    Apter Power provides this genuine GE 489 Generator Protection System to ensure the reliability and longevity of your power generation assets.

489-P5-HI-A20-E

/ 4.9
1001 reviews | Need a Specific Revision?
The 489-P5-HI-A20-E generator protection relay is a multi-functional protection system that provides comprehensive and safe protection for generator equipment, ensuring its reliable operation and preventing electrical faults.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 489-P5-HI-A20-E
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 489-P5-HI-A20-E

  • Manufacturer:
    General Electric
  • Part Number:
    489-P5-HI-A20-E
  • Product Family:
    GE Generator Protection System
  • Product Type:
    Generator Protection Relay
  • Stock:
    1
  • CT Primary:
    10 to 50000 A
  • CT Secondary:
    1 A or 5 A (must be specified with order)
  • Conversion Range:
    0.02 to 20 x CT
  • VT Ratio:
    1.00 to 240.00:1 in steps of 0.01
  • VT Secondary:
    200 V AC (full-scale)
  • Conversion Range:
    0.02 to 1.00 x Full Scale
  • Accuracy:
    ±0.5% of Full Scale
  • Max. Continuous:
    280 V AC
  • Weight:
    7.36 kg
  • Estimated shipping dimensions:
    21.5x23x25cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Diagnostics & Protection Safety & Compliance

Features:

  • Complete, Secure Protection for Small to Medium Sized Generators
  • Advanced Protection and Monitoring with RTD Thermal and Vibration Inputs
  • Global Acceptance in Renowned Protection Relay Product Family
The 489-P5-HI-A20-E operates as a comprehensive generator protection relay, providing complete, secure protection for small to medium sized generator assets across diverse industrial applications. It continuously monitors generator electrical parameters, thermal conditions, and mechanical health to prevent costly damage from faults, overloads, and abnormal operating conditions. Seamless integration with monitoring systems is standard with the 489-P5-HI-A20-E, however using its advanced communication capabilities will allow seamless data exchange with SCADA and energy management platforms for comprehensive system visibility. The 489-P5-HI-A20-E has incorporated significant improvements in protection functionality and user interface design over previous relay generations in addition to maintaining global acceptance as a member of the most renowned protection relay product family in the market.

The 489-P5-HI-A20-E provides essential protection functions critical to generator safety, and is a vital component of the generator protection scheme, directly affecting the proper, normal operation of the overall power generation system. One 489-P5-HI-A20-E relay is required per generator depending on the protection requirements and application complexity. The 489-P5-HI-A20-E features a large, user-friendly front panel interface with a display that is easily readable in direct sunlight, enabling convenient local monitoring and setpoint access.

For enhanced reliability applications, the 489-P5-HI-A20-E system supports comprehensive diagnostic capabilities including IRIG-B time synchronized event records, waveform capturing, and data loggers for detailed troubleshooting analysis. In addition to standard protection functions, the advanced configuration also performs automatic event logging. The 489-P5-HI-A20-E protection system executes monitoring using the internal RTD inputs specified for stator and bearing thermal protection. Using this method, the protection system continually monitors the health of generator thermal conditions. If the system detects that temperatures exceed configured thresholds (outside acceptable operating levels), it will automatically initiate protective actions and place an event in the event record.

The 489-P5-HI-A20-E GE Generator protection relay may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric 489-P5-HI-A20-E Generator protection relay Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric 489-P5-HI-A20-E Generator protection relay Specs

General

  • Manufacturer General Electric
  • Model 489-P5-HI-A20-E
  • Condition New Original ready stock
  • Product Family 489-P5-HI-A20,489-P1-LO-A20-E
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Generator Types: Synchronous or induction generators operating at 25, 50, or 60 Hz.
  • Cogeneration: Ideally suited for primary or backup protection in cogeneration applications.
  • System Integration: Supports direct integration into DCS and SCADA systems via Modbus RTU, Modbus TCP/IP, and DNP 3.0 protocols.
  • Core Protection: Includes high-speed stator differential protection (87G), 100% stator ground (64), loss of excitation (40Q), and reverse power/anti-motoring (32).
  • Thermal Monitoring: Uses thermal modeling algorithms and RTD biasing for precise stator and bearing overtemperature protection.
  • Diagnostic Tools: Features waveform capture for fault analysis, IRIG-B time-synchronized event records, and data logging.
  • Security Features: Includes RTD voting to prevent nuisance trips from single sensor malfunctions.
  • Electrical Standards: Complies with IEEE/ANSI C37.90.1 for Surge Withstand Capability (SWC) and impulse voltage withstand up to 5 kV.
  • Maintenance Safety: Features a draw-out construction, allowing for easy removal and installation during maintenance without disturbing field wiring.
  • Environmental Protection: Available with a harsh chemical environment option (conformal coating) to ensure durability in industrial settings.
  • Quality Management: Manufactured in facilities registered to ISO 9001:2000.
Description
The 489-P5-HI-A20-E is a comprehensive generator protection relay designed specifically for safeguarding small to medium-sized generators across diverse industrial and commercial environments. This versatile protection system delivers complete, secure protection for generator assets, ensuring reliable operation and preventing costly damage from electrical faults, thermal overloads, and mechanical issues. The 489-P5-HI-A20-E features an easy-to-use interface supported by an industry-leading suite of software tools that simplify configuration, monitoring, and maintenance procedures for protection engineers and technicians.

