Bently Nevada 330910-00-09-10-01-00
Bently Nevada 330910-00-09-10-01-00
Bently Nevada 330910-00-09-10-01-00
Bently Nevada 330910-00-09-10-01-00
Bently Nevada 330910-00-09-10-01-00
Bently Nevada 330910-00-09-10-01-00
Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail sales1@apterpower.com

330910-00-09-10-01-00

/ 4.9
1001 reviews | Need a Specific Revision?
The 330910-00-09-10-01-00 is an M10 x 1 armored NSv probe with 90 mm case, 1.0 meter cable, increased chemical resistance, superior side-view characteristics, and gold-plated ClickLoc connectors for process compressor applications.
Get a quick price for 330910-00-09-10-01-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330910-00-09-10-01-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330910-00-09-10-01-00
  • Product Family:
    NSV Probe
  • Product Type:
    3300 NSv Proximity Probe, Metric
  • Thread Type:
    M10 x 1 (with armor)
  • Total Length:
    1.0 meter (39 inches)
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    90 mm
  • Connector Type:
    Miniature coaxial ClickLoc™ with connector protector
  • Connector Material:
    Gold-plated brass
  • Cable Type:
    Standard cable
  • Agency Approval:
    Not required
  • Key Benefit:
    Upgrades legacy 3300 RAM installations with a drop-in armored probe that delivers better chemical resistance and side-view accuracy—no new cabling needed.
  • Weight:
    0.08 kg
  • Estimated shipping dimensions:
    3x1.7x2cm
  • Tariff Code:
    8479899990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Performance and Efficiency Application Scenarios

Features:

  • Armored M10 x 1 metric thread with 90 mm case provides mechanical protection and standard metric mounting for process compressor installations.
  • Increased chemical resistance compared to 3300 RAM probes enables reliable operation in environments with oils, solvents, and aggressive media.
  • Superior side-view characteristics deliver accurate readings when perfect perpendicular alignment isn't possible—common in tight compressor casings.
The 330910-00-09-10-01-00 is designed to slide into existing 3300 RAM installations without rework. Its M10 x 1 thread matches metric ports already in place, and its electrical characteristics align with legacy systems so that swapping the Proximitor sensor is the only change required to gain NSv performance. The 1.0 meter integral cable keeps wiring tidy, and the gold-plated ClickLoc connector locks with a finger turn—no tools needed.

The armor on the 330910-00-09-10-01-00 is not just for show. It protects the probe during the rough handling that comes with installation in tight compressor skids, where cables share conduit with power wiring and are subject to pulls and bends that would damage unprotected cables. The armor also guards against accidental impacts during maintenance, keeping the probe intact when tools slip or panels are moved.

Process compressors expose probes to a cocktail of lubricating oils, solvents, and aggressive media that can degrade standard materials. The 330910-00-09-10-01-00 uses the NSv platform's increased chemical resistance to stand up to these conditions, maintaining accuracy and structural integrity where other probes fail.

The 330910-00-09-10-01-00 Bently Nevada 3300 NSv Proximity Probes may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330910-00-09-10-01-00 3300 NSv Proximity Probese Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330910-00-09-10-01-00 3300 NSv Proximity Probes Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330910-00-09-10-01-00
  • Condition New Original ready stock
  • Product Family 330910-00-09-10-02-00,330910-00-09-10-12-00,330910-00-09-10-01-05
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Small, high-speed machinery: such as small centrifugal compressors, expanders, and integrally geared compressors.
  • Narrow measurement area monitoring: When the target area width on the shaft is less than 9.5 mm (0.375 in), the 3300 NSv is the only option that can provide an accurate signal.
  • Embedded mounting: Due to its small probe head, it is suitable for installation in extremely narrow spaces inside the bearing housing.
  • Linear Range: The standard range is 1.5 mm (60 mils), starting approximately 0.25 mm (10 mils) from the probe.
  • High Sensitivity (Scale Factor): The standard scale factor is 7.87 V/mm (200 mV/mil), enabling precise detection of extremely small axial vibrations.
  • Low Cross-Interference: Compared to the standard probe, the NSv design significantly reduces sensitivity to lateral metal objects, greatly improving measurement efficiency and accuracy when installed in narrow housings.
  • Radial Vibration Monitoring: Arranged X-Y (90 degrees) on the bearing housing to observe the shaft orbit of small rotors, diagnosing imbalance, misalignment, or fluid eddy currents.
  • Thrust/Axial Position Monitoring: Monitors the axial movement of small turbine rotors to prevent rotor collisions caused by thrust bearing failure.
  • Speed/Phase Monitoring: Utilizes small slots or protrusions on the shaft to generate pulse signals as a keyphasor reference, providing accurate speed data and vibration phase analysis.
Description
The 330910-00-09-10-01-00 brings together M10 x 1 metric threading and armor protection in a 90 mm case, giving field crews a durable option for process compressor monitoring. Its gold-plated ClickLoc connector locks with a finger turn, staying tight under vibration without tools.

Inside the 330910-00-09-10-01-00, the NSv platform delivers two practical improvements over legacy 3300 RAM probes. Chemical resistance steps up to handle the solvents, oils, and aggressive media common in compressor applications.

This probe slides into existing 3300 RAM installations without a hitch—it's mechanically and electrically interchangeable, so swapping the Proximitor sensor is all it takes to gain NSv performance. The 1.0 meter integral cable keeps wiring tidy, eliminating the need for an extension cable in many setups.

The 330910-00-09-10-01-00 solves the problem of upgrading legacy systems without ripping everything out. Keep the existing cabling in place, replace the probe with this armored NSv version, and get the chemical resistance and side-view accuracy that matter in process compressors.
Alternative Names
330910-00-09-10-02-00 330910-00-09-10-12-00 330910-00-09-10-11-00 330910-00-09-10-01-05
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What makes the 330910-00-09-10-01-00 a drop-in replacement for 3300 RAM probes?
It's mechanically and electrically interchangeable with 3300 RAM designs, so you can swap the probe without changing existing cabling or mounting holes.
How does the side-view improvement help in real installations?
It gives you accurate readings even when the probe can't be perfectly perpendicular to the target—common in tight compressor casings where alignment is compromised.
What does the armor protect against?
It shields the probe from crushing, abrasion, and impact damage during installation and maintenance—especially valuable when cables share conduit with other wiring.
Why would I choose this over a non-armored version?
For process compressors where cables are exposed to rough handling, conduit pulls, or accidental impacts—the armor adds a layer of durability without changing electrical performance.
