HCS02.1E-W0012-A-03-NNNN

/ 4.9
1001 reviews | Need a Specific Revision?
Bosch Rexroth HCS02.1E-W0012-A-03-NNNN (R911298371) is an IndraDrive C compact converter power section with 11.5 A maximum current for single-axis applications.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for HCS02.1E-W0012-A-03-NNNN
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for HCS02.1E-W0012-A-03-NNNN

  • Manufacturer:
    Rexroth
  • Part Number:
    HCS02.1E-W0012-A-03-NNNN
  • Product Family:
    Rexroth
  • Product Type:
    IndraDrive C Compact Converter Power Section
  • Stock:
    1
  • Maximum current:
    11.5 A
  • Continuous current:
    4.5 A
  • Mains supply:
    1-phase 200 to 250 VAC or 3-phase 200 to 500 VAC, 50 to 60 Hz
  • Output voltage:
    3-phase 0 VAC to mains connection voltage
  • Continuous power:
    2.1 kW without or with mains choke
  • Maximum power:
    5 kW without or with mains choke
  • Protection:
    IP20
  • Switching frequencies:
    4, 8, 12 or 16 kHz
  • Operating ambient:
    0 to +40°C nominal; derated operation to +55°C
  • Dimensions:
    6.5 × 25.15 × 29.0 cm
  • Weight:
    2.9 kg
  • Tariff Code:
    8503009090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Standalone Power Control-Section Match Axis Checkout Application
  • Match HCS02.1E-W0012-A-03-NNNN to R911298371
  • Do not use W0012 as an HMS/HMD supply unit
  • Preserve the separate control section, firmware and axis data

HCS02.1E-W0012-A-03-NNNN is a Bosch Rexroth indradrive c compact converter power section for the IndraDrive C HCS02 family.

Bosch Rexroth HCS02.1E-W0012-A-03-NNNN (R911298371) is an IndraDrive C compact converter power section with 11.5 A maximum current for single-axis applications. The exact complete order code maps to Bosch Rexroth material R911298371; the control section, firmware, encoder, communication and safety options are selected separately.

Before installation or replacement, verify the complete nameplate, compatible companion hardware, wiring or network design, saved configuration and commissioning plan.

Availability, condition, price, and shipping time for HCS02.1E-W0012-A-03-NNNN are confirmed during quotation.

Bosch Rexroth HCS02.1E-W0012-A-03-NNNN IndraDrive C Compact Converter Power Section Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use W0012 as a compact single-axis converter, not an HMS/HMD supply
  • Confirm the approved single- or three-phase mains design
  • Verify fuses, contactor, grounding and cabinet airflow
  • Record the separate control-section type and options
  • Restore firmware, motor, encoder and network data
  • Confirm safety and I/O configuration before enable
  • Test brake, feedback direction and low-speed motion
  • Verify current limits and acceleration under controlled load
  • Prove stopping and recovery from mains or network faults
  • Compact single-axis packaging machines
  • Small conveyor and positioning axes
  • Machine-tool auxiliary axes
Description
HCS02.1E-W0012-A-03-NNNN is a Bosch Rexroth indradrive c compact converter power section for the IndraDrive C HCS02 family.

Bosch Rexroth HCS02.1E-W0012-A-03-NNNN (R911298371) is an IndraDrive C compact converter power section with 11.5 A maximum current for single-axis applications. The exact complete order code maps to Bosch Rexroth material R911298371; the control section, firmware, encoder, communication and safety options are selected separately.

Before installation or replacement, confirm the complete HCS02.1E-W0012-A-03-NNNN identity, compatible hardware, wiring, saved configuration and installed-system requirements.
Alternative Names
HCS02.1E-W0012-A-03-NNNN HCS02.1E W0012 A 03 NNNN HCS021EW0012A03NNNN Bosch Rexroth HCS02.1E-W0012-A-03-NNNN Rexroth HCS02.1E-W0012-A-03-NNNN R911298371
Technical notes
HCS02.1E-W0012-A-03-NNNN is the converter power section identified by R911298371. The separate control section and firmware, mains components, DC-bus topology, motor feedback and braking design must be verified for the installed machine.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Is the control section included with HCS02.1E-W0012-A-03-NNNN?
The type identifies the power section. Match the installed control section, firmware, encoder, safety and communication configuration separately.
Can HCS02.1E-W0012-A-03-NNNN power additional HMS or HMD inverter axes?
No. The official system manual states that W0012 is not allowed as the supply unit for HMS/HMD and it has no external DC-bus connection.
Can HCS02.1E-W0012-A-03-NNNN use single-phase mains for the same duty as three-phase mains?
Do not assume equal system performance. Recheck phase loading, protection, conductor size, available continuous power, thermal duty and the approved machine design.
What must match when ordering HCS02.1E-W0012-A-03-NNNN as a spare?
Match material R911298371, the complete power-section code, separate control section, firmware, connectors, mains components, motor and encoder data.
Why can a replacement HCS02.1E-W0012-A-03-NNNN power up but remain not ready?
Check the control section, firmware, 24 V supply, mains enable, motor/encoder data, safety option, fieldbus configuration and active diagnostics.
Why can connected HMS or HMD axes reset when the motor controlled by HCS02.1E-W0012-A-03-NNNN accelerates?
The shared DC bus may be dropping below its permitted level because the simultaneous acceleration demand exceeds the available mains and DC-bus capacity. Check supply voltage, phase loading, mains protection, DC-bus connections, capacitance, configured acceleration ramps and the combined load of every connected axis.
Can regenerative energy from connected HMS or HMD axes always be absorbed through HCS02.1E-W0012-A-03-NNNN?
No. The simultaneous regenerative energy, DC-bus voltage limits and documented braking arrangement must be calculated for the complete drive group. Provide the approved braking resistor or other specified energy-management hardware when the internal arrangement cannot absorb the operating cycle.
