C98043-A7005-L1 6RY1704-0AA00

/ 4.9
1001 reviews | Need a Specific Revision?
The Siemens C98043-A7005-L1 6RY1704-0AA00 is PMU operator panel designed for the SIMOREG DC-MASTER 6RA70 series, providing real-time drive status visualization, fault diagnostics, and parameterization via a rugged industrial interface.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for C98043-A7005-L1 6RY1704-0AA00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for C98043-A7005-L1 6RY1704-0AA00

  • Manufacturer:
    Siemens
  • Part Number:
    C98043-A7005-L1 6RY1704-0AA00
  • Product Family:
    Siemens SINAMICS
  • Product Type:
    PMU Operator Panel
  • Stock:
    1
  • Communication Interface:
    X300 (9-pin SUB-D); RS232 / RS485 (USS Protocol)
  • Compatibility:
    SIMOREG DC-MASTER 6RA70 Series (CUD1 based)
  • Supply Voltage:
    Derived from Electronics Board (5V/24V logic)
  • Cable Length (RS232):
    Max 15m
  • Cable Length (RS485):
    Max 1200m (≤93.75 kBd) / 600m (187.5 kBd)
  • Protection Class:
    IP40
  • Operating Temperature:
    0°C to +55°C
  • Weight:
    0.82 kg
  • Estimated shipping dimensions:
    15x 8.5x 25cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Environmental Ratings Operating Environment Applications

Features:

  • Real-Time Process Visualization
  • Integrated Dual-Protocol Interface
  • Robust "Hot-Swap" Diagnostic Functionality
The Siemens C98043-A7005-L1 6RY1704-0AA00 provides immediate feedback on drive status via three discrete LEDs (Run/Ready/Fault) and a high-contrast numeric display. Operators can instantly view actual current (r019), armature voltage (r038), or firing angle (r018) without needing an external meter, drastically reducing troubleshooting time in the field.

Equipped with a versatile X300 port, the Siemens C98043-A7005-L1 6RY1704-0AA00 supports both RS232 for point-to-point PC diagnostics (DriveMonitor) and RS485 for multi-drop USS network connections. This flexibility allows engineers to connect to an OP1S plain-text panel located up to 200 meters away (with external 5V supply) or plug directly into a laptop for local parameterization.

During fault states (Red LED flashing), the Siemens C98043-A7005-L1 6RY1704-0AA00 allows users to shift alarms to the background to review the history using the P + UP/DOWN key combination. This feature enables operators to acknowledge temporary faults (e.g., F004 Phase Failure) without a drive reset, maintaining production uptime while alerting maintenance to underlying supply issues.

The C98043-A7005-L1 6RY1704-0AA00 Siemens PMU Operator Panel may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens C98043-A7005-L1 6RY1704-0AA00 PMU Operator Panel Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Siemens C98043-A7005-L1 6RY1704-0AA00 PMU Operator Panel Specs

