        IS220PTCCH1B

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        IS220PTCCH1B is a GE Mark VIe thermocouple input module with 12 combustion-optimized channels, 16-bit resolution, 100Hz sampling, and dual Ethernet for gas/steam turbine control.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for IS220PTCCH1B
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IS220PTCCH1B

        • Manufacturer:
          General Electric
        • Part Number:
          IS220PTCCH1B
        • Product Family:
          GE Mark VIe Distributed I/O
        • Product Type:
          Input Module
        • Stock:
          1
        • Resolution:
          16-bit A/D Conversion
        • Sampling Rate:
          100 Hz (per channel)
        • Accuracy:
          ±0.25 % FS (±0.5 °C)
        • Isolation Voltage:
          1500 Vrms
        • Input Voltage (Signal):
          -8 mV to +45 mV / ±80 mV
        • Operating Temperature:
          -40°C to +70°C (some variants -30°C to +65°C)
        • Storage Temperature:
          -45°C to +85°C
        • Weight:
          0.38 kg
        • Estimated shipping dimensions:
          12.8x8.2x6cm
        • Tariff Code:
          8517795000
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Application Certifications Compatibility

        Features:

        • 16-bit resolution with 100 Hz sampling per channel, delivering ±0.25% FS accuracy for precise gas/steam turbine exhaust monitoring .
        • Auto-sensor recognition, built-in cold junction compensation, and 2 ms open/short circuit detection for rapid fault diagnosis .
        • Dual Ethernet ports supporting TMR/duplex configurations and hot-swap design (<5 min MTTR) for non-stop system availability .
        The IS220PTCCH1B is engineered to meet the demanding response requirements of gas turbine exhaust temperature monitoring. It features a 16-bit A/D converter and a dedicated sampling rate of 100 Hz per channel, enabling the control system to detect rapid thermal changes such as flame instability or combustor blowout within a 10 ms window .

        Equipped with advanced onboard intelligence, the IS220PTCCH1B continuously monitors itself and its field wiring. It includes auto-sensor recognition that identifies the type of thermocouple connected (E, J, K, etc.) and its polarity without manual configuration, preventing human configuration errors . Crucially, it performs hardware line monitoring capable of detecting an open circuit (broken wire) or short circuit in the thermocouple loop within 2 milliseconds and immediately flags the data as invalid .

        The IS220PTCCH1B is built for the redundancy requirements of critical power generation assets. It features dual independent 10/100 Mbps Ethernet ports that support Modbus TCP/IP and Profibus DP protocols, allowing integration into redundant I/O networks (IOnet) . This hardware supports Simplex, Duplex, and full Triple Modular Redundant (TMR) control architectures without additional external switches, allowing a single combustion temperature sensor to feed three independent processor channels simultaneously for 2oo3 voting logic .

        The IS220PTCCH1B GE Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

        GE IS220PTCCH1B Input Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        GE IS220PTCCH1B Input Module Specs

        General

        • Manufacturer GE
        • Model IS220PTCCH1B
        • Condition New Original ready stock
        • Product Family IS220PAICH1A,IS220PAICH2A,IS220PAOCH1A
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Gas Turbine Exhaust Frameworks: Extensively used to monitor Exhaust Gas Temperature (EGT) profiles across the turbine circumference to analyze combustion uniformity, protect blades from thermal stress, and prevent compressor stalls.
        • Heavy Thermal Power Generation: Deployed in steam turbine casing monitors, boiler tube superheaters, and bearing temperature watchdogs across combined-cycle and nuclear plants.
        • Industrial Furnace & Combustion Systems: Applied in heavy petrochemical processing, steel reheating ovens, and large-scale industrial incinerators to maximize fuel-to-air combustion efficiency and reduce carbon footprint.
        • Hazardous Area Safety (ATEX / IECEx): Certified under IECEx UL 21.0067X and DEMKO ATEX standards. It complies with explosion-protection protocols for Zone 2, Group IIC, T4 environments, enabling mounting inside fuel-skid or turbine-enclosure junction boxes.
        • North American Safety Listings: Evaluated and certified under UL 61010-1 and CSA C22.2 No. 61010-1 for standard electrical safety and equipment control compliance.
        • Marine & Offshore Approvals: Meets stringent international marine type approvals (such as DNV, Lloyd’s Register, or ABS) regarding mechanical vibration resistance, humidity survival, and electromagnetic compatibility (EMC) on offshore drilling vessels.
        • Multi-Topology Redundancy: Interoperable with multi-tier voting schemes. It supports Simplex (single channel), Duplex (dual backup networks), and Triple Modular Redundancy (TMR) architectures. In TMR setups, three individual PTCC packs plug into a single TBTCH terminal board to achieve bumpless voting hardware protection.
        • Dual IONet Communications: Features dual, full-duplex 100 Mbps Ethernet ports (IONet). This proprietary, deterministic network enables the pack to interoperate in real-time with Mark VIe master controllers.
        • Sensor Flexibility: Natively interoperates with diverse industry-standard sensor types, including E, J, K, S, and T-type thermocouples (whether grounded or ungrounded) as well as raw millivolt signals ranging from -8 mV to +45 mV.
        Description
        The IS220PTCCH1B is a Thermocouple Input Module from General Electric, specifically designed for the Mark VIe Speedtronic platform to manage critical turbine temperature monitoring. This IS220PTCCH1B features 12 combustion-optimized inputs with a dedicated cold junction, supporting conventional thermocouples such as Types E, J, K, S, and T for precise exhaust temperature measurement.

        To ensure high accuracy, the IS220PTCCH1B utilizes 16-bit A/D conversion with 100 Hz sampling per channel and ±0.25% FS accuracy. The IS220PTCCH1B is equipped with dual redundant Ethernet ports (Modbus TCP/IP, Profibus DP), allowing parallel connection to DCS and cloud platforms for real-time diagnostics and firmware updates. It also supports hot-swap replacement for easy maintenance.

        For reliability, the IS220PTCCH1B integrates comprehensive self-diagnostics, including flash memory, RAM, and power supply monitoring. Its isolation rating of 1500 Vrms prevents ground loops, and its ATEX Zone 2 certification makes the IS220PTCCH1B suitable for hazardous environments. It operates on 28 Vdc with a current draw of 0.16 A.
