    Apter Power can support HIMA K7214 documentation access, pricing requests, and confirmation of the recorded 24 VDC distribution designation.

K7214

/ 4.9
1001 reviews | Need a Specific Revision?
HIMA K7214 is a 24 VDC fusing and current distribution unit rated for 120 A with 18 circuit-breaker slots in HIQuad X power systems.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for K7214
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for K7214

  • Manufacturer:
    HIMA
  • Part Number:
    K7214
  • Product Family:
    HIMA HIQuad® X
  • Product Type:
    24 VDC Fusing and Current Distribution Unit
  • Stock:
    1
  • Rated voltage:
    24 VDC
  • Total current rating:
    120 A
  • Circuit-breaker capacity:
    18 slots
  • Distribution function:
    Fusing and current distribution
  • Equipment section:
    Power supply current and distribution
  • Tariff Code:
    8537109090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Capacity Breaker Slots Protection Cabinet Match

Features:

  • 24 VDC fusing and current distribution
  • 120 A documented current rating for the complete assembly
  • 18 circuit-breaker slots for outgoing branches
HIMA identifies K7214 in the power-supply current and distribution section of the certified HIQuad X equipment scope.

The 120 A value applies to the distribution assembly, while the eighteen slots define the available circuit-breaker positions.

Selection and maintenance must follow the exact 24 VDC designation and the approved branch schedule for the installed cabinet.

The HIMA K7214 24 VDC Fusing and Current Distribution Unit is listed as Active / Available from OEM; Apter Power can assist with pricing and official documentation.
HIMA K7214 24 VDC Fusing and Current Distribution Unit Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Applying the documented assembly rating

  • Current ceiling: The complete K7214 distribution assembly is documented for 120 A.
  • Supply basis: All outgoing circuits originate from the specified 24 VDC distribution system.
  • Load total: The connected branch demands are considered together against the assembly rating.
  • Capacity review: Any added branch is checked against both the feeder and the remaining documented capacity.

Organizing protected outgoing circuits

  • Available positions: K7214 provides eighteen circuit-breaker slots within one distribution assembly.
  • Branch identity: Each populated position is matched to its documented cabinet destination.
  • Protective device: The installed breaker must suit the conductor and connected 24 VDC load.
  • Unused positions: Spare slots remain identified so later changes do not bypass the approved circuit schedule.

Tracing an interrupted 24 VDC branch

  • Fault location: The affected circuit-breaker position identifies the outgoing branch requiring inspection.
  • Load check: Downstream wiring and equipment are examined before the protective device is restored.
  • Feeder condition: The common 24 VDC input is checked separately from an individual branch event.
  • Return to service: The branch is re-energized only after its fault cause and breaker rating are confirmed.

Matching the installed distribution assembly

  • Model marking: The complete K7214 designation is confirmed on the installed unit.
  • Voltage match: The replacement arrangement must retain the documented 24 VDC supply basis.
  • Slot map: All eighteen positions are compared with the existing breaker and load schedule.
  • Approval scope: The cabinet design is reviewed against the certification applicable to the installation.
Description
Within the HIQuad X power-supply architecture, HIMA K7214 performs the fusing and current-distribution function for 24 VDC cabinet circuits.

The complete HIMA K7214 assembly carries a documented 120 A rating and provides eighteen circuit-breaker slots for protected outgoing branches.

Because HIMA K7214 is identified specifically for 24 VDC distribution, feeder voltage, branch allocation, and protective-device selection must follow the approved cabinet design.

When servicing HIMA K7214, record the installed breaker positions and connected loads before removal so the original distribution arrangement can be restored accurately.
Alternative Names
HIMA K 7214 HIMA-K7214 HIMA K-7214 K 7214 HIMA HIMAK7214 K7214 HIMA HIQuad X HIMA HIQuad X K7214 HIMA K7214 Power Distribution
Technical notes
K7214 provides 24 VDC fusing and current distribution rated at 120 A, with 18 circuit-breaker slots. Match the installed feeder and branch schedule before replacement.
