MOTION CONTROL MP3-404HR2 is a compact multi‑axis motion control module designed for precision positioning and I/O management in industrial automation systems.
Get a quick price for MP3-404HR2
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MP3-404HR2

  • Manufacturer:
    MOTION SCIENCE
  • Part Number:
    MP3-404HR2
  • Product Family:
    MOTION SCIENCE
  • Product Type:
    Motion Multi‑Axis Motion Control Module
  • Communication Ports:
    Multiple RJ45 style interfaces
  • I/O Connections:
    Removable terminal blocks (green)
  • Feedback Support:
    High‑resolution encoder / resolver (HR series)
  • Cooling:
    Passive convection chassis heat dissipation
  • Operating Environment:
    Industrial indoor use, non‑condensing
  • Weight:
    3.36 kg
  • Estimated shipping dimensions:
    10.9x24.2x39.5cm
  • Tariff Code:
    9032899099
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Monitoring & Control Configuration Applications

Features:

  • High‑Resolution (HR) Feedback Processing
  • Modular Internal Architecture for Simplified Maintenance
  • Industrial‑Grade Build with Multiple I/O and Communication Ports
The MOTION CONTROL MP3-404HR2 is built with enhanced position feedback circuitry that supports high‑resolution encoders or resolvers. This allows the module to maintain accurate positioning even at very low speeds, making it ideal for precision stages and coordinated multi‑axis moves.

Inside the MOTION CONTROL MP3-404HR2, logic, I/O, and power functions reside on separate board sections (e.g., 9290005‑type logic boards). This design enables targeted board‑level troubleshooting and replacement, significantly reducing downtime and repair costs compared to fully integrated units.

Equipped with RJ45 ports and removable green terminal blocks, the MOTION CONTROL MP3-404HR2 supports flexible field wiring and digital communication. Its rugged chassis resists electrical noise and thermal stress, ensuring reliable operation on factory floors without active cooling.

The MP3-404HR2 MOTION CONTROL Motion Multi‑Axis Motion Control Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
MOTION CONTROL MP3-404HR2 Motion Multi‑Axis Motion Control Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
MOTION CONTROL MP3-404HR2 Motion Multi‑Axis Motion Control Module

General

  • Manufacturer MOTION CONTROL
  • Model MP3-404HR2
  • Condition New Original ready stock
  • Product Family MP3-404BR2,MP3-404HR1,MP3-402HR2
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Real‑time LED Status:Front‑panel Power, Ready, and Fault LEDs provide immediate operational feedback.
  • Analog Monitor Outputs:Velocity or current signals available for oscilloscope‑based tuning and troubleshooting.
  • Closed‑loop Feedback:Continuously compares command and actual position to correct deviations instantly.
  • External Brake Control:Integrated logic outputs for managing mechanical brakes during emergency stops or power loss.
  • Standardized I/O Mapping:Predictable pin assignments on terminal blocks simplify integration with MoPro3‑compatible controllers.
  • Hardware Jumpers & DIP Switches:Physical switches for setting gain parameters, feedback types, and operational modes without software.
  • Potentiometer Tuning:On‑board potentiometers for adjusting offset, balance, and signal gain.
  • Proprietary RJ45 Communication:The multi‑port RJ45 interface supports Motion Science’s serial or network protocol (details require official manual).
  • Precision CNC Machinery:Axis control for milling and lathe equipment requiring coordinated motion and holding torque.
  • Packaging Systems:High‑speed labeling, filling, and cartoning lines where timing accuracy is critical.
  • Material Handling:Conveyor synchronizers, automated sorting gates, and stacker cranes.
  • Semiconductor Manufacturing:Cleanroom‑compatible motion stages for wafer handling and inspection.
Description
The MOTION CONTROL MP3-404HR2 integrates motion logic and field I/O interfacing into a single panel‑mount unit. Its modular internal architecture – including separate logic, I/O, and power sections – simplifies diagnostics and targeted board‑level replacement, reducing long‑term maintenance costs for critical production lines.

Engineered for industrial environments, the MOTION CONTROL MP3-404HR2 features multiple RJ45 communication ports and removable terminal blocks for secure field wiring. The “HR” (High Resolution) designation indicates enhanced feedback processing capability, making this module suitable for applications that demand fine position control and smooth low‑speed operation.

As a legacy product from Motion Science Inc., the MOTION CONTROL MP3-404HR2 is particularly valuable for maintaining existing MoPro3‑compatible systems. Its robust housing resists electrical noise and thermal stress, ensuring stable performance on factory floors where system uptime is critical.
Alternative Names
MP3-404BR2 MP3-404HR1 MP3-402HR2 MP3-408HR2
Technical notes
Before maintenance the MOTION CONTROL MP3-404HR2, please release the internal DC bus capacitor and ensure that the configuration jumper matches your motor feedback type to prevent malfunctions.
