The 31000-28-05-00-037-03-02 is a 31000 Series Proximity Probe Housing Assembly designed for use with 3300 XL 8 mm probes with multiple approvals.
Get a quick price for 31000-28-05-00-037-03-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 31000-28-05-00-037-03-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    31000-28-05-00-037-03-02
  • Product Family:
    31000 and 32000 Proximity Probe Housing Assemblies
  • Product Type:
    31000 Series Proximity Probe Housing Assembly
  • Compatible Probe:
    3300 XL 8 mm probe with multiple approvals
  • Probe Cable Length:
    0.5 m (20 in)
  • Standoff Adapter:
    None
  • Probe Penetration:
    3.7 in (94 mm)
  • Mounting Thread:
    3/4-14 NPT
  • Housing Material:
    Polyphenylene sulfide (PPS) thermoplastic
  • Key Benefit:
    Model 31000-28-05-00-037-03-02 eliminates the need for machine disassembly, reducing downtime and simplifying field service.
  • Weight:
    1.5 kg
  • Estimated shipping dimensions:
    37x9x8cm
  • Tariff Code:
    8479899990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Certifications Compatibility

Features:

  • Through-case mounting design with 3.7-inch probe penetration allows external gap adjustment and probe replacement without machine disassembly.
  • PPS thermoplastic housing with stainless steel components provides excellent corrosion resistance for long-term durability in harsh industrial environments.
  • Versatile cable entry options include a seal grip with three grommet sizes, a 3/4-14 NPT fitting, a stainless steel reducer, and two plugs for flexible field wiring.
The 31000-28-05-00-037-03-02 is specifically designed for applications where the probe must be mounted through the machine casing—a common requirement for radial vibration and Keyphasor measurements on large rotating equipment. Its through-case design provides external access to the probe and extension cable, allowing technicians to adjust probe gap or replace the probe entirely without disassembling the machine.

The 31000-28-05-00-037-03-02 is constructed from materials chosen for long-term reliability in harsh industrial conditions. The main housing is molded from polyphenylene sulfide (PPS), an advanced thermoplastic with excellent resistance to chemicals, moisture, and temperature extremes.

The 31000-28-05-00-037-03-02 is equipped with a comprehensive set of fittings to accommodate a variety of field installation scenarios. The included cable seal grip comes with three grommet sizes, covering the most common cable diameters encountered in industrial wiring.

The 31000-28-05-00-037-03-02 Bently Nevada English Proximity Probe Housing Assemblies may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 31000-28-05-00-037-03-02 English Proximity Probe Housing Assemblies Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 31000-28-05-00-037-03-02 English Proximity Probe Housing Assemblies Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 31000-28-05-00-037-03-02
  • Condition New Original ready stock
  • Product Family 31000-30-05-00-037-03-02,31000-31-05-00-037-03-02
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Radial Vibration Monitoring: Mounted on a fluid thin-film bearing housing, it measures the dynamic vibration of the shaft.
  • Keyphasor: Monitors the keyways on the shaft, providing speed and phase signals.
  • Typical Equipment: Key industrial equipment such as steam turbines, compressors, pumps, motors, and generators.
  • Industry Standards: Fully compliant with API 670 standards for externally mounted probe enclosures.
  • Protection Rating: The enclosure is NEMA 4X and IP66 certified, providing protection against hose jets and corrosive environments.
  • Hazardous Area Certification: The built-in probe has multi-national explosion-proof certifications (defined by code 28), and the enclosure material is CENELEC EN50014 electrostatic dissipation certified, suitable for hazardous areas.
  • Probe Compatibility: This model comes pre-installed with a 3300 XL 8 mm probe, replacing or upgrading older 7200 series probe systems.
  • System Integration: Requires the 3300 XL Proximitor sensor. Since the probe cable is 0.5 meters, a 4.5-meter or 8.5-meter extension cable is typically required to form a standard 5-meter or 9-meter system.
  • Shell Material: Constructed from glass fiber reinforced polyphenylene sulfide (PPS) and stainless steel, offering excellent chemical resistance.
Description
The 31000-28-05-00-037-03-02 is built for through-case mounting of proximity probes, allowing external access for gap adjustment and probe replacement without machine disassembly. Its 3.7-inch probe penetration provides ample reach through machine casings for radially mounted transducers used in vibration and Keyphasor measurements.

This assembly is designed to accept 3300 XL 8 mm probes with multiple approvals, making it suitable for a wide range of industrial applications. The included cable seal grip accommodates three cable size ranges (1/8 to 3/16 in, 1/4 to 5/16 in, 5/16 to 3/8 in), providing flexibility for field wiring without requiring additional adapters.

The 31000-28-05-00-037-03-02 includes a 3/4-14 NPT fitting and a stainless steel reducer to 1/2-14 NPT, allowing compatibility with a variety of conduit systems. The two plugs provide sealing options for unused ports, ensuring the housing maintains its environmental protection when not fully populated.

With its combination of corrosion-resistant materials, flexible cable entry options, and through-case mounting capability, the 31000-28-05-00-037-03-02 is particularly well-suited for radial vibration and Keyphasor measurements on steam turbines, compressors, and generators.
Alternative Names
31000-30-05-00-037-03-02 31000-31-05-00-037-03-02 31000-32-05-00-037-03-02 31000-33-05-00-037-03-02
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What types of measurements are best suited for the 31000-28-05-00-037-03-02?
This housing is ideal for radially mounted transducers used in vibration and Keyphasor measurements on steam turbines, compressors, and generators where through-case mounting is required.
How does this housing simplify maintenance?
It allows external access to the probe and extension cable, permitting gap adjustment or probe replacement without disassembling the machine—a significant time savings compared to direct mounting.
What materials are used in the 31000-28-05-00-037-03-02?
The main housing is made from PPS thermoplastic for corrosion resistance, while other components are fabricated from stainless steel for durability in demanding environments.
What cable sizes does the seal grip accommodate?
The included cable seal grip comes with grommets for three cable size ranges: 1/8 to 3/16 inches, 1/4 to 5/16 inches, and 5/16 to 3/8 inches, covering common field cable diameters.
