IOP302 is a Metso Automation maxPAC 16-channel 4 to 20 mA analog input module for maxDNA DCS process signals.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IOP302
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IOP302

  • Manufacturer:
    Metso Auttomation
  • Part Number:
    IOP302
  • Product Family:
    Metso Auttomation
  • Product Type:
    16 channel 4 to 20 mA common analog input module
  • Stock:
    1
  • Input:
    4 to 20 mA common input
  • Channels:
    16
  • Loop power:
    24 V backplane transmitter loop power, individually fused
  • Resolution:
    15 bits plus sign
  • Scan:
    20 ms
  • Conversion:
    sigma delta, one ADC per channel
  • Calibration:
    startup and periodic online calibration
  • Input impedance:
    300 Ohm
  • Normal mode:
    50 V
  • Rejection:
    60 dB at 50 and 60 Hz
  • Isolation:
    1500 VAC field to logic
  • Input power:
    125 mA
  • Dimensions:
    4.4 × 31.5 × 25.6 cm
  • Weight:
    0.62 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Loop wiring Diagnostics System integration Application
  • IOP302 is a maxPAC sixteen channel common analog input module.
  • The module accepts 4 to 20 mA process transmitter signals.
  • Backplane loop power, isolation, calibration, and diagnostics support DCS operation.

IOP302 is a Metso Automation maxPAC analog input module.

Availability, condition, price, and shipping time for IOP302 are confirmed during quotation.

Metso Automation IOP302 Manuals, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Identify each 4 to 20 mA transmitter loop and polarity.
  • Check backplane loop power and individual fuses.
  • Verify field terminals and DPU point mapping before energizing.
  • Use module diagnostics and Active indication to check operating state.
  • Separate transmitter, fuse, wiring, and module faults.
  • Record calibration and diagnostic results after replacement.
  • Confirm DPU, chassis position, and bus address.
  • Verify common or redundant module arrangement.
  • Compare the loop list with the maxDNA DCS configuration.
  • maxPAC local process I/O cabinets.
  • maxPAC remote I/O transmitter loops.
  • 4 to 20 mA process measurement in maxDNA DCS installations.
Description
IOP302 is a Metso Automation maxPAC 4 to 20 mA common analog input module.

The module converts sixteen process transmitter inputs with backplane loop power, field-to-logic isolation, sigma delta conversion, diagnostics, and online recalibration.

Before replacement, confirm maxPAC chassis, DPU compatibility, bus address, field wiring, loop power, and redundant or common module configuration.
Alternative Names
IOP302 Metso IOP302 Metso Automation IOP302 maxPAC IOP302 IOP 302
Technical notes
IOP302 is a maxPAC sixteen channel 4 to 20 mA module. Verify DPU, chassis, address, loop power, wiring, and redundancy before replacement.
