Bently Nevada 22811-00-04-10-02 is a compact 7200 8 mm M10 × 1 proximity probe with a 40 mm case, no integral-lead armor, a 1.0 m cable and miniature male coaxial connector.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 22811-00-04-10-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 22811-00-04-10-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    22811-00-04-10-02
  • Product Family:
    7200 Proximity Transducer Systems
  • Product Type:
    8 mm Standard Mount Probe
  • Stock:
    1
  • Case thread:
    M10 × 1
  • Overall case length:
    40 mm
  • Unthreaded length:
    0 mm
  • Integral cable length:
    1.0 m
  • Lead armor:
    Without lead armor
  • Connector:
    Miniature male coaxial
  • Weight:
    0.06 kg
  • Estimated shipping dimensions:
    1.8x1.5x96cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Short M10 Case Unarmored Lead System Chain Product Applications

Features:

  • Short M10 case: The 04 option specifies 40 mm overall length.
  • Unarmored lead: The 22811 family omits stainless-steel cable armor.
  • One-metre connection: The 10 option supplies a 1.0 m integral coaxial lead.
The probe combines a compact M10 × 1 case with 0 mm unthreaded length.

A miniature male coaxial connector joins the lead to the planned 7200 extension cable.

The 8 mm tip is the sensing element of a 7200 system completed by a Proximitor.

Apter Power can provide technical documentation, a quotation and 7200 configuration support for the Bently Nevada 22811-00-04-10-02 8 mm Standard Mount Probe.
Bently Nevada 22811-00-04-10-02 8 mm Standard Mount Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Case length: The 04 metric option is 40 mm overall.
  • Thread: The standard 22811 case uses M10 × 1.
  • Unthreaded section: The 00 option specifies 0 mm.
  • Tip size: The probe uses the standard 8 mm sensing face.
  • Lead length: The 10 option gives 1.0 m of integral cable.
  • Armor: The 22811 family has no stainless-steel lead armor.
  • Connection: The 02 option terminates in miniature male coax.
  • Tip junction: Improved 8 mm 7200 probes include Cable LoC.
  • Probe position: The 8 mm tip senses gap to the observed surface.
  • Extension: A 4.0 m cable combines with the 1.0 m integral lead.
  • Five-metre unit: The 18745-03 Proximitor is specified for that total length.
  • Monitor interface: The Proximitor conditions the signal for display.
  • Radial vibration: The complete 7200 system can observe shaft motion.
  • Axial thrust: The assembled loop can indicate shaft thrust position.
  • Eccentricity: The system can measure rotor bow.
  • Diagnostic phase: The full 7200 system supports phase-angle measurement.
Description
For a short metric probe mount, 22811-00-04-10-02 provides an 8 mm standard tip in a 40 mm M10 × 1 case. The 22811 family has no stainless-steel armor on its integral lead.

The 00 unthreaded-length option is 0 mm. A 1.0 m integral coaxial cable with a miniature male connector extends from 22811-00-04-10-02, so routing and mechanical protection depend on the installed cable path.

In the assembled 7200 transducer system, 22811-00-04-10-02 is the probe component. An extension cable and Proximitor provide the specified total length and conditioned signal needed for machine shaft monitoring.
Alternative Names
Bently Nevada 22811-00-04-10-02 22811 00 04 10 02 22811/00/04/10/02 2281100041002 22811-00-04-10-02 7200 probe
Technical notes
The 40 mm M10 × 1 case makes 22811-00-04-10-02 shorter than the 60 mm and 100 mm case options, but its 1.0 m integral lead is unchanged. The 22811 family is unarmored, so a route exposed to mechanical abuse needs protection outside this probe assembly. Case length, lead length and armor are separate installation decisions.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Will 22811-00-04-10-02 suit an M10 × 1 location with room for only a 40 mm probe case?
Yes. Its metric thread is M10 × 1 and the 04 case option is 40 mm overall length.
Does 22811-00-04-10-02 include stainless-steel armor on the integral cable?
No. The 22811 family is unarmored; the cable route needs separate protection where physical abuse is expected.
Will a one-metre lead on 22811-00-04-10-02 complete a 5 m 7200 loop by itself?
No. A 4.00 m extension cable is used with the 1.0 m integral lead for the five-metre 18745-03 arrangement.
Does 22811-00-04-10-02 have a protruding unthreaded section for a recessed shaft target?
No. The 00 option is 0 mm unthreaded length; the installed mount determines probe-tip placement.
What connector is supplied on 22811-00-04-10-02 for the 7200 cable path?
The 02 option supplies a miniature male coaxial connector for the matching extension arrangement.
Can 22811-00-04-10-02 be wired directly to a monitor without a Proximitor?
No. The probe is one component of the 7200 transducer system; the Proximitor conditions the signal supplied to the monitor.
