330101-00-43-20-02-05

/ 4.9
1001 reviews | Need a Specific Revision?
The 330101-00-43-20-02-05 is a 3300 XL 8 mm probe with 3/8-24 UNF thread, 4.3-inch case, 2.0-meter cable, CSA/ATEX/IECEx approvals, and backward compatibility with 5 mm systems.
Get a quick price for 330101-00-43-20-02-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330101-00-43-20-02-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330101-00-43-20-02-05
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    3300 XL 8 mm Proximity Probe
  • Thread Type:
    3/8-24 UNF (without armor)
  • Total Length:
    2.0 meters (6.6 feet)
  • Unthreaded Length:
    0.0 inches
  • Overall Case Length:
    4.3 inches
  • Agency Approvals:
    CSA, ATEX, IECEx
  • Compatibility:
    Backward compatible with 3300 series 5 mm/8 mm
  • Optional Feature:
    FluidLoc cable (fluid containment)
  • Key Benefit:
    Solves upgrading legacy 5 mm systems to 8 mm durability—4.3-inch case fits standard ports, 2.0-meter cable reaches remote monitors, triple approvals enable global use.
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    20x20x2cm
  • Tariff Code:
    8479899990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Firmware and Updates Installation Configuration

Features:

  • 4.3-inch case length fits standard mounting ports originally sized for 5 mm probes, enabling easy upgrades.
  • 2.0-meter integral cable provides flexible Proximitor placement without a separate extension cable.
  • CSA, ATEX, and IECEx approvals allow global hazardous area deployment without region-specific variants.
The 330101-00-43-20-02-05 replaces 5 mm probes without drilling new holes. Its 4.3-inch case matches the footprint of older probes, while the 3/8-24 UNF thread fits existing ports. Gain 8 mm durability—swap, don't re-engineer.

At 2.0 meters, the integral cable reaches remote cabinets and junction boxes. No extension cable needed. The 330101-00-43-20-02-05 simplifies wiring in large machinery where the Proximitor sensor must sit away from the probe.

CSA for North America, ATEX for Europe, IECEx for international sites. The 330101-00-43-20-02-05 moves with your equipment. No region-specific variants, no compliance delays.

The 330101-00-43-20-02-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330101-00-43-20-02-05 3300 XL 8 mm Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330101-00-43-20-02-05 3300 XL 8 mm Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330101-00-43-20-02-05
  • Condition New Original ready stock
  • Product Family 330101-00-43-20-01-05,330101-00-43-20-11-05,330101-00-43-20-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Vibration and Displacement Monitoring: Measures shaft vibration and position/displacement in hydrodynamic bearing machines (such as steam turbines, compressors, motors, and pumps).
  • Keyphasor: Provides speed measurement and phase reference signals for mechanical diagnostic analysis.
  • Industrial Applications: Widely used in harsh industrial environments requiring high-reliability monitoring, such as oil and gas, power generation, and chemical industries.
  • Passive Component Characteristics: The probe consists of an inductor coil and cable; its performance depends on its physical structure and the electrical properties of the materials.
  • System Updates: Related "updates" typically occur on the connected 3300 XL Proximitor sensor or 3500 monitoring system module. To improve monitoring capabilities, firmware updates to the backend monitoring host or replacement with a higher-performance sensor are usually required.
  • Compatibility: This series offers high interchangeability, allowing direct replacement of older 3300 series 5mm or 8mm components without recalibration.
  • Gapping Setting: It is generally recommended to set the voltage between the probe and the target axis to approximately -9 Vdc (about 1.27 mm or 50 mils) to ensure optimal linearity measurement.
  • System Connection: Requires a 3300 XL Proximitor sensor. The default calibration target material is AISI 4140 steel. If the target material is another material, coefficient compensation must be performed in the backend monitoring software.
  • Software Programming: In the 3500 architecture, configure the probe type, linear scaling factor (ISF), and alarm values ​​using the 3500 Rack Configuration Software.
Description
The 330101-00-43-20-02-05 combines a 4.3-inch case with a 2.0-meter cable, providing balanced reach for standard mounting ports. Its 3/8-24 UNF thread fits English ports, while the longer cable allows flexible Proximitor placement.

Inside this probe, the 8 mm construction delivers thicker PPS encapsulation than 5 mm alternatives. The larger body diameter resists bending and impact, maintaining accuracy where smaller probes fail.

The 330101-00-43-20-02-05 is fully backward compatible with non-XL 3300 series 5 mm and 8 mm components. Use it to upgrade existing 5 mm installations where the mounting hole accepts the larger 8 mm body. No recalibration needed—just swap and go.

This probe solves the pain point of upgrading legacy 5 mm systems to 8 mm durability without changing mounting holes. The 330101-00-43-20-02-05’s 4.3-inch case fits standard ports, while its 2.0-meter cable reaches remote monitoring equipment.
Alternative Names
330101-00-43-20-12-05 330101-00-43-20-01-05 330101-00-43-20-11-05 330101-00-43-20-02-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the overall case length of the 330101-00-43-20-02-05?
4.3 inches—fits standard mounting ports designed for 5 mm probes.
Can I use this probe to replace an existing 5 mm probe?
Yes. It is backward compatible with non-XL 3300 series 5 mm probes, provided the mounting hole accepts the larger 8 mm body.
What approvals does this probe carry?
CSA, ATEX, and IECEx—suitable for hazardous areas in North America, Europe, and international markets.
How long is the integral cable?
2.0 meters (6.6 feet)—allows remote placement of the Proximitor sensor.
