Product overview:
- Supplied 162381 flexible 3300 XL 8 mm probe reference
- Mechanical fields 138 and 040 require nameplate interpretation
- 9.0 m total probe length with option 05 multiple approvals
162381-138-040-90-05 is a supplied legacy or special reference associated with a flexible 3300 XL 8 mm eddy-current proximity probe. The base 162381 is present in current approval references but is not defined in the current standard 3300 XL 8 mm probe ordering table.
The supplied mechanical fields are 138 and 040, and length option 90 indicates 9.0 m. These mechanical fields must not be decoded from another probe family without the original nameplate or configuration drawing.
Before quotation or replacement, confirm the complete nameplate, mechanical dimensions, sealing construction, connector, cable length, approval certificate and matching gap curve. System calibration and Proximitor compatibility must be verified as one loop.
Verified resources for Bently Nevada 162381-138-040-90-05:
Configured ordering fields:
- 162381: legacy or special flexible probe reference
- 138: supplied mechanical field A
- 040: supplied mechanical field B
- 90: 9.0 m total probe length
- 05: multiple approvals
Use the complete 162381-138-040-90-05 reference when checking the nameplate, certificate or replacement request.
Probe details:
- Flexible or special 8 mm probe construction
- Mechanical fields require original configuration data
- Total probe length: 9.0 m
These details apply to the complete 162381-138-040-90-05 configuration and should be verified against the supplied unit.
Compatibility and matching:
- Obtain the original gap curve
- Verify Proximitor Sensor calibration and full loop length
- Confirm connector and sealing construction
Do not substitute 162381-138-040-90-05 until the mechanical, electrical and approval requirements have been matched.
Installation checks:
- Measure the supplied mechanical envelope
- Inspect sealing and cable condition
- Set the probe gap only after calibration is confirmed
Record mechanical, wiring and functional verification after installing 162381-138-040-90-05.
