330103-00-13-05-02-05

/ 4.9
1001 reviews | Need a Specific Revision?
The 330103-00-13-05-02-05 is a 3300 XL 8 mm proximity probe featuring an M10 x 1 metric thread without armor. This model includes a 0.5 meter (1.6 feet) total length with an overall case length of 130 mm and unthreaded length of 0 mm.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330103-00-13-05-02-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330103-00-13-05-02-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330103-00-13-05-02-05
  • Product Family:
    3300 XL 8 mm Probe
  • Product Type:
    Proximity Probe
  • Stock:
    1
  • Product Type:
    3300 XL 8 mm Proximity Probe, Metric
  • Thread Type:
    M10 x 1 (without armor)
  • Total Length:
    0.5 meter (1.6 feet)
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    130 mm
  • Connector Type:
    Miniature coaxial ClickLoc™
  • Cable Type:
    Standard cable
  • Agency Approvals:
    CSA, ATEX, IECEx
  • Key Benefit:
    Solves the pain point of deep mounting in hazardous areas with a 130 mm case length and triple hazardous area approvals—reaches through thick casings while maintaining global certification.
  • Probe Case Material:
    AISI 303 or 304 stainless steel
  • Probe Cable Construction:
    75 Ω triaxial, FEP-insulated cable
  • Nominal Probe DC Resistance:
    7.45 ± 0.50 Ω
  • Case-to-Lead Tensile Strength:
    330 N (75 lbf) maximum rated
  • Recommended Probe Case Torque:
    11.2 N·m (100 in·lbf)
  • Maximum Rated Probe Case Torque:
    33.9 N·m (300 in·lbf)
  • Operating and Storage Temperature:
    -52°C to +177°C (-62°F to +350°F)
  • Incremental Scale Factor:
    7.87 V/mm (200 mV/mil) ±5%
  • Approximate Linear Region:
    0.25–2.3 mm (10–90 mils)
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    1.8x1.5x67cm
  • Tariff Code:
    8479899990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Diagnosis Installation and Upgrades

Features:

  • 130 mm overall case length provides deep reach through thick machine casings, insulation layers, or double-walled equipment without standoffs.
  • CSA, ATEX, and IECEx approvals enable global hazardous area deployment without region-specific variants.
  • 8 mm construction with thicker PPS tip encapsulation delivers superior resistance to physical abuse compared to 5 mm alternatives.
The 330103-00-13-05-02-05 is engineered for installations where the measurement point sits deep inside the machine casing. Its 130 mm overall case length allows the probe to pass through thick turbine casings, heavy compressor walls, or multiple insulation layers without requiring standoffs or custom adapters.

With CSA, ATEX, and IECEx approvals on the same probe, the 330103-00-13-05-02-05 eliminates the need to stock multiple region-specific variants. A single model can serve facilities in North America, Europe, and other regions requiring hazardous area compliance. This simplifies procurement, reduces spare parts inventory, and ensures that field crews always have the correct certified probe on hand.

The 330103-00-13-05-02-05 leverages the inherent durability advantages of the 8 mm platform, featuring thicker encapsulation of the probe coil in molded PPS plastic than 5 mm alternatives. This provides superior protection against physical abuse, making it particularly valuable in machinery where probes may be subject to accidental contact during installation or maintenance. The larger body diameter also contributes to structural rigidity, helping the probe maintain measurement accuracy in high-vibration environments.

