330930-060-00-00

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 330930-060-00-00 is a 6.0-meter (19.7-foot) extension cable from the 3300 XL NSv Proximity Transducer System, designed without stainless steel armor. Featuring low DC resistance of 0.220 Ω/m (0.067 Ω/ft) and a typical capacitance of 69.9 pF/m (21.3 pF/ft), this cable is terminated with gold-plated brass ClickLoc connectors that lock securely to prevent loosening.
Get a quick price for 330930-060-00-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330930-060-00-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330930-060-00-00
  • Product Family:
    NSV Extension Cable
  • Component Type:
    Extension Cable
  • Cable Length:
    6.0 meters (19.7 feet)
  • DC Resistance:
    0.220 Ω/m (0.067 Ω/ft)
  • Capacitance:
    69.9 pF/m (21.3 pF/ft)
  • Connector Type:
    Gold-plated Brass ClickLoc Connectors
  • Recommended Accessory:
    Connector Protectors for environmental sealing
  • Agency Approval:
    Not Required
  • Weight:
    0.12 kg
  • Estimated shipping dimensions:
    23x23x2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The Bently Nevada 330930-060-00-00 is a critical link within the high-performance 3300 XL NSv Proximity Transducer System. As a standard extension cable, the 330930-060-00-00 is specified with a length of 6.0 meters (19.7 feet) and is constructed without stainless steel armor, offering a balance of flexibility and durability for typical industrial installations.

Its electrical characteristics are precisely defined, with a center conductor DC resistance of 0.220 Ω/m (0.067 Ω/ft) and a typical capacitance of 69.9 pF/m (21.3 pF/ft). A key advantage of the 330930-060-00-00 is its role in facilitating system upgrades.

 The 3300 XL NSv system, for which the 330930-060-00-00 is a core component, is designed to replace older 3300 RAM Transducer Systems and 3000-series or 7000-series 190 Transducer Systems. When upgrading from a 3300 RAM system, the existing probe and extension cable can often be retained and used with a new NSv Proximitor Sensor.

However, the 330930-060-00-00 becomes essential when upgrading from the 3000/7000-series, as the probe, cable, and sensor must all be replaced with NSv components like the 330930-060-00-00. The 330930-060-00-00 is engineered for reliability and ease of use in the field. Both ends of the cable are terminated with gold-plated brass ClickLoc connectors.

These connectors provide excellent corrosion resistance and conductivity, and their patented locking mechanism securely "clicks" into place, preventing connections from loosening due to vibration—a common cause of signal failure in rotating machinery environments.

The performance specifications for systems incorporating the 330930-060-00-00 are validated under defined reference conditions: an ambient temperature range of 0°C to +45°C (+32°F to +113°F), a maximum altitude of 2000 meters, a -24 Vdc power supply, a 10 kΩ load, and a Bently Nevada-supplied AISI 4140 steel target with a diameter of at least 31 mm (1.2 in), with the probe gapped at 1.0 mm (40 mils).

The stated system accuracy and interchangeability are guaranteed only when using components calibrated to this standard target.
Alternative Names
330930-040-00-00 330930-045-00-00 330930-060-00-00 330930-065-00-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What are the key electrical specifications and length of the 330930-060-00-00 extension cable?
The Bently Nevada 330930-060-00-00 is a 6.0-meter (19.7-foot) long extension cable. Its critical electrical parameters include a center conductor DC resistance of 0.220 Ω/m (0.067 Ω/ft) and a typical capacitance of 69.9 pF/m (21.3 pF/ft). These low values are engineered to minimize signal loss and distortion over the cable's length, ensuring accurate transmission of probe signals to the monitoring system.
How does the 330930-060-00-00 facilitate upgrades from older transducer systems, and what is its compatibility?
The 330930-060-00-00 is central to system modernization. When upgrading from a 3300 RAM system, the existing probe and cable may be reused with a new NSv Proximitor. However, for upgrades from 3000-series or 7000-series 190 systems, the probe, cable, and sensor must all be replaced with NSv components, necessitating the 330930-060-00-00. It is fully mechanically and electrically compatible and interchangeable with previous 3300 RAM extension cables, ensuring seamless integration.
What connector technology does the 330930-060-00-00 use, and what accessories are recommended for reliable operation?
The 330930-060-00-00 is terminated at both ends with gold-plated brass ClickLoc connectors. These connectors provide superior conductivity and feature a positive locking mechanism that prevents them from loosening under vibration. For maximum reliability, the use of connector protectors is strongly recommended on both connections made by the 330930-060-00-00 (probe-to-cable and cable-to-Proximitor) to provide environmental sealing against moisture, oil, and dust.
Under what reference conditions are the performance specifications for a system using the 330930-060-00-00 valid?
The performance specifications for a transducer system incorporating the 330930-060-00-00 are valid under the following reference conditions: an ambient temperature of 0°C to +45°C (+32°F to +113°F), at a maximum altitude of 2000 meters, with a -24 Vdc power supply and a 10 kΩ load. The system must use a Bently Nevada-supplied AISI 4140 steel target with a diameter of at least 31 mm (1.2 in) and the probe must be gapped at 1.0 mm (40 mils). Guaranteed accuracy and interchangeability apply only to systems calibrated to this specific target.
