        PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201
        PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201
        PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201
        PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201
        PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201
        PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201
        Ask our team:
        • Phone: +86 181 0690 9650
        • E-Mail sales1@apterpower.com

        SCE906A2-002-01-SCE906A200201

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 is a fully digital AC servo drive designed for precision motion control in demanding industrial environments.
        Get a quick price for SCE906A2-002-01-SCE906A200201
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for SCE906A2-002-01-SCE906A200201

        • Manufacturer:
          PACIFIC SCIENTIFIC
        • Part Number:
          SCE906A2-002-01-SCE906A200201
        • Product Family:
          PACIFIC SCIENTIFIC
        • Product Type:
          Digital AC Servo Drive
        • Main Power Supply:
          400 VAC +32% / -55%, 3-phase, 50/60 Hz
        • Control Power Supply:
          230 VAC ±10%, 1-phase, 50/60 Hz
        • Peak Output Current (r.m.s.):
          33.7 A (for max. 5s at 50°C)
        • Continuous Output Current (r.m.s.):
          11.25 A (at 50°C with forced air cooling)
        • Peak Output Power:
          22.5 kVA (for max. 1s at 50°C)
        • Current Loop Bandwidth:
          1500 Hz max.
        • Velocity Loop Bandwidth:
          400 Hz max.
        • Position Loop Bandwidth:
          100 Hz max.
        • Feedback Resolution:
          24-bit (16,777,216 per revolution)
        • Programmable I/O:
          6 bi-directional, 24V PLC compatible
        • Communication Options:
          RS232, RS485 (up to 32 nodes)
        • Operating Temperature:
          0°C to 50°C (full ratings)
        • Storage Temperature:
          -40°C to +70°C
        • Estimated shipping dimensions:
          18.2x7.8x37cm
        • Tariff Code:
          8501510090
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Safety & Compliance Firmware & Updates Applications

        Features:

        • Signature Sinusoidal Current Control for Ultra-Smooth Motion
        • All-Digital Architecture Eliminates Analog Drift
        • Built-in Protection & Diagnostics for Maximum Uptime
        The PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 employs a proprietary commutation technique called "Signature Control." By tailoring the current waveform to match the motor's back EMF, it reduces electromagnetic ripple torque to as low as ±2%. This results in exceptional smoothness at low speeds, higher overall efficiency, and reduced mechanical wear in precision applications like grinding or semiconductor handling.

        Unlike traditional analog drives, the PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 uses a fully digital signal path (DSP, DRDC, and ASICs). This design removes the need for potentiometer adjustments, eliminates performance drift over temperature and time, and significantly improves system reliability. All tuning parameters are stored in EEPROM and can be managed via user-friendly Windows software.

        The PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 integrates extensive protection circuits, including output short circuit, over/undervoltage, motor and drive overtemperature, and in-rush current limiting. A built-in 7-segment status display provides immediate visual feedback on drive condition, making troubleshooting fast and straightforward, thereby reducing machine downtime.

        The SCE906A2-002-01-SCE906A200201 PACIFIC SCIENTIFIC High-Performance Digital AC Servo Drive may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 High-Performance Digital AC Servo Drive Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 High-Performance Digital AC Servo Drive

