        21504-000-024-10-02

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The 21504-000-024-10-02 is a 7200 Series 8 mm proximity probe featuring standard tip construction with 3/8-24 UNF threads. This model is designed for non-contacting shaft position and vibration measurements on rotating machinery.
        Get a quick price for 21504-000-024-10-02
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 21504-000-024-10-02

        • Manufacturer:
          Bently Nevada
        • Part Number:
          21504-000-024-10-02
        • Product Family:
          7200 Proximity Transducer Systems
        • Product Type:
          7200 Series 8 mm Proximity Probe
        • Thread Type:
          3/8-24 UNF
        • Tip Construction:
          Standard
        • Probe Material:
          Polyphenylene sulfide (PPS)
        • Linear Range:
          80 mils (2.0 mm)
        • Scale Factor:
          200 mV/mil (7.87 V/mm) ±4% (system calibrated)
        • Frequency Response:
          0 to 10 kHz (0 to 600,000 cpm)
        • Operating Temperature (Probe):
          -30°F to +350°F (-34°C to +177°C)
        • Standard Compliance:
          API 670
        • Key Benefit:
          Model 21504-000-024-10-02 provides 80 mils linear range with 200 mV/mil scale factor for precise vibration and position measurements.
        • Weight:
          0.05 kg
        • Estimated shipping dimensions:
          1.6x1.3x69cm
        • Tariff Code:
          8479899990
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Application Diagnosis and Protection Installation

        Features:

        • The 21504-000-024-10-02 features 8 mm probe tip diameter with 3/8-24 UNF threads for standard English mounting applications.
        • This model includes patented CableLoc technology that secures the coaxial cable to the probe tip for superior durability during installation and operation.
        • The 21504-000-024-10-02 is constructed of polyphenylene sulfide (PPS) for excellent chemical resistance in harsh industrial environments.
        The 21504-000-024-10-02 provides essential measurement functions common to the 7200 system, and is a critical component directly affecting the accuracy of machinery protection and condition monitoring. It incorporates Bently Nevada's CableLoc technology, which provides the strongest junction between the coaxial cable and probe tip, increasing durability during installation and usage. The 21504-000-024-10-02 is constructed of polyphenylene sulfide (PPS), a high-performance plastic capable of withstanding harsh, wet, and chemical environments.

        For applications requiring precise vibration and position measurement, the 21504-000-024-10-02 supports measurements such as radial vibration, axial thrust position, shaft average radial position, vibration amplitude and phase angle, and eccentricity. Its PPS construction provides excellent corrosion resistance to air, water, lube oil, ammonium hydroxide, sulfuric acid, MEK, and DMF. The 21504-000-024-10-02 operates reliably across a wide temperature range, making it suitable for demanding industrial environments.

        The 21504-000-024-10-02 solves the critical pain point of reliable shaft monitoring in harsh industrial environments through its rugged PPS construction and CableLoc technology. This probe is designed for use with virtually any machine type and is fully compatible with API 670 requirements. The 21504-000-024-10-02 ensures accurate, repeatable measurements for predictive maintenance and machinery protection in power generation, oil and gas, and manufacturing industries.

        The 21504-000-024-10-02 Bently Nevada 7200 Series 8 mm Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

        Bently Nevada 21504-000-024-10-02 7200 Series 8 mm Proximity Probe Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        Bently Nevada 21504-000-024-10-02 7200 Series 8 mm Proximity Probe Specs

        General

        • Manufacturer GE / Bently Nevada
        • Model 21504-000-024-10-02
        • Condition New Original ready stock
        • Product Family 21505-000-024-10-02,22810-000-024-10-02,22811-000-024-10-02
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Small high-speed rotating machinery: Vibration and displacement monitoring of small centrifugal compressors, boosters, and high-speed pumps.
        • Bearing housing internal monitoring: Suitable for rolling bearings or small sliding bearing housings with extremely limited physical space.
        • Laboratory and test benches: Measuring minute clearance changes or analyzing shaft trajectories in precision R&D equipment.
        • Not OK Status Diagnosis: The system continuously monitors the electrical integrity of the circuit. If the probe coil is damaged, the cable is broken, or the connector is loose, the preamplifier will output an abnormal voltage signal, triggering the "Not OK" indicator on the monitoring system, thereby disabling alarms and preventing false trips due to sensor failure.
        • Gap Voltage Misalignment Monitoring: By observing the static voltage (usually installed at -10V DC), technicians can diagnose whether the bearings are excessively worn or whether the probe is loose or displaced.
        • Anti-interference protection: It has excellent electromagnetic shielding performance, which can effectively filter out electronic noise generated by motors or frequency converters, ensuring that the signal transmitted to the protection system is clean.
        • Gap Alignment: During installation, rotate the probe to adjust the distance from the shaft until the preamplifier output voltage reaches the center of the linear region (usually -10V).
        • Tightening and Preventing Loosening: 1/4-28 threads are fine; strictly adhere to the recommended torque during installation to prevent thread stripping due to overtightening. It is recommended to use a self-locking nut to prevent loosening during operation.
        • Connector Protection: When connecting extension cables, it is recommended to use a connector protector or silicone tape to prevent corrosive liquids or oil from seeping into the connector.
        View as PDF
        Description
        The 21504-000-024-10-02 operates as a non-contacting eddy current proximity probe within the Bently Nevada 7200 Proximity Transducer System, measuring static and dynamic distances between the probe tip and the observed target. It features standard tip construction with 3/8-24 UNF threads, constructed of polyphenylene sulfide (PPS), a high-performance plastic capable of withstanding harsh, wet, and chemical environments.

        The 21504-000-024-10-02 provides essential measurement functions common to the 7200 system, and is a critical component directly affecting the accuracy of machinery protection and condition monitoring. It incorporates Bently Nevada's CableLoc feature, which secures the coaxial cable to the probe tip, providing the strongest junction yet offered and increasing durability during installation and usage.

        For applications requiring precise vibration and position measurement, the 21504-000-024-10-02 supports a frequency response of 0 Hz DC to 10 kHz, enabling radial vibration, axial thrust position, shaft average radial position, vibration amplitude and phase angle, and eccentricity measurements. The probe is constructed of PPS, providing excellent corrosion resistance to air, water, lube oil, ammonium hydroxide, 10% sulfuric acid, MEK, and DMF.

        The 21504-000-024-10-02 solves the critical pain point of reliable shaft monitoring in harsh industrial environments through its rugged PPS construction and CableLoc technology. This probe is designed for use with virtually any machine type and is fully compatible with API 670 requirements.
        Alternative Names
        21505-000-024-10-02 22810-000-024-10-02 22811-000-024-10-02
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What types of measurements can the 21504-000-024-10-02 perform?
        It performs radial vibration, axial thrust position, shaft average radial position, vibration amplitude and phase angle, and eccentricity measurements with frequency response from DC to 10 kHz.
        What is the CableLoc feature on the 21504-000-024-10-02?
        CableLoc is a patented technology that secures the coaxial cable to the probe tip, providing the strongest junction available and increasing durability during installation and usage.
        What is the linear range and scale factor of the 21504-000-024-10-02?
        The probe offers 80 mils (2.0 mm) linear range with a scale factor of 200 mV/mil (7.87 V/mm), with linearity within 0.8 mils when calibrated as a system.
        What is the operating temperature range for the 21504-000-024-10-02?
        The probe operates from -30°F to +350°F (-34°C to +177°C), making it suitable for high-temperature applications such as gas and steam turbines.
