330908-39-71-05-01-00

/ 4.9
1001 reviews | Need a Specific Revision?
The Model 330908-39-71-05-01-00 is a 3300 NSv proximity probe featuring 3/8-24 UNF mounting threads without armor, designed for tight installation clearances in centrifugal air compressors, refrigeration compressors, and process gas applications.
Get a quick price for 330908-39-71-05-01-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330908-39-71-05-01-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330908-39-71-05-01-00
  • Product Family:
    NSV Probe
  • Probe Type:
    3300 NSv Proximity Probe
  • Mounting Thread:
    3/8-24 UNF
  • Total Length:
    0.5 meter (20 inches)
  • Unthreaded Length:
    3.9 in (99 mm)
  • Overall Case Length:
    7.1 in (180 mm)
  • Connector Type:
    Miniature coaxial ClickLoc
  • Connector Protection:
    Pre-installed connector protector
  • Cable Type:
    Standard cable
  • Agency Approvals:
    Not required
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    1.5x1.3x66.5cm
  • Tariff Code:
    8525891900
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications

Features:

  • Interfaces 3300 XL NSv Proximity Transducer System with proximitor for non-contact shaft vibration/displacement measurement.
  • Combines eddy current sensing with rugged design for precise static/dynamic position detection.
  • Operates with 3500 monitors to provide reliable vibration and keyphasor protection.
The 3300 NSv Proximity Probe 330908-39-71-05-01-00 operates as the sensing element in a 3300 NSv proximity transducer system, providing precise measurement of static and dynamic positions relative to conductive surfaces. It continuously generates an electromagnetic field at the probe tip, and as a target moves relative to this field, eddy current losses modulate an oscillator signal, which is converted by a proximitor to a voltage proportional to displacement. Seamless integration with the 3300 NSv system is standard with the 330908-39-71-05-01-00, allowing direct replacement in existing installations while maintaining compatibility with 3300 and 3500 series monitoring systems. The 330908-39-71-05-01-00 has made improvements in mechanical ruggedness and environmental sealing over previous probe designs while incorporating the established NSv form factor for consistent, reliable performance.

The 330908-39-71-05-01-00 provides essential sensing functions critical to machinery protection, directly affecting the accuracy and reliability of vibration and position monitoring. It features a standard 5-meter probe length, 3/8-24 UNF thread size, and Reverse Mounting configuration, requiring only a single installation point per measurement channel depending on the monitoring requirements.

For applications requiring extended temperature range or resistance to harsh environments, the 3300 NSv probe incorporates advanced materials and sealing techniques to ensure continuous operation. In addition to standard mounting configurations, the reverse mount design allows for simplified installation from the machine interior. Using this method, the probe body remains securely fixed while the sensitive tip region maintains accurate proximity measurement, ensuring uninterrupted machinery protection data even under varying operational conditions.

The 330908-39-71-05-01-00 Bently Nevada  3300 NSv Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330908-39-71-05-01-00 3300 NSv Probe Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330908-39-71-05-01-00 3300 NSv Probe Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330908-39-71-05-01-00
  • Condition New Original ready stock
  • Product Family 330908-39-71-05-02-00,330908-39-71-05-01-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Description
The Model 330908-39-71-05-01-00 is a specialized 3300 NSv proximity probe engineered for applications with demanding space constraints and chemical exposure. This non-armored configuration features standard 3/8-24 UNF mounting threads and an extended unthreaded length of 3.9 inches, with an overall case length of 7.1 inches.

Chemical resistance is a significant advancement in the 330908-39-71-05-01-00 compared to previous probe generations. This NSv probe offers increased chemical resistance relative to the earlier 3300 RAM probe, enabling reliable operation in many process compressor applications where exposure to aggressive media is a concern.

The connector system on the 330908-39-71-05-01-00 features a miniature coaxial ClickLoc connector with gold-plated brass contacts, ensuring reliable signal transmission and corrosion resistance. This model includes a pre-installed connector protector, which is recommended for all installations to provide increased environmental protection against moisture, contaminants, and mechanical damage.

System compatibility is a key feature of the 330908-39-71-05-01-00, which is mechanically and electrically compatible and interchangeable with Bently Nevada's previous 3300 RAM proximity probe and extension cable systems. This backward compatibility allows the 330908-39-71-05-01-00 to be seamlessly integrated into existing monitoring installations without requiring system redesign.
Alternative Names
330908-39-71-05-11-00 330908-39-71-05-02-00 330908-39-71-05-12-00 330908-39-71-05-01-05
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What are the key dimensional specifications for the 330908-39-71-05-01-00 probe?
The 330908-39-71-05-01-00 features 3/8-24 UNF mounting threads, an unthreaded length of 3.9 inches (99 mm), and an overall case length of 7.1 inches (180 mm). The total length of the probe assembly, including the integral cable, is 0.5 meter (20 inches), terminated with a miniature coaxial ClickLoc connector and pre-installed connector protector.
What applications are specifically suited for the 330908-39-71-05-01-00?
The 330908-39-71-05-01-00 is specifically intended for use with centrifugal air compressors, refrigeration compressors, process gas compressors, and other machines with tight installation requirements. Its extended unthreaded length and superior side-view characteristics make it ideal for applications where clearance is limited and previous probe designs cannot be accommodated.
How does the 330908-39-71-05-01-00 compare chemically and mechanically to previous probe models?
The 330908-39-71-05-01-00 offers increased chemical resistance compared to Bently Nevada's previous 3300 RAM probe, allowing its use in many process compressor applications with aggressive media exposure. The side-view characteristics are superior to those of the 3000-series 190 probe when gapping the 330908-39-71-05-01-00 at the same distance from the probe target. Additionally, it is mechanically and electrically compatible and interchangeable with 3300 RAM probe systems.
What connector features are included on the 330908-39-71-05-01-00?
The 330908-39-71-05-01-00 features a miniature coaxial ClickLoc connector with gold-plated brass contacts for reliable signal transmission and corrosion resistance. The model includes a pre-installed connector protector, which is recommended for all installations to provide increased environmental protection against moisture, contaminants, and mechanical damage. The ClickLoc design enables tool-free installation while maintaining a secure, vibration-resistant connection.