The 330103-00-13-05-02-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330103-00-13-05-02-05 3300 XL 8 mm Proximity Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD
Bently Nevada 330103-00-13-05-02-05 3300 XL 8 mm Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330103-00-13-05-02-05
  • Condition New Original ready stock
  • Product Family 330103-00-13-05-01-05,330103-00-13-05-11-05,330103-00-13-05-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Critical Rotating Machinery Monitoring: Such as steam turbines, gas turbines, centrifugal compressors, large pumps, and fans.
  • Radial Vibration: Monitoring the dynamic vibration of the inner shaft of a bearing to assess imbalance or misalignment.
  • Axial Thrust: Monitoring the longitudinal position of the rotor to prevent major accidents caused by thrust bearing wear.
  • Gap Voltage Diagnosis: By measuring the static bias voltage output from the preamplifier, it is possible to instantly determine whether the probe is loose, damaged, or misaligned.
  • OK Circuit Monitoring: When used with the 3500 monitoring system, if the probe cable is broken or short-circuited, the system will trigger a "Not OK" alarm to prevent unplanned shutdowns caused by false alarms.
  • FluidLoc Sealing: The -02 cable in this model has a liquid-proof function to prevent machine oil from flowing into the monitoring housing along the inside of the cable.
  • Upgrade Path: Backward compatible; the 3300 XL system is fully compatible with older 3300 series (5mm and 8mm) probes and cables. Upgrading only requires replacing the proximitor for better linearity.
  • Armored Upgrade: If the installation environment poses a risk of mechanical damage (e.g., exposed cables are easily stepped on), upgrading to a model with stainless steel armor is recommended.
  • Certifications (-05 option): This version has multiple approvals, including ATEX, IECEx and NEPSI explosion-proof standards, making it suitable for long-term operation in flammable and explosive "hazardous areas".
Description
The 330103-00-13-05-02-05 combines a 130 mm overall case length with triple hazardous area approvals, making it suitable for deep mounting applications in explosive environments. Its M10 x 1 metric thread fits standard metric ports, while the 0.5-meter integral cable simplifies wiring in compact installations.

With its 130 mm case, the 330103-00-13-05-02-05 reaches through thick machine casings or insulation layers without requiring standoffs or custom adapters. This extended length is particularly valuable in large turbines, compressors, and generators where standard probe lengths are insufficient.

The 8 mm construction of the 330103-00-13-05-02-05 provides thicker encapsulation of the probe coil in molded PPS plastic than 5 mm alternatives, delivering superior resistance to physical abuse. The larger body diameter contributes to structural rigidity, helping maintain measurement accuracy in high-vibration environments.

This probe solves the pain point of deep mounting in hazardous areas by combining extended case length with global hazardous area certifications. The 330103-00-13-05-02-05 is ideal for retrofitting older equipment where the original mounting hole was sized for a 5 mm probe.
Alternative Names
330103-00-13-05-01-05 330103-00-13-05-11-05 330103-00-13-05-12-05 330103-00-13-05-02-00 330103 00 13 05 02 05 3301030013050205 Bently Nevada 3300 XL 8 mm M10 × 1 Probe Bently Nevada 0.5 m ClickLoc Proximity Probe
Technical notes
Bently Nevada 330103-00-13-05-02-05 must not be treated as a process-pressure barrier because aggressive media can erode the probe-tip assembly. Provide suitable containment wherever leakage could create a hazard.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Where does the 130 mm case length of the 330103-00-13-05-02-05 make a difference?
In deep mounting applications where standard probes cannot reach through thick turbine casings, compressor walls, or insulation layers—eliminates the need for standoffs.
Can this probe replace an existing 5 mm probe?
Yes, it is backward compatible with non-XL 3300 series 5 mm probes, provided the mounting hole diameter accommodates the larger 8 mm body.
How should the connector on Bently Nevada 330103-00-13-05-02-05 be secured?
Tighten the gold-plated ClickLoc connector by hand until it clicks. Special installation tools are not required for two matching ClickLoc connectors.
Can Bently Nevada 330103-00-13-05-02-05 operate with earlier non-XL components?
Specified non-XL 3300-series 5 mm and 8 mm components are interchangeable, but mixed assemblies are limited to the non-XL system performance specification.
Is Bently Nevada 330103-00-13-05-02-05 automatically suitable for overspeed protection?
No. Overspeed or tachometer service requires a complete application review covering target geometry, pulse behavior, mounting and the associated monitoring system.
What information should accompany an inquiry for Bently Nevada 330103-00-13-05-02-05?
Provide the complete order number, target material, required system length, existing Proximitor Sensor, mounting arrangement and hazardous-area requirements.
