330704-000-100-10-01-RU

/ 4.9
1001 reviews | Need a Specific Revision?
The 330704-000-100-10-01-RU is an armored 11 mm probe with M14 x 1.5 thread, 100 mm case, 1.0 m cable, TipLoc/CableLoc, and country-specific approvals for Russia.
Get a quick price for 330704-000-100-10-01-RU
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330704-000-100-10-01-RU

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330704-000-100-10-01-RU
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Product Type:
    3300 XL 11 mm Proximity Probe
  • Thread Type:
    M14 x 1.5 (with armor)
  • Total Length:
    1.0 meter (3.3 feet)
  • Overall Case Length:
    100 mm
  • Connector:
    ClickLoc with connector protector
  • Patented Features:
    TipLoc, CableLoc (330 N pull)
  • Agency Approval:
    Country-specific (Russia)
  • Key Benefit:
    Solves armored 11 mm measurement in Russian facilities—local approvals, TipLoc/CableLoc integrity, and FluidLoc option for oil containment.
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    2.2x2x122cm
  • Tariff Code:
    8525891900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Performance Application Scenarios

Features:

  • Armored M14 x 1.5 thread with 100 mm case for deep mounting in metric ports.
  • Combines Capability of AC/DC Power Conversion with Redundant Power Support
  • Country-specific approvals for Russia eliminate local certification delays.
The 330704-000-100-10-01-RU delivers the 4.0 mm linear range of 11 mm probes with armor protection. M14 x 1.5 threads fit standard metric ports, while the 100 mm case provides balanced reach.

Country-specific approvals mean no waiting for local certification. Install the 330704-000-100-10-01-RU directly in Russian industrial plants—paperwork done at the factory.

TipLoc prevents tip separation. CableLoc provides 330 N pull strength. The locknut with safety wire holes adds positive locking. This probe stays together where others come apart.

The 330704-000-100-10-01-RU Bently Nevada 3300 XL 11 mm Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330704-000-100-10-01-RU 3300 XL 11 mm Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330704-000-100-10-01-RU 3300 XL 11 mm Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330704-000-100-10-01-RU
  • Condition New Original ready stock
  • Product Family 330704-000-100-10-02-RU,330704-000-100-10-12-RU,330704-000-100-10-01-CN
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Large steam turbines and gas turbines: Monitoring rotor differential expansion, i.e., the relative displacement between the rotor and casing caused by thermal stress.
  • Hydraulic generator sets: Monitoring radial vibration and structural displacement of large-diameter shafts.
  • Large reciprocating compressors: Used to monitor piston rod drop and diagnose support ring wear.
  • Industrial process pumps: Monitoring axial thrust position under high loads.
  • Wide linear range: Offers a 4.0 mm (160 mils) linear measurement range, twice that of the standard 8 mm probe (2.0 mm), allowing for greater machine displacement without signal loss.
  • High Sensitivity Stability: Standard sensitivity is 3.94 V/mm (100 mV/mil).
  • Signal Transmission Efficiency: Equipped with a 1.0 m (10 dm) probe cable (Option-10) using a gold-plated ClickLoc™ connector, ensuring minimal contact resistance at the connection to the extension cable, reducing signal attenuation and noise interference.
  • Thermal Expansion Monitoring: During power plant unit start-up or shutdown, monitor the rate of thermal expansion of various components to prevent excessive differential expansion from causing friction and scraping between the rotor and stator.
  • Heavy-Duty Thrust Bearing Monitoring: In equipment with heavy thrust bearing loads, monitor minute axial movement of the shaft to prevent thrust bearing damage.
  • Russian-Speaking Region Projects: With RU certification, this model is the preferred configuration for equipment exported to Eurasian Economic Union (EAEU) countries such as Russia and Kazakhstan, ensuring compliance with local metrology and safety standards.
Description
The 330704-000-100-10-01-RU brings armor protection to the 11 mm platform with M14 x 1.5 metric threads. Its 100 mm case length reaches through standard casings, while the 1.0 meter integral cable keeps wiring simple. Country-specific approvals for Russia mean no extra certification steps for local installations.

Inside this probe, TipLoc molding bonds the tip to the body—no separation under vibration. CableLoc provides 330 N pull strength, keeping the cable attached during rough pulls. The gold-plated ClickLoc connector locks with a finger turn, staying tight where others loosen.

The 330704-000-100-10-01-RU includes a locknut with pre-drilled safety wire holes for critical applications. Optional FluidLoc cable prevents oil migration through the cable interior. The connector protector seals against humidity, recommended for all installations.

This probe solves the pain point of armored 11 mm measurement in Russian industrial facilities. The 330704-000-100-10-01-RU delivers the extended linear range of 11 mm probes with armor protection, local approvals, and patented mechanical integrity features—all in a compact 100 mm package.
Alternative Names
330704-000-100-50-01-RU 330704-000-100-10-02-RU 330704-000-100-10-12-RU 330704-000-100-10-01-CN
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What thread does the 330704-000-100-10-01-RU use?
M14 x 1.5 metric thread with armor protection for robust mounting.
What approvals does this probe carry?
Country-specific approvals for Russia—no additional certification needed for local installations.
How does TipLoc help reliability?
It bonds the probe tip to the body, preventing separation under vibration and mechanical stress.
Can I add fluid protection to this probe?
Yes. Order it with the optional FluidLoc cable to block oil migration through the cable interior.
