The Bently Nevada 21504-32-56-10-02 Standard Mount Proximity Probe is designed for the precise measurement of vibration and displacement in rotating machinery.
Get a quick price for 21504-32-56-10-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 21504-32-56-10-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    21504-32-56-10-02
  • Product Family:
    7200 Proximity Transducer Systems
  • Output Resistance:
    50 Ω
  • Probe Case Material:
    AISI 304 stainless steel
  • Maximum Torque:
    0.56 N•m (5 in•lb)
  • Minimum Bend Radius:
    25.4 mm (1 inch)
  • Operating Temperature:
    -52°C to +100°C (-62°F to +212°F)
  • Storage Temperature:
    -52°C to +105°C (-62°F to +221°F)
  • Operating Frequency:
    0 to 10 kHz
  • Signal Output:
    4-20 mA, proportional to displacement
  • Power Supply:
    24 Vdc
  • Weight:
    0.05 kg
  • Estimated shipping dimensions:
    1.5x1.3x119cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Protection Functions Installation and Upgrades

Features:

  • 8 mm probe diameter with 3/8-24 UNF threads and extended case length provides standard English mounting compatibility with deeper reach for thicker machine casings.
  • PPS (polyphenylene sulfide) tip material with thicker coil encapsulation offers excellent chemical resistance and superior durability against physical abuse compared to 5 mm alternatives.
  • Integral cable design with custom length configuration simplifies installation by eliminating the need for separate extension cables in many applications.
The 21504-32-56-10-02 is designed for installations where the measurement target sits deeper inside the machine casing than standard probes can reach. Its extended case length allows the probe to pass through thicker turbine casings, heavy compressor walls, or multiple insulation layers without requiring standoffs or custom mounting hardware.

The 21504-32-56-10-02 is constructed with a PPS (polyphenylene sulfide) probe tip, a material chosen for its exceptional resistance to a wide range of industrial chemicals. This makes the probe particularly suitable for applications where exposure to lubricating oils, hydraulic fluids, solvents, or corrosive agents is routine—common in process compressors, chemical plants, and offshore facilities.

The 21504-32-56-10-02 features an integral cable designed to match specific installation requirements, eliminating the need for a separate extension cable in many applications. This reduces the number of connections and potential failure points in the monitoring path, while simplifying parts management.

The 21504-32-56-10-02 Bently Nevada Mount Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 21504-32-56-10-02 Mount Proximity Probe Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 21504-32-56-10-02 Mount Proximity Probe Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 21504-32-56-10-02
  • Condition New Original ready stock
  • Product Family 21504-32-56-05-02,21504-32-56-15-02,21504-32-56-10-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Radial Vibration Monitoring: Measures dynamic oscillations within journal bearings to determine imbalances or misalignments.
  • Axial Displacement Monitoring: Monitors the condition of thrust bearings to prevent mechanical collisions between the rotor and stator.
  • Speed ​​and Phase Measurement: Provides synchronization signals as a keyphasor sensor.
  • Typical Equipment: Steam turbines, compressors, industrial fans, pumps, generators, and centrifuges.
  • Gap Voltage Monitoring: Ensures the probe is centered in the linear range by measuring the gap voltage (typically set between -9V and -11V DC).
  • OK Circuit Diagnosis: The system automatically detects open or short circuits in the cable. If the signal is out of range (e.g., greater than -17.5Vdc or less than -2Vdc), a "Not OK" signal is triggered to prevent erroneous protection actions due to sensor failure.
  • Environmental Resistance: Possesses excellent chemical resistance, withstanding corrosion from 10% sulfuric acid and MEK solvent, and operates stably at extreme temperatures ranging from -34°C to +177°C.
  • Installation Requirements: Use 3/8-24 UNF standard threads for installation. Strictly adhere to the linear range specified in API 670 (approximately 2.0 mm / 80 mils) during installation.
  • Full Interchangeability: The 7200 series system (probe, extension cable, preamplifier) ​​is fully interchangeable; no on-site recalibration is required when replacing components.
  • 3300 XL Upgrade: While the 7200 series offers excellent performance, Bently Nevada's current flagship product is the 3300 XL series. These two series are generally interchangeable, but it is strongly recommended to avoid mixing components from different brands (i.e., the so-called "Frankenstein System") to prevent reading errors.
Description
The Bently Nevada 21504-32-56-10-02 Standard Mount Proximity Probe is designed for the precise measurement of vibration and displacement in rotating machinery. It provides high accuracy and reliability for continuous monitoring of machine health, particularly in applications where early detection of misalignment, imbalance, or other mechanical issues is critical.

Constructed from durable materials and designed to withstand harsh environments, this probe is ideal for use in power plants, manufacturing facilities, and other industrial applications.

The 21504-32-56-10-02 proximity probe offers exceptional performance, including robust signal output and the ability to function in extreme temperature and humidity conditions. The probe is compatible with a variety of measurement systems, providing valuable real-time data to optimize maintenance and reduce unplanned downtime.

The Bently Nevada 21504‑32‑56‑10‑02 is a standard mount proximity vibration probe engineered for precision monitoring of shaft movement and vibration on rotating machinery.
Alternative Names
2I5O4-32-56-10-02 2I5O4-32-56-10-02 2I5O4-32-56-I0-02 2I5O4-32-56-IO-O2
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the output resistance of the Bently Nevada 21504-32-56-10-02 Standard Mount Proximity Probe?
The output resistance of this proximity probe is 50 Ω, ensuring compatibility with most monitoring and measurement systems.
What is the construction material of the probe case?
The probe case is made from AISI 304 stainless steel, providing durability and corrosion resistance, ideal for harsh industrial environments.
What is the maximum torque this proximity probe can handle?
The maximum torque for this probe is 0.56 N•m (5 in•lb), ensuring secure installation while preventing damage during setup.
