Bently Nevada 330171-00-08-20-02-00 is a compact non-armored 1/4-28 UNF 3300 5 mm probe with a 0.8 in case, 2.0 m lead, ClickLoc connector, and no agency approval.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 330171-00-08-20-02-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330171-00-08-20-02-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330171-00-08-20-02-00
  • Product Family:
    3300 5mm Probe
  • Product Type:
    3300 5 mm Compact Non-Armored 1/4-28 UNF Proximity Probe
  • Stock:
    1
  • Case thread:
    1/4-28 UNF
  • Cable armor:
    Without armor
  • Unthreaded length:
    0.0 in
  • Case length:
    0.8 in
  • Total probe length:
    2.0 m
  • Connector:
    Miniature coaxial ClickLoc
  • Approval option:
    No agency approval
  • Temperature range:
    -35 to 177 °C
  • Weight:
    0.323 kg
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Compact Case Cable Routing Approval Boundary

Features:

  • Compact mounting: short 0.8-inch non-armored 1/4-28 UNF case.
  • Probe lead: 2.0 m total length with a miniature ClickLoc connector.
  • Approval boundary: ordering option 00 specifies no agency approval.
Bently Nevada 330171-00-08-20-02-00 is the compact-case alternative within the 3300 5 mm proximity probe range.

Its 2.0 m lead becomes part of the matched 5 mm measurement chain used for shaft vibration, position, Keyphasor, or speed input.

Selection should prioritize available mounting depth, non-armored cable protection, total electrical length, and confirmation that no certified option is required.

Availability of Bently Nevada 330171-00-08-20-02-00 is subject to Apter Power inventory and sourcing confirmation.
Verified Apter-hosted resources for Bently Nevada 330171-00-08-20-02-00: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330171-00-08-20-02-00 3300 5 mm Probe Specs

General

  • ManufacturerBently Nevada
  • Model330171-00-08-20-02-00
  • ConditionNew Original ready stock
  • Product Family3300 5 mm Proximity Transducer System
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Mounting-space review

  • Case length: 0.8 in supports the documented compact threaded arrangement.
  • Thread: match the receiving hole to 1/4-28 UNF.
  • Torque: use 5.1 Nm as the recommendation and remain below the 7.3 Nm maximum.
  • Exit clearance: reserve space for the non-armored lead and 25.4 mm bend radius.

Non-armored lead handling

  • Abrasion control: separate the 2.0 m lead from sharp edges and moving surfaces.
  • Bend radius: keep every turn at or above 25.4 mm.
  • Strain relief: support the lead so pull force does not reach the probe or ClickLoc connector.
  • Loop match: include the 2.0 m probe length when selecting the remaining 5 mm system components.

Use of option 00

  • No agency approval: option 00 carries no hazardous-area approval marking.
  • Project screening: establish the area classification before accepting this configuration.
  • Replacement control: do not substitute it for an approved BR or other certified option.
  • Documentation: record the no-approval status with the installed probe ordering code.
Description
Designed around a short 0.8-inch threaded case, Bently Nevada 330171-00-08-20-02-00 is the compact non-armored 1/4-28 UNF probe option in the 3300 5 mm family.

The 2.0 m lead on Bently Nevada 330171-00-08-20-02-00 connects through a miniature ClickLoc interface to the matching 5 mm extension cable and Proximitor Sensor for shaft vibration or position measurement.

Because Bently Nevada 330171-00-08-20-02-00 uses approval option 00, selection should verify that no hazardous-area agency approval is required, while also checking mounting depth, electrical length, torque, and cable routing.
Alternative Names
330171 00 08 20 02 00 3301710008200200 Bently Nevada 330171-00-08-20-02-00 Baker Hughes 330171-00-08-20-02-00 Bently Nevada 330171 00 08 20 02 00 3300 5 mm compact probe 0.8 in case 330171 2 m no-approval proximity probe 5 mm ClickLoc probe 1/4-28 UNF option 00
Technical notes
Bently Nevada 330171-00-08-20-02-00 carries no agency approval, so do not use it where a certified hazardous-area option is required. Match the 2.0 m lead to the 3300 5 mm loop, preserve the 25.4 mm bend radius, and keep probe-case torque within the documented 5.1 to 7.3 Nm guidance.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
When is the short case of Bently Nevada 330171-00-08-20-02-00 useful?
The 0.8-inch case suits installations where the documented 1/4-28 UNF interface and cable-exit clearance fit the available depth.
Does Bently Nevada 330171-00-08-20-02-00 include a hazardous-area agency approval?
No. Ordering option 00 specifies no agency approval, so it must not replace an approved configuration by assumption.
How should the 2.0 m lead of Bently Nevada 330171-00-08-20-02-00 be included in system matching?
Use the documented probe length when confirming the extension cable, Proximitor Sensor, connector, and complete 5 mm electrical length.
What case torque should be used for Bently Nevada 330171-00-08-20-02-00?
Follow the documented 5.1 Nm recommendation and do not exceed the 7.3 Nm maximum probe-case torque.
How should the non-armored cable of Bently Nevada 330171-00-08-20-02-00 be routed?
Protect it from abrasion, impact, and pull force, keep bends above 25.4 mm, and avoid strain at the ClickLoc connection.
How can buyers distinguish Bently Nevada 330171-00-08-20-02-00 from the longer BR option?
Compare the complete code: this version has a 0.8-inch case, 2.0 m lead, and no agency approval.
What should be inspected if Bently Nevada 330171-00-08-20-02-00 reports an erratic signal?
Review probe gap, target condition, connector seating, cable damage, system-family match, and Proximitor calibration before changing hardware.
Which records should accompany a quotation for Bently Nevada 330171-00-08-20-02-00?
Send the installed probe code, mounting details, system component numbers, target material, required quantity, destination, and confirmation that approval is not required.
