330730-080-03-00

/ 4.9
1001 reviews | Need a Specific Revision?
The 3300 XL 11 mm extension cable 330730-080-03-00 features an armored cable construction and is equipped with a connector protector. It is designed for applications that require extended cable length without compromising signal integrity.
Get a quick price for 330730-080-03-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330730-080-03-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330730-080-03-00
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Cable Length:
    8.0 meters (26.2 feet)
  • Connector and Cable:
    Armored cable with connector protector
  • Maximum Altitude:
    2000 m
  • Power Supply Voltage:
    –24 Vdc
  • Load Resistance:
    10 kΩ
  • Target Material (Standard for Calibration):
    AISI 4140 steel
  • Weight:
    0.78 kg
  • Estimated shipping dimensions:
    29x29x3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Performance & Efficiency Temperature & Humidity Range

Features:

  • Extension Cable Component for the 3300 XL 11 mm Proximity Transducer System
  • Combines 8.0 Meter Cable Length with Armored Cable and Connector Protector Design
  • Operates in Conjunction with the 3300 XL 11 mm Probe and 3300 XL 11 mm Proximitor Sensor
The 330730-080-03-00 operates as the 8.0 meter extension cable in the 3300 XL 11 mm Proximity Transducer System, providing reliable signal transmission between the probe and Proximitor Sensor. It continuously maintains the 3.94 V/mm (100 mV/mil) output characteristic across its full 8.0 meter (26.2 feet) length, ensuring accurate non-contacting vibration and displacement measurements on fluid film bearing machines. Seamless integration is standard with the 330730-080-03-00, however using it in conjunction with the complete 3300 XL 11 mm system components will allow optimal performance in demanding industrial applications. The 330730-080-03-00 has incorporated advanced ClickLoc connector technology and gold-plated brass connectors within the 3300 XL series design.

The 330730-080-03-00 provides essential connection functions critical to the entire transducer system, and is a vital component of the measurement path, directly affecting the proper, normal operation of vibration and displacement monitoring. One 330730-080-03-00 extension cable is required per transducer channel depending on the installation distance between probe and Proximitor Sensor. The 330730-080-03-00 occupies an intermediate position in the signal chain and is always located between the probe and the Proximitor Sensor.

For applications requiring protection against oil and liquid ingress, the 330730-080-03-00 is compatible with the FluidLoc cable option. In addition to standard signal transmission, the armored cable configuration also performs environmental protection. The 330730-080-03-00 connector protector design executes safeguarding using the integrated protector specified in the cable options. Using this method, the 330730-080-03-00 continually shields the connection points. If the installation environment presents humid or moist conditions, the connector protector will automatically provide increased environmental protection and ensure reliable signal integrity throughout the measurement chain.

The 330730-080-03-00 Bently Nevada 3300 XL 11 mm Extension Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330730-080-03-00 3300 XL 11 mm Extension Cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330730-080-03-00 3300 XL 11 mm Extension Cable Specs

General

  • Manufacturer Bently Nevada
  • Model 330730-080-03-00
  • Condition New Original ready stock
  • Product Family 330730-080-03-05,330730-080-01-00,330730-040-03-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Axial (Thrust) Position Measurements: Monitoring the longitudinal movement of shafts in large turbine generators.
  • Radial Vibration and Position: Detecting shaft movement and vibration in fluid-film bearing machines.
  • Differential Expansion: Measuring the relative expansion between a steam turbine's rotor and casing.
  • Keyphasor & Speed Measurements: Providing phase reference and rotational speed data for gears or toothed wheels.
  • Reciprocating Compressors: Monitoring rod drop and rod position.
  • Extended Linear Range: Provides a standard linear range of 4.0 mm (160 mils), double that of the 8 mm system.
  • Signal Integrity: Features a 75 Ω triaxial design with a typical capacitance of 69.9 pF/m to ensure minimal signal distortion over its 8-meter length.
  • Robust Connectivity: Utilizes ClickLoc™ connectors that lock into place to prevent loosening due to machine vibration.
  • RFI/EMI Immunity: Enhanced immunity to radio frequency interference allows for installation in various housings without specialized shielding.
  • Output Sensitivity: Standard output is 3.94 V/mm (100 mV/mil) when used with the full 3300 XL 11 mm Proximity Transducer System.
  • Operating/Storage Temperature:-52°C to +177°C (-62°F to +351°F).
  • Relative Humidity:100% condensing, non-submerged (when connectors are protected).
  • Mechanical Protection:Armored jacket for physical protection; hermetically sealed case.
Description
The 3300 XL 11 mm Extension Cable, specifically the 330730-080-03-00, is a critical component within the Bently Nevada™ 3300 XL 11 mm Proximity Transducer System. This 330730-080-03-00 extension cable features a cable length of 8.0 meters (26.2 feet) and is equipped with an armored cable configuration complete with a connector protector. The 330730-080-03-00 is designed to work seamlessly with the 3300 XL 11 mm probe and the 3300 XL 11 mm Proximitor Sensor, forming a comprehensive transducer system that delivers a 3.94 V/mm (100 mV/mil) output for non-contacting vibration and displacement measurements on fluid film bearing machines.

The 330730-080-03-00 extension cable is specifically engineered to support applications where extended cable reach is necessary without compromising signal integrity. This 330730-080-03-00 is primarily utilized in axial (thrust) position measurements, where precise monitoring of rotor position is essential for preventing catastrophic machinery failures. The 330730-080-03-00 also plays a vital role in ramp differential expansion measurements on steam turbines, enabling accurate tracking of thermal growth differentials between turbine casing and rotor components. Additionally, the 330730-080-03-00 supports rod position and rod drop measurements on reciprocating compressors, providing critical data for compressor valve health monitoring and operational efficiency optimization.

The 330730-080-03-00 extension cable incorporates the advanced ClickLoc connector technology, featuring gold-plated brass connectors that lock securely into place to prevent loosening from vibration. This 330730-080-03-00 is further enhanced with the connector protector option, which provides additional environmental protection in humid or moist industrial environments. The armored cable construction of the 330730-080-03-00 ensures durability in harsh industrial settings, while the FluidLoc cable compatibility prevents oil and liquid leakage through the cable interior, making the 330730-080-03-00 ideal for demanding applications in power generation, oil and gas, and heavy industrial machinery monitoring systems.
Alternative Names
330730 080 03 00 330730-080-03-05 330730-080-03-CN 330730-080-01-00 330730-080-02-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the function of this extension cable?
The cable connects the probe to the Proximitor Sensor, ensuring reliable signal transmission across longer distances without signal degradation.
What output performance does the system provide?
The complete system delivers a precise output of 3.94 V/mm (100 mV/mil) for non-contact vibration and displacement measurements.
How does the connector protector improve performance?
The connector protector adds extra environmental protection, especially in humid or contaminated conditions, ensuring long-term reliability.