The 489-P5-HI-A20-E incorporates advanced protection and monitoring capabilities that address critical generator health parameters. The relay utilizes RTDs (Resistance Temperature Detectors) for comprehensive stator and bearing thermal protection, preventing insulation damage and bearing failures caused by excessive heat. Additionally, the 489-P5-HI-A20-E provides analog inputs dedicated to vibration monitoring, enabling early detection of mechanical imbalances, misalignment, or bearing degradation that could lead to catastrophic generator failure. These features make the 489-P5-HI-A20-E particularly valuable in power generation facilities, manufacturing plants with captive power units, and marine applications where generator reliability is paramount.

Designed for global acceptance, the 489-P5-HI-A20-E belongs to the most renowned protection relay product family in the market, ensuring compatibility with existing infrastructure and industry standards worldwide. The relay features a robust draw-out construction that allows for minimized downtime during maintenance routines, enabling easy removal and installation of the 489-P5-HI-A20-E without disrupting critical power system operations. This design characteristic proves especially beneficial in continuous process industries such as chemical plants, data centers, and healthcare facilities where generator availability cannot be compromised.

The 489-P5-HI-A20-E is equipped with a large, user-friendly front panel interface that facilitates real-time power monitoring and convenient setpoint access. The display is specifically engineered to remain easily readable even in direct sunlight, making the 489-P5-HI-A20-E ideal for outdoor installations, switchyard environments, and shipboard applications where lighting conditions vary significantly. Enhanced generator troubleshooting capabilities are achieved through IRIG-B time-synchronized event records, waveform capturing functionality, and integrated data loggers that provide detailed forensic analysis of system disturbances and protection operations.

For commissioning and testing efficiency, the 489-P5-HI-A20-E offers simplified setpoint verification testing using built-in waveform simulation functionality, reducing the time and resources required for relay validation. The relay provides cost-effective access to critical information through industry-standard communication hardware including RS232, RS485, and 10BaseT Ethernet interfaces, supporting protocols such as Modbus RTU, Modbus TCP/IP, and DNP 3.0 for seamless integration with SCADA systems and energy management platforms. The 489-P5-HI-A20-E is available with a Harsh Chemical Environment Option for deployment in extreme locations, and it carries GL Certification for below-deck shipboard applications, making it suitable for marine vessels, offshore platforms, petrochemical facilities, and other demanding industrial environments where corrosive atmospheres and severe operating conditions prevail.
Alternative Names
489-P5-HI-A20 489-P1-LO-A20-E 489-P1-LO-A20 489 P5 HI A20 E 4B9-P5-HI-A20-E 489-P5-H1-A20-E 489-P5-HI-A2O-E
Technical notes
The General Electric 489-P5-HI-A20-E serves as an upgraded iteration featuring an enhanced display option designed to directly replace or update standard legacy 489 variants without altering existing wiring layouts. For correct commissioning, technicians must ensure the order code parameters match the 5A CT secondary ratings and the 90–300 VDC / 70–265 VAC control power specifications of the host switchgear panel.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the 489-P5-HI-A20-E designed for?
The 489-P5-HI-A20-E is a comprehensive generator protection relay developed to safeguard small to medium-sized generators in a wide range of industrial and commercial environments. It ensures reliable operation by protecting generator assets from electrical faults, thermal overloads, and mechanical issues.
What makes the 489-P5-HI-A20-E a reliable protection solution?
It provides complete and secure protection through advanced monitoring and protection functions, helping prevent costly damage and unplanned downtime while maintaining stable generator performance.
How does the 489-P5-HI-A20-E simplify operation and maintenance?
The relay features an intuitive interface supported by powerful software tools that streamline configuration, monitoring, and maintenance tasks for engineers and technicians.
What thermal protection capabilities does the 489-P5-HI-A20-E offer?
It uses RTDs (Resistance Temperature Detectors) to monitor stator and bearing temperatures, preventing overheating that could lead to insulation damage or bearing failure.
