FC-TSRO-0824 V1.1

/ 4.9
1001 reviews | Need a Specific Revision?
The FC-TSRO-0824 V1.1 is a Field Termination Assembly (FTA) module designed by Honeywell as a critical interface component within safety instrumented systems.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for FC-TSRO-0824 V1.1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FC-TSRO-0824 V1.1

  • Manufacturer:
    Honeywell
  • Part Number:
    FC-TSRO-0824 V1.1
  • Product Family:
    Honeywell FSC Series
  • Product Type:
    Field Termination Assembly Module
  • Stock:
    2
  • Approvals:
    CE, UL, TUV, CSA
  • Safety class:
    up to and including SIL3
  • Input Nominal input voltage:
    24 Vdc
  • Max. input voltage:
    36 Vdc
  • Relay pick-up voltage:
    19.2 Vdc
  • Input current:
    Typically 40 mA at 24 Vdc
  • Output Number of output channels:
    8
  • Max. output current:
    5 A (fused)
  • Min. output current:
    1 mA at 5 V
  • Max. output voltage:
    250 Vac / 250 Vdc
  • Weight:
    0.5 kg
  • Estimated shipping dimensions:
    30.1x7x5.8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Performance & Efficiency Environmental Ratings

Features:

  • Bridge Between System Interconnection Cable and External Field Wiring
  • Integrates Relay-Based Safe Output Capability with SIL3 Compliance
  • Functions Alongside Safety Manager and SICC-0001/Lx Cable Systems
The FC-TSRO-0824 V1.1 serves as the Safe Dry Digital Output Field Termination Assembly within Safety Manager systems, providing reliable potential-free output channels for critical safety applications. It continuously interfaces between the system interconnection cable SICC-0001/Lx and external field wiring through screw terminals, delivering eight independent relay-based output channels to support SIL3-rated operations without fault exclusions. Each channel incorporates three relays, a fused normally open field contact rated at 5 AT slow-acting, and a status indication LED for operational visibility. The FC-TSRO-0824 V1.1 enables Safety Manager to achieve 115/230 Vac output capability for SIL3 applications, with floating non-commoned contacts that can be wired independently according to field requirements.

The FC-TSRO-0824 V1.1 provides essential output interface functions common to the entire safety system, and is a critical component of the safety instrumented function path, directly affecting the proper, normal operation of the overall Safety Manager system. One FC-TSRO-0824 V1.1 module is required per eight-channel output requirement, occupying a dedicated slot within the termination assembly configuration.

For expanded output applications, the Safety Manager system accommodates multiple FC-TSRO-0824 V1.1 modules installed in appropriate slots. In addition to standard single module operation, the modular configuration allows flexible scaling. The Safety Manager system continuously monitors the status of each FC-TSRO-0824 V1.1 through integrated diagnostics. If the system detects that any output channel requires attention, the status indication LED provides immediate visual feedback, and module health information is communicated to the central safety controller for logging and maintenance planning.

The FC-TSRO-0824 V1.1 HONEYWELL Safe dry digital output FTA may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
HONEYWELL FC-TSRO-0824 V1.1 Safe dry digital output FTA Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
HONEYWELL FC-TSRO-0824 V1.1 Safe dry digital output FTA Specs