        General

        • Manufacturer PACIFIC SCIENTIFIC
        • Model SCE906A2-002-01-SCE906A200201
        • Condition New Original ready stock
        • Product Family SC752A-001-01,SC904-001-01,E42HLLB-LNK-NS-01
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Integrated Protection Circuits – The drive includes output short circuit protection, over/undervoltage monitoring, overtemperature protection for both motor and drive, and in-rush current limiting to prevent damage during startup.
        • Emergency Stop & Enable Input – A dedicated hardware enable input allows the safe disabling of the output stage, complying with machine safety standards for unexpected startup prevention.
        • Status Monitoring – The 7-segment display provides real-time diagnostic codes for overvoltage, undervoltage, overtemperature, and short circuit conditions, aiding rapid fault identification.
        • Environmental Compliance – Designed for industrial environments with 10% to 90% non-condensing humidity and operation up to 1500m altitude without performance derating.
        • Windows-Based Parameterization Software – The drive is configured using user-friendly Windows software, eliminating manual potentiometer adjustments and enabling precise digital tuning.
        • EEPROM Storage for Parameters – All system and application parameters can be saved to non-volatile EEPROM memory (either on the base drive or a removable option card), ensuring settings persist through power cycles.
        • Digital Auto-Tuning – The PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 includes an intelligent auto-tuning routine that automatically sets current, velocity, and position loop parameters based on the connected motor characteristics, reducing setup time significantly.
        • Optional Fieldbus Firmware – The drive supports optional communication cards (RS232, RS485, SERCOS, PacLAN) to integrate with various industrial networks. Firmware updates or configuration changes are typically performed through the serial interface using the manufacturer's software tools.
        • Packaging Machinery – Provides precise synchronized motion for cut-to-length, labeling, and wrapping machines where smooth acceleration and deceleration reduce material waste.
        • CNC & Machine Tools – Delivers high peak torque for rapid traverses and accurate positioning for milling, routing, or grinding spindles with 24-bit feedback resolution.
        • Robotics & Pick-and-Place – Enables fast, repetitive axis movements with low torque ripple (±2%), increasing throughput while maintaining positional accuracy.
        • Semiconductor & Electronics Manufacturing – Offers clean, precise control for wafer handling, die bonding, or PCB assembly equipment where vibration and electromagnetic interference must be minimized.
        Description
        The PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 utilizes a fully digital architecture built around a high-speed DSP, proprietary DRDC (Digital Resolver-to-Digital Converter), and custom ASICs. This all-digital implementation eliminates analog drift, reduces component count for higher reliability, and provides precise control over velocity, position, and torque.

        Engineered for rigorous industrial cycles, the PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 operates on a three-phase 400V AC main power supply with a dedicated 230V AC control input (due to its integrated cooling fans). It delivers a continuous output of 7.5 kVA at 50°C with forced air cooling and a peak output of 22.5 kVA, making it suitable for high-inertia or rapid acceleration applications.

        This drive features signature sinusoidal current control, reducing electromagnetic ripple torque to as low as ±2% for exceptional smoothness and efficiency. The PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 also includes digital auto-tuning and user-friendly Windows-based software for easy parameterization, eliminating the need for manual potentiometer adjustments.
        Alternative Names
        SCE906A200201 SCE9O6A2-OO2-O1 SCE906A2-002-0I SCE9O6A2OO2O1 BLF2924-12-0-S-002 PC834-107-N SC904-001-01 SC752A-001-01
        Technical notes
        When deploying the PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201, note that the "A2" designation in the model number requires a dedicated 230V AC ±10% control power supply (not a wide-range input) to power its internal fans. Additionally, the drive's continuous output power must be linearly derated by 0.5% for each meter of motor cable exceeding 10 meters.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What are the power supply requirements for the PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201?
        The drive requires two separate power sources: a three-phase 400V AC main power supply for motor power, and a dedicated single-phase 230V AC control power supply (±10%, 50/60 Hz). The
        In which industrial applications is the PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 typically used?
        This drive is ideal for applications requiring precise speed, position, or torque control under variable loads. Common use cases include packaging machinery, CNC machine tools, robotic axes, semiconductor handling equipment, and automated assembly lines. Its high peak power (22.5 kVA) makes it particularly suitable for machines with frequent start-stop cycles or high inertia loads.
        How do I know if the drive is operating correctly or has a fault?
        The PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 features a 7-segment status display on the front panel. This display provides real-time operational codes during normal running and specific fault codes (e.g., overvoltage, overtemperature) if a problem occurs. This allows maintenance personnel to quickly diagnose issues without needing external diagnostic tools.
        What communication and I/O options does the PACIFIC SCIENTIFIC SCE906A2-002-01-SCE906A200201 support?
        The drive includes standard RS232 and RS485 serial ports (supporting up to 32 nodes for multi-axis systems). It also provides 6 bi-directional programmable digital I/O channels that are 24V PLC-compatible, plus differential ±10V analog inputs for velocity or torque commands. Optional fieldbus cards (such as SERCOS or PacLAN) can be added for advanced networking.
