
        This configuration combines the 11.7 in penetration code with the fuller package 03 fitting set.

        It carries the probe through an extended machine-case path while preserving protected access to the probe connection.

        Sleeve support, cable reach and both unresolved XX fields must be verified against drawing 323933-00-02.

        Apter Power can review sourcing, documentation and system matching for 24701-28-05-XX-117-03-XX MOD 323933-00-02.
        Verified resources for Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Deep bearing-housing access points can use the extended sleeve to reach the defined shaft viewing location.
        • Outdoor machinery installations can route the probe cable through the supplied seal-grip hardware.
        • Maintenance programs can preserve a repeatable probe insertion distance during removal and reinstallation.
        • The installed probe must remain within the temperature range specified for the selected 3300 XL 8 mm sensing element.
        • Seal components should be inspected where condensation or washdown can enter the external cover.
        • Low-temperature installations require attention to the probe system's documented pressure-seal limitations.
        • The cable seal and reducer must be assembled with threads and grommets that match the installed conduit arrangement.
        • Sleeves approaching 12 in require a stiffness assessment, and longer sleeves require positive support.
        • Area approval is determined by the exact completed assembly rather than the base 24701 family alone.
        • The housing establishes a stable mechanical reference for measuring shaft gap and dynamic displacement.
        • Repeatable probe depth helps preserve the electrical gap when a serviced sensor is returned to the machine.
        • Cable sealing reduces contamination risks that could affect connector insulation and signal stability.
        Description
        24701-28-05-XX-117-03-XX MOD 323933-00-02 applies an 11.7 in insertion depth to the stainless-steel 24701 housing platform. The 05 selection is intended for a 0.5 m probe lead, and package 03 supplies the plug, reducer and cable-seal hardware.

        A long insertion path lets the proximity probe reach a target through thick machine housings or extended brackets. The external cover keeps the probe termination serviceable without exposing it directly to surrounding plant activity.

        Long sleeves demand careful mechanical support and alignment. Because the standoff and mounting thread are coded XX, the field assembly and MOD 323933-00-02 drawing must govern replacement selection.
        Alternative Names
        24701-28-05-XX-117-03-XX MOD 323933-00-02 Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02 24701 28 05 XX 117 03 XX MOD 323933 00 02 24701-28-05-XX-117-03-XX-MOD-323933-00-02 247012805XX11703XXMOD3239330002 24701-28-05-XX-065-03-XX MOD 323933-00-02 Bently Nevada 21000, 24701 and 164818 Proximity Probe Housing Assemblies Bently Nevada Stainless-Steel Proximity Probe Housing Assembly
        Technical notes
        Provide mechanical support for the long sleeve used with 24701-28-05-XX-117-03-XX MOD 323933-00-02 and verify both XX selections from the installed unit.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Why is the 117 penetration code important on Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02?
        It defines an 11.7 in insertion distance and therefore drives sleeve support and probe reach checks.
        Which fittings belong with Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02?
        Package 03 includes a 3/4-14 NPT plug, a 3/4-to-1/2 NPT reducer and cable-seal grip with three grommet sizes.
        What application favors Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02?
        It suits a machine case where the target must be reached through an extended probe-access path.
        Does Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02 need added sleeve support?
        Its 11.7 in penetration is close to the 12 in threshold; evaluate the full standoff and sleeve length before installation.
        How should a substitute for Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02 be screened?
        Match penetration, cable allowance, fitting package, standoff, mounting thread and MOD drawing revision.
        What should procurement photograph for Bently Nevada 24701-28-05-XX-117-03-XX MOD 323933-00-02?
        Capture the complete tag, all thread interfaces, fitting package and any 323933-00-02 drawing marking.
