    Apter Power specializes in the supply of premium Bently Nevada hardware, ensuring our clients receive authentic, performance-ready components for critical rotating equipment protection.

330130-040-02-CN

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 330130-040-02-CN is a 3300 XL standard extension cable with standard cable and connector protectors, ensuring full interchangeability and compliance with API 670 standards.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330130-040-02-CN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330130-040-02-CN

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330130-040-02-CN
  • Product Family:
    3300 XL Extension Cable
  • Product Type:
    3300 XL Standard Extension Cable
  • Stock:
    1
  • Cable Length Option:
    4.0 meters (11.5 feet)
  • Connector Protector and Cable Option:
    Standard cable with connector protector
  • Nominal Extension Cable DC Resistance:
    0.88 ± 0.13 Ω
  • Maximum Altitude for Specs:
    2000 meters
  • Load Resistance:
    10 kΩ
  • Weight:
    0.16 kg
  • Estimated shipping dimensions:
    21x21x1.5cm
  • Tariff Code:
    8712008900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Configuration & Programming Environmental Ratings

Features:

  • Interface Between the Proximitor Sensor and 3300 XL Monitoring System
  • Combines Capability of Signal Extension with Flexible Installation Support
  • Operates in Conjunction with the 3300 XL 8mm Proximitor Probe and Monitor
The 330130-040-02-CN operates as the Standard Extension Cable in a 3300 XL system, providing reliable signal transmission between the probe and the Proximitor Sensor. It continuously extends the electrical signal from the probe tip to the monitoring electronics while maintaining signal integrity and phase response across the full frequency range. Seamless signal continuity is standard with the 330130-040-02-CN, however using proper cable routing and grounding practices will allow optimal performance in high-RF or high-electromagnetic interference environments. The 330130-040-02-CN has made improvements in several areas over previous extension cable designs in addition to incorporating FEP-insulated coaxial cable construction within the 3300 XL system.

The 330130-040-02-CN provides essential connection functions common to the entire measurement chain, and is a critical component of the monitoring path, directly affecting the proper, normal operation of the overall vibration monitoring system. One 330130-040-02-CN extension cable is required per probe depending on the desired system configuration. The 330130-040-02-CN occupies the interconnect position between the probe and the Proximitor Sensor and is always used with matching system components (same part number series, the dedicated extension cable for 3300 XL applications).

For complete system applications, the 3300 XL system requires the 330130-040-02-CN extension cable installed between the probe and the Proximitor Sensor. In addition to standard signal extension, the 330130-040-02-CN also performs consistent electrical length compensation. The 3300 XL system executes measurement accuracy using the total electrical length specified in the probe, extension cable, and Proximitor Sensor options. Using this method, the complete system continually maintains the calibrated measurement field. If the system detects that the total electrical length is outside the specified range (outside configured tolerance levels), it will affect the linearity and accuracy of the displacement measurement and may require recalibration of the System Event List.

The 330130-040-02-CN Bently Nevada 3300 XL Standard Extension Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330130-040-02-CN 3300 XL standard extension cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330130-040-02-CN 3300 XL standard extension cable Specs

General

  • Manufacturer Bently Nevada
  • Model 330130-040-02-CN
  • Condition New Original ready stock
  • Product Family 330130-040-02-05,330130-040-02-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Vibration Measurement: Capturing dynamic radial vibration on fluid-film bearing machines.
  • Position Measurement: Monitoring static axial position or thrust.
  • Speed/Keyphasor Reference: Providing timing signals for phase and speed tracking.
  • API 670 Compliance: Used in safety-critical applications requiring full compliance with the API 670 Standard.
  • Plug-and-Play: Probes, cables, and sensors can be swapped without re-matching individual parts.
  • Connector Protectors (Option -02): This specific model includes factory-installed connector protectors to prevent contamination during installation in restrictive conduits.
  • CN Agency Approval: This configuration features country-specific approvals for use in China.
  • Operating Temperature: -51°C to +177°C (-60°F to +351°F).
  • Material Construction: 75 Ω coaxial cable with FEP (Fluoroethylene Propylene) insulation for high chemical and moisture resistance.
  • Mechanical Strength: Minimum tensile strength of 330 N (75 lbf).
  • Hazardous Area Ratings: Approved for use in Class I, Div 1 and Zone 0/1 environments when used with appropriate barriers.
Description
The Bently Nevada 330130-040-02-CN is a key component of the 3300 XL 8 mm eddy current proximity transducer system, designed to provide accurate and stable signal output proportional to the distance between the probe tip and the observed conductive surface. With a cable length option of 4.0 meters (11.5 feet) and a standard cable with connector protector, the cable ensures effective protection of the connector from environmental factors while maintaining the reliability of signal transmission. Its nominal DC resistance is 0.88 ± 0.13 Ω, delivering precise performance for static and dynamic measurements.

This extension cable fully supports the high-performance requirements of 3300 XL 8 mm systems. When paired with the standard 5-meter 3300 XL system, it complies with the American Petroleum Institute (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. The system can be applied to vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements, providing a robust solution for industrial monitoring applications.

The 330130-040-02-CN cable also reflects design improvements over previous models. Its connector protector ensures secure connections, while the cable structure supports stable and consistent signal transmission. Combined with the 3300 XL 8 mm probes and Proximitor sensors, the extension cable allows complete interchangeability, eliminating the need for individual component matching or bench calibration, which simplifies installation and maintenance.

Moreover, the 330130-040-02-CN provides excellent backward compatibility with non-XL 3300 series 5 mm and 8 mm components. This flexibility allows users to integrate the cable into systems with space constraints or mixed legacy components without compromising measurement accuracy or system performance. Its durability and precision make it suitable for demanding industrial environments.
Alternative Names
330130-040-02-00 330130-040-02-05 330130-040-02-BR 330130-040-02-RU 330130-040-01-CN 330130-040-12-CN 33013004002CN 33O13O-O4O-O2-CN
Technical notes
The 330130-040-02-CN standard extension cable is used to connect the probe to the preamplifier. The cable is 4.0 meters long and is suitable for vibration monitoring and protection applications of various rotating machinery, such as steam turbines, compressors, pumps and fans.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which load resistance is specified for 330130-040-02-CN?
The specified load resistance for Bently Nevada 330130-040-02-CN is 10 kΩ, supporting proper operation within compatible 3300 XL transducer systems.
How long is the cable on 330130-040-02-CN?
Bently Nevada 330130-040-02-CN provides a cable length of 4.0 meters (11.5 feet), making it suitable for installations requiring extended routing between system components.
Does 330130-040-02-CN have an altitude limitation?
Bently Nevada 330130-040-02-CN is specified for operation at elevations up to 2000 meters, ensuring rated performance under the documented installation conditions.