General

  • Manufacturer Siemens
  • Model C98043-A7005-L1 6RY1704-0AA00
  • Condition New Original ready stock
  • Product Family C98043-A7004-L2,C98043-A7011-L6,C98043-A1601-L4
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Storage & Transport: Withstands -25°C to +70°C, protecting internal EEPROM data retention during logistics.
  • Altitude: Rated for operation up to 1000m without derating. Between 1000m and 4000m, the user must derate via P077 (cooling) due to reduced air density affecting the thermal dissipation of the Siemens C98043-A7005-L1 6RY1704-0AA00's internal logic.
  • Humidity: Tested for condensation per DIN IEC 60068-2-30 (95% RH at 40°C). However, the Siemens C98043-A7005-L1 6RY1704-0AA00 should have a condensation heater in tropical climates to prevent shorting of the RS232 pins.
  • Pollution Degree: Rated Class 3K3 (EN 60721-3-3). It is not resistant to aggressive gases (e.g., chlorine, H2S); such environments require the panel to be mounted in a pressurized purged cabinet to prevent corrosion of the ribbon cable contacts.
  • Temperature Range: The Siemens C98043-A7005-L1 6RY1704-0AA00 operates reliably in 0°C to 55°C ambient temperatures. Below freezing (0°C), the 7-segment display contrast may slow, but the unit will function once the cabinet reaches operational temperature.
  • Atmospheric Conditions: Designed for pollution degree 2 (non-conductive pollution) per EN 50178. In cement or mining applications, the unit must be housed in an IP54 cabinet to prevent conductive dust bridging the X300 connector pins.
  • Electromagnetic Immunity: Rated for industrial environments (EN 61800-3). The Siemens C98043-A7005-L1 6RY1704-0AA00 can withstand radio frequencies up to 2.4 GHz (walkie-talkies) provided the shield of the X300 cable is grounded at both ends.
  • Vibration: Suitable for shipbuilding (DNV/GL certified). The Siemens C98043-A7005-L1 6RY1704-0AA00 passes severity grade 12 (DIN IEC 60068-2-6), allowing installation on engine-room bulkheads without contact bounce issues on the membrane keys.
  • Metals & Steel Mills: Used extensively on 6RA70 drives controlling coiler/uncoiler reels and hot/cold rolling mills, where the Siemens C98043-A7005-L1 6RY1704-0AA00 provides visual confirmation of torque direction (MI/MII) and field weakening thresholds.
  • Heavy Lifting & Hoists: Essential for crane drives (4Q converters), allowing technicians to monitor overvoltage (F007) during regenerative braking of suspended loads.
  • Paper & Converting: Employed in winder drives to monitor the I²t motor monitor (F037) and speed controller deviation during tension control.
  • Test Benches & Dynamometers: Used for quick parameterization of analog inputs (terminals 4/5 for speed setpoint) without needing a PC connection.
Description
The Siemens C98043-A7005-L1 6RY1704-0AA00 PMU Panel serves as the primary human-machine interface for the SIMOREG DC-MASTER 6RA70 family of fully digital DC converters. Engineered for heavy industrial environments, this panel enables operators to perform critical start-up procedures, monitor live operational states (RUN/READY/FAULT), and execute parameter adjustments directly on the drive. Its five-digit, seven-segment LED display ensures high visibility even in low-light or high-vibration conditions.

Built to withstand demanding applications such as rolling mills, hoists, and extruders, the Siemens C98043-A7005-L1 6RY1704-0AA00 integrates seamlessly with the CUD1 electronics board. It provides a standardized USS interface (RS232/RS485) via its X300 connector, allowing for connection to external OP1S operator panels or PC-based DriveMonitor software. This eliminates the need for complex wiring during maintenance and troubleshooting.

As a critical component for legacy system support, the Siemens C98043-A7005-L1 6RY1704-0AA00 ensures high system availability for existing 6RA70 installations. While the product is officially discontinued (End-of-Life), it remains essential for replacement and repair strategies in sectors like metals, mining, and energy where drives are required to operate for decades.
Alternative Names
C98043-A7005-L1 6RY1704-0AA00 C98043-A7005-L1/6RY1704-0AA00 C98O43-A7OO5-L1 6RY17O4-OAAOO C98043-A7004-L2 C98043-A7009-L1 6RY1703-0GA01 C98043-A7011-L6 C98043-A1601-L4
Technical notes
When replacing a faulty Siemens C98043-A7005-L1 6RY1704-0AA00, power must be completely disconnected from the 6RA70 unit for at least two minutes before unplugging the ribbon cable to prevent damage from snubber capacitor discharge.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does the Siemens C98043-A7005-L1 6RY1704-0AA00 handle parameter management during a firmware upgrade of the 6RA70 drive?
The Siemens C98043-A7005-L1 6RY1704-0AA00 is a display/input unit only; it does not store parameters. When upgrading firmware (using HEXLOAD_WIN), the parameters are stored in the CUD1 board's EEPROM. After the upgrade, simply plugging the Siemens C98043-A7005-L1 6RY1704-0AA00 back into X109 will display the current operational states immediately.
Is the Siemens C98043-A7005-L1 6RY1704-0AA00 compatible with third-party PLCs via the RS485 port?
Yes. The X300 port utilizes the USS protocol (Parameter P780 = 2). While the Siemens C98043-A7005-L1 6RY1704-0AA00 primarily serves the OP1S, the bus interface allows a third-party Modbus RTU gateway to read process data (K connectors) by mimicking a USS master. However, note that the PMU itself remains the slave; you cannot use it as a master to poll other devices without the OP1S.
What are the safe installation steps for the Siemens C98043-A7005-L1 6RY1704-0AA00 in a Zone 2 hazardous area?
The Siemens C98043-A7005-L1 6RY1704-0AA00 is rated for IP40 and lacks intrinsic safety barriers. For installation in Zone 2 (ATEX/IECEx), it must be mounted inside a certified Ex e (increased safety) or Ex tb (dust) enclosure. The front membrane is not certified for Zone 1. Users must ensure that the RS232 cable leaving the enclosure passes through an Ex e certified cable gland to maintain the IP rating.