General

  • Manufacturer HONEYWELL
  • Model FC-TSRO-0824 V1.1
  • Condition New Original ready stock
  • Product Family FS-TSDO-0824,FC-TSDO-0824,FC-TSRO-0824
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Emergency Shutdown (ESD) Systems: Ensuring safe plant shutdown during critical process deviations.
  • Fire and Gas (F&G) Detection: Activating safety interlocks and alarms for fire or hazardous gas leaks.
  • Burner/Boiler Management: Controlling critical fuel valves and ignition sequences.
  • Critical Process Control: Managing safety-critical loops in oil, gas, and chemical processing.
  • Output Configuration: Features 8 relay-based, potential-free safe output channels.
  • Voltage: Up to 250 Vac/Vdc.
  • Current: Rated for 5 A per channel (fused with 5 AT slow-acting fuses).
  • Switched Load: Maximum 1250 VA (AC) or 150 W (DC).
  • Reliability: Utilizes gold flash over silver alloy contact materials to ensure long-term electrical conductivity even in low-load conditions (minimum 1 mA at 5 V).
  • Diagnostics: Includes status indication LEDs for each channel to facilitate rapid troubleshooting and monitoring.
  • Operating Temperature: Typically -5°C to +60°C (23°F to 140°F). Some variants may support expanded ranges up to +70°C.
  • Isolation: Provides robust electrical protection with 4000 Vac isolation from coil to contact and 1200 Vac contact to contact.
  • Protection: Features IP65 protection class for the module itself in certain configurations, safeguarding against dust and water ingress.
  • Certifications: Complies with CE, UL, TUV, and CSA standards for functional safety and industrial hardware.
Description
FC-TSRO-0824 V1.1 serves as the connection point between the system interconnection cable SICC-0001/Lx and external field wiring through screw terminals, ensuring reliable signal transmission in demanding industrial environments. The FC-TSRO-0824 V1.1 features eight relay-based potential-free safe output channels, making it suitable for applications requiring Safety Integrity Level 3 (SIL3) compliance without relying on fault exclusions. This capability positions the FC-TSRO-0824 V1.1 as a trusted solution for safety-critical operations where failure could result in significant hazards.

The FC-TSRO-0824 V1.1 is specifically engineered to meet stringent safety requirements outlined in IEC 61508, providing assurance for general use in SIL3-classified safety applications. Each output channel on the FC-TSRO-0824 V1.1 comprises three relays, a fused normally open (NO) field contact rated at 5 AT slow-acting, and a status indication LED for real-time operational monitoring. The floating, non-commoned output contacts can be wired independently, offering flexibility in system design and installation. Additionally, the relays within the FC-TSRO-0824 V1.1 are capable of driving diverse loads, including 115/230 Vac applications, thereby extending the Safety Manager's output capability to support SIL3-rated 115/230 Vac outputs. The energized relay state is clearly indicated by an LED on the module, facilitating quick diagnostics and maintenance activities.
Alternative Names
FC-TSRO-O824 V1.1 FC-TSRO-0824 VI.I FC TSRO 0824 V1.1 FC-TSDI-1624 FC-TSDI-16UNI FC-TSHART-1620M FC-TSDO-0824 FC-TSAO-0220M
Technical notes
The Honeywell FC-TSRO-0824 V1.1 is a Safety Relay Output Module designed for the Honeywell FSC (Fail‑Safe Control) and Safety Manager systems . It provides 8 relay output channels with 24V DC operation, certified for use in safety‑critical applications up to SIL 3 (per IEC 61508) and PL e (per ISO 13849-1).
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the FC-TSRO-0824 V1.1 module?
The Honeywell FC-TSRO-0824 V1.1 is a Field Termination Assembly (FTA) designed for safety instrumented systems. It acts as a reliable interface between system interconnection cables and external field wiring in industrial environments.
What advantages does the FC-TSRO-0824 V1.1 design provide?
The Honeywell FC-TSRO-0824 V1.1 uses floating, non-commoned contacts, allowing each output to be wired independently. This enhances system flexibility and simplifies installation in complex industrial setups.
How does the FC-TSRO-0824 V1.1 support monitoring and maintenance?
The Honeywell FC-TSRO-0824 V1.1 features LED indicators that display the energized state of each relay. This provides immediate visual feedback, making diagnostics and maintenance more efficient.
Why is FC-TSRO-0824 V1.1 suitable for safety-critical environments?
With SIL3 compliance, robust relay design, and flexible wiring options, the Honeywell FC-TSRO-0824 V1.1 ensures reliable operation in environments where safety, uptime, and fault tolerance are essential.
