Bently Nevada 330930-065-00-00
Bently Nevada 330930-065-00-00
Bently Nevada 330930-065-00-00
Bently Nevada 330930-065-00-00
Bently Nevada 330930-065-00-00
Bently Nevada 330930-065-00-00
Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail sales1@apterpower.com

330930-065-00-00

/ 4.9
1001 reviews | Need a Specific Revision?
330930-065-00-00 Facilitates flexible installation of machinery monitoring systems, meeting typical industrial application needs. It is lightweight and easy to wire as it does not have stainless steel armor.
Get a quick price for 330930-065-00-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330930-065-00-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330930-065-00-00
  • Product Family:
    NSV Extension Cable
  • Cable Length:
    6.5 meters (21.3 feet)
  • Connector and Cable:
    Without stainless steel armor
  • Agency Approval:
    Not Required
  • Probe Gap:
    1.0 mm (40 mils)
  • Target diameter:
    ≥ 31 mm (1.2 inches)
  • Target Material:
    AISI 4140 steel
  • Load Condition:
    10 kΩ
  • Weight:
    0.34 kg
  • Estimated shipping dimensions:
    29x28x2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Firmware and Updates Configuration

Features:

  • 6.5-meter stainless steel armored extension cable provides mechanical protection against crushing, abrasion, and impact damage in harsh industrial environments.
  • FEP jacket offers excellent chemical resistance to oils, solvents, and aggressive media common in process compressor applications.
  • Integrated connector protector seals the connection against moisture and contaminants, eliminating field-applied silicone tape.
The 330930-065-00-00 wraps its 6.5-meter length in stainless steel armor. Crushing, abrasion, and impact damage? The armor shrugs it off. For cables running through conduit or sharing space with power wiring, this protection keeps the signal path intact.

FEP jacket stands up to oils, solvents, and aggressive chemicals. Process compressors leak, washdowns happen, and chemical exposure is routine. The 330930-065-00-00 keeps working when standard jackets fail. No swelling, no cracking, no signal loss.

The connector protector comes pre-installed. No silicone tape, no field sealing compounds. Just plug it in and trust the factory seal. The 330930-065-00-00 eliminates a common field error and speeds up installation.

The 330930-065-00-00 Bently Nevada 3300 NSv Extension Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330930-065-00-00 3300 NSv Extension Cable Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330930-065-00-00 3300 NSv Extension Cable Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330930-065-00-00
  • Condition New Original ready stock
  • Product Family 330930-040-00-00,330930-045-00-00,330930-065-05-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Narrow Space Monitoring: The NSv probe has a narrow electromagnetic field range, specifically designed for machinery with extremely limited installation space or small shaft diameters (e.g., less than 30 mm).
  • Process Control Systems: Utilizes its powerful analog signal processing capabilities to control pressure, temperature, and flow in the pharmaceutical, food processing, or water treatment industries.
  • Small Counterbore Mounting: Suitable for applications requiring probe mounting within extremely small counterbores.
  • Compact Multi-Probe Mounting: Due to its low lateral sensitivity, probes can be mounted side-by-side with shorter distances without significant crosstalk.
  • Hardware Evolution: This cable uses ClickLoc™ gold-plated silver brass connectors with anti-loosening locking.
  • System-Level Updates: While the cable itself does not require updates, the connected 3300 XL NSv Proximitor sensors (such as the 330901) may have hardware design optimizations in different batches (such as improved RFI/EMI immunity). System upgrades typically involve replacing sensor hardware rather than cable software.
  • System Matching: During configuration, ensure the total lengths of the probe, extension cable, and Proximitor sensor are matched.
  • Hardware Connection: Utilizes proprietary CableLoc™ technology, providing 220 N tensile strength to ensure a secure connection.
  • Connector Protection: It is strongly recommended to use connector sleeves or dedicated silicone tape at cable connections to prevent liquid ingress that could affect electrical signals.
  • Material Calibration: The sensor system is calibrated by default for AISI 4140 steel. If the target material is another material, specify the MOD code when purchasing the sensor for specific material calibration.
Description
The 330930-065-00-00 is a 3300 NSv Extension Cable designed to extend the connection between 3300 XL Proximity Probes and Proximitor Sensors, enabling flexible installation in machinery monitoring systems.

The cable length of the 330930-065-00-00 is 6.5 meters (21.3 feet), providing ample reach for typical industrial setups.

This extension cable comes without stainless steel armor, making it lightweight and easy to route.

No agency approval is required for the 330930-065-00-00 making it suitable for general industrial applications where certification is not mandatory.

Alternative Names
330930 065 00 00 330930-065-00-05 330930-065-01-00 330930-065-02-00 330930-060-00-00
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What protection do connector protectors provide?
Connector protectors help prevent most liquids from entering the ClickLoc connectors, protecting signal integrity and improving overall system reliability.
How does Our Company handle issues during the warranty period?
During the warranty period, if a product issue is confirmed to meet warranty conditions, Our Company will provide a replacement or return solution based on the specific situation. The process is customer-oriented, transparent, and ensures problems are resolved efficiently.
What payment methods does Our Company accept?
Our Company currently accepts T/T (bank wire transfer). For in-stock items, payment is usually completed before shipment to ensure smooth order processing, inventory allocation, and logistics arrangement.
