330704-000-030-50-02-00

/ 4.9
1001 reviews | Need a Specific Revision?
The total cable length is 5.0 meters (16.4 feet), allowing flexible routing and installation across larger equipment layouts without compromising signal integrity.
Get a quick price for 330704-000-030-50-02-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330704-000-030-50-02-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330704-000-030-50-02-00
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    30 mm
  • Total Length:
    5.0 meters (16.4 feet)
  • Connector -Type:
    Miniature coaxial ClickLoc connector
  • Cable-Type:
    standard cable
  • Agency Approval:
    Not required
  • Probe Case Thread:
    M14x1.5
  • Maximum Length of Thread Engagement:
    21 mm
  • Weight:
    0.16 kg
  • Estimated shipping dimensions:
    115.5x2.5x2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China.
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Protection Features Upgrade Path

Features:

  • M14 x 1.5 metric thread with armor protection provides enhanced mechanical durability for demanding industrial installations requiring metric mounting standards.
  • 30 mm overall case length with 5.0 meter integral cable combines a compact mounting footprint with extended reach for remote monitoring applications.
  • Patented TipLoc molding and CableLoc design with 330 N pull strength ensure robust probe tip bonding and secure cable retention in high-vibration environments.
The 330704-000-030-50-02-00 packs armor protection into a 30 mm case. M14 x 1.5 threads fit metric ports, while the armor shields against impact and crushing. For tight spots where longer probes won't fit, this compact armored probe delivers 11 mm measurement capability.

Five meters of integral cable lets you place the Proximitor sensor away from the machine. No separate extension cable needed. The 330704-000-030-50-02-00 simplifies wiring in large turbine and compressor installations where the control cabinet sits remote from the measurement point.

TipLoc molding bonds the probe tip to the body—no separation under vibration. CableLoc provides 330 N pull strength, keeping the cable attached during rough pulls. The 330704-000-030-50-02-00 survives installation abuse and years of operation.

The 330704-000-030-50-02-00 Bently Nevada 3300 XL 11 mm Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330704-000-030-50-02-00 3300 XL 11 mm Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330704-000-030-50-02-00 3300 XL 11 mm Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330704-000-030-50-02-00
  • Condition New Original ready stock
  • Product Family 330704-000-030-50-01-00,330704-000-030-50-11-00,330704-000-030-50-02-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Axial (Thrust) Position Measurement: Monitoring the forward and backward displacement of the steam turbine and compressor shafts.
  • Ramp Differential Expansion: Measuring the relative thermal expansion between the steam turbine rotor and casing.
  • Reciprocating Compressor Monitoring: Used for piston rod position or rod drop measurement.
  • Phase and Speed ​​Reference: Provides keyphasor signals or is used for zero-speed monitoring.
  • Environmental Protection: IP67 protection rating; probe tip made of PPS material; housing made of AISI 304 stainless steel.
  • Sealing Protection: The probe is designed with a Viton® O-ring seal, capable of withstanding differential pressure and preventing leakage of process media.
  • Signal Integrity: Gold-plated ClickLoc™ connectors ensure a stable connection and reduce signal loss.
  • Abnormal Alarm: When used with a Proximitor sensor, it can monitor faults such as signal interruption and probe gap abnormalities (outside OK limits).
  • Replacement for the 7200 Series: This system is designed to replace older 7200 Series 11mm and 14mm sensor systems.
  • Upgrade Requirements: When upgrading from the 7200 Series, the probes, extension cables, and Proximitor sensors must be replaced simultaneously, and the monitoring instrument's configuration parameters must be updated.
Description
330704-000-030-50-02-00 is an 11 mm Proximity Probe from the 3300 XL series, designed with an M14 × 1.5 threaded body and supplied with armor, providing enhanced mechanical protection for demanding industrial environments. As a specific model within the 3300 XL 11 mm probe family, 330704-000-030-50-02-00 features clearly defined structural and performance parameters, supporting reliable integration into machinery condition monitoring systems.

From a dimensional perspective, 330704-000-030-50-02-00 has an unthreaded length of 0 mm and an overall case length of 30 mm, resulting in a compact probe profile suitable for installations with limited axial space. The total cable length is 5.0 meters (16.4 feet), allowing flexible routing and installation across larger equipment layouts without compromising signal integrity.

In terms of connectivity, 330704-000-030-50-02-00 is equipped with a miniature coaxial ClickLoc connector, ensuring a secure and stable electrical connection. The probe uses a standard cable, meeting typical industrial application requirements and supporting consistent signal transmission over the extended length.

Regarding compliance, 330704-000-030-50-02-00 does not require agency approval, offering greater flexibility for use across various industrial projects. Overall, this model combines armored mechanical protection, compact dimensions, and standardized connection features, making it suitable for long-distance installations in industrial monitoring applications.
Alternative Names
330704-000-030-50-01-00 330704-000-030-50-11-00 330704-000-030-50-12-00 330704-000-030-50-02-05
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How is product quality guaranteed?
All products are 100% brand-new and original, sourced through legitimate and traceable channels, ensuring long-term stable operation and reliability.
What is the system operating-temperature range?
0 °C to +45 °C (32 °F to 113 °F).
Maximum altitude for operation?
2 000 m.
Probe-cable type?
75 Ω triaxial, FEP-insulated.
