Compressor Controls Corporation TIOC-555HD is a rear I/O transition module that provides field-termination connections for IOC-555-D card positions in a Series 5 Vanguard duplex controller chassis.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for TIOC-555HD
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for TIOC-555HD

  • Manufacturer:
    COMPRESSOR-CONTROLS
  • Part Number:
    TIOC-555HD
  • Product Family:
    COMPRESSOR-CONTROLS
  • Product Type:
    Series 5 Vanguard I/O Transition Module
  • Stock:
    1
  • System Platform:
    Series 5 Vanguard
  • Module Function:
    I/O transition module and field-termination interface
  • Chassis Position:
    Rear transition-module position corresponding to the front I/O card slot
  • Front-card Association:
    IOC-555-D in the documented duplex chassis arrangement
  • Supported Duplex I/O Positions:
    Rear positions corresponding to front slots 3 through 8
  • Field Interface:
    FTA connections located on each TIOC module
  • Chassis Capacity Context:
    Up to three paired IOC/TIOC paths in the documented duplex chassis
  • Access Requirement:
    Rear access required for transition modules and cables
  • External Interface Reference:
    One 9-pin port and four 60-pin connectors reported by the exact-model regional reference
  • Dimensions:
    23.4 × 8.0 × 2.0 cm
  • Weight:
    0.2 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Chassis Placement Card Pairing Field Termination Application
  • Rear transition interface for a corresponding IOC-555-D front card
  • Field termination assembly connections located on the TIOC module
  • Matched front and rear chassis positions in a duplex I/O arrangement

TIOC-555HD connects the Series 5 Vanguard I/O card path to rear-access field termination cabling in the documented duplex chassis.

Its position must correspond to the front IOC card, preserving the redundant A/B channel assignment and the chassis keying intended to prevent mismatched card and transition-module combinations.

Replacement control therefore depends on exact suffix verification, rear-slot identity, cable and FTA labeling, channel maps, shielding, and a point-by-point test of both redundant paths.

Availability, condition, price, and shipping time for TIOC-555HD are confirmed during quotation.

Compressor Controls Corporation TIOC-555HD Series 5 Vanguard I/O Transition Module Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Transition modules mount at the rear of the Series 5 duplex chassis
  • Rear position numbers correspond to front-card slot numbers
  • Rear access is required for module and cable installation
  • Each TIOC position corresponds to an IOC-555-D front-card position
  • Duplex A and B paths occupy defined paired I/O slots
  • Chassis keying helps prevent card and transition-module mismatch
  • FTA connections are located on each TIOC module
  • Cable identity and channel mapping must be preserved during replacement
  • Shields, grounds, and redundant-path separation require controlled verification
  • Rear field termination in a Series 5 Vanguard duplex compressor-control chassis
  • I/O transition for paired IOC-555-D cards in redundant controller arrangements
  • Field interface routing between Series 5 controller I/O and connected compressor instrumentation
Description
TIOC-555HD is an I/O transition module installed at the rear of a Series 5 Vanguard duplex controller chassis behind the corresponding IOC-555-D front-card position.

The transition module provides the field termination assembly connection point for the I/O path, while the chassis keying and matched front/rear slot positions help prevent card-to-transition-module mismatch.

Before replacement, confirm the complete HD suffix, corresponding IOC-555-D channel, rear slot, chassis keying, interface-cable labels, FTA connectors, field wiring records, and the isolated state of the controlled equipment.
Alternative Names
TIOC-555HD TIOC 555HD TIOC555HD CCC TIOC-555HD Compressor Controls TIOC-555HD Compressor Controls Corporation TIOC-555HD Series 5 Vanguard TIOC-555HD
Technical notes
TIOC-555HD replacement requires confirmation of the HD suffix, rear chassis position, paired IOC-555-D card, keyed slot, interface cables, FTA mapping, shielding, and redundant A/B path; connector fit alone cannot prove compatibility.
