Features:
- Compact mechanical construction designed for standardized installation structure.
- Stable operation within defined temperature range using miniature coaxial ClickLoc connector and standard cable interface.
- Reinforced probe and cable assembly design with TipLoc bonding, CableLoc high pull-strength structure, and optional FluidLoc leakage control.
The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe is built as part of a probe and extension cable system with a standardized mechanical configuration. The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe uses a miniature coaxial ClickLoc connector and standard cable structure to maintain consistent signal connection. It is designed for stable operation under defined environmental temperature conditions and controlled installation requirements. The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe integrates a FluidLoc option to prevent internal leakage through the cable system. The overall structure supports reliable integration between probe and extension cable components.
The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe incorporates a TipLoc molding process to strengthen the bond between probe tip and probe body. The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe cable assembly is reinforced with a CableLoc structure providing high mechanical pull strength for secure attachment. It ensures stable connection integrity between probe cable and probe tip through integrated structural design. The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe maintains consistent connector and cable configuration for standardized system compatibility. The design supports reliable mechanical assembly across probe and extension cable interfaces.
The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe is structured to ensure uniform mechanical and electrical configuration within the 3300 XL probe system. The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe supports stable installation through standardized connector and cable-type design. It maintains system-level consistency across probe and extension cable integration. The Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe is designed with reinforced structural features to ensure secure mechanical retention. The overall configuration supports reliable and repeatable system assembly performance.
The 330104-00-16-50-02-00 Bently Nevada 3300 XL 8 mm Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330104-00-16-50-02-00 3300 XL 8 mm Proximity Probe Specs
General
- Manufacturer GE / Bently Nevada
- Model 330104-00-16-50-02-00
- Condition New Original ready stock
- Product Family 330104-00-16-50-12-00,330104-00-16-05-02-00,330104-00-16-10-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Output Voltage Verification: Measure the preamplifier output using a multimeter. With a 1.27 mm (50 mils) gap, the normal voltage should be approximately -10 Vdc. If the voltage is close to 0 Vdc or the supply voltage (e.g., -24 Vdc), the probe may have a short circuit or open circuit.
- Linearity Check: Perform displacement increment testing using a graduated micrometer. Within the 2.0 mm linear range, the output voltage change should stabilize at approximately 2.0 V for every 0.25 mm (10 mils) movement (average sensitivity 7.87 V/mm).
- Connector Inspection: Check the ClickLoc connector center pin for bending or damage. Abnormal impedance at the connector is often a major cause of signal jumps or excessive noise.
- Cable Insulation Test: With the preamplifier disconnected, test the insulation resistance between the probe's center conductor and the shielding layer to ensure there are no grounding faults caused by damage.
- Coaxial Connector Locking: This model (02) comes with a small coaxial connector. Ensure the ClickLoc structure is fully locked during connection; a "click" sound is required to guarantee stable high-frequency signal transmission.
- System Total Length Matching: This model (50) comes with a 5.0-meter cable. It must be directly connected to the preamplifier; additional extension cables are strictly prohibited, as this will alter the system inductance and cause measurement errors.
- Cable Bending Radius: Minimum bending radius limits should be followed during wiring. The minimum bending radius for standard cables is 25.4 mm (1.0 in) to avoid physical damage to the coaxial layer due to excessive bending.
- Protective Conduit Use: When wiring in industrial settings, cables should be run through a stainless steel flexible conduit or tubing to prevent mechanical wear, chemical corrosion, and long-term oil penetration that can cause cable aging.
- Deep Hole Installation Measurement: With its 160 mm (16) long housing design, this model is particularly suitable for radial vibration monitoring requiring penetration through heavy machine housings or deep mounting holes.
- Bearing Shaft Displacement Monitoring: Reduced intermediate joints via a 5.0-meter straight-through cable improves signal reliability and is commonly used for precise axial displacement measurement of thrust bearings in critical units.
- Hydropower Generator Monitoring: Utilizing the high linearity of its 8 mm probe, it monitors radial runout and sway of the main shaft in large, low-speed equipment such as turbines.
- Oil-Proof Environment Applications: Leveraging its excellent pressure-sealing performance (500 psi), it is used for speed and keyphasor measurement inside gearboxes or in splash lubrication environments.
