6AV2124-0QC02-0AX0

/ 4.9
1001 reviews | Need a Specific Revision?
The 6AV2124-0QC02-0AX0 is a high-performance touchscreen human-machine interface (HMI) device in the SIMATIC HMI series TP1500 Comfort product line. It features an advanced touch interface for intuitive and convenient operation.
Get a quick price for 6AV2124-0QC02-0AX0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6AV2124-0QC02-0AX0

  • Manufacturer:
    Siemens
  • Part Number:
    6AV2124-0QC02-0AX0
  • Product Family:
    Siemens Simatic HMI
  • Type of supply voltage:
    DC
  • Rated value (DC):
    24 V
  • permissible range, lower limit (DC):
    19.2 V
  • permissible range, upper limit (DC):
    28.8 V
  • Current consumption (rated value):
    1.5 A
  • Active power input, typ.:
    36 W
  • Processor type:
    X86
  • Weight:
    5 kg
  • Estimated shipping dimensions:
    41.4x31x8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications

Features:

  • Interface Between the Operator and Industrial Automation Control System
  • Combines Capability of High-Resolution Visualization with Touch-Based Operation
  • Operates in Conjunction with SIMATIC S7 Series and Standard PROFINET/PROFIBUS Networks
The 6AV2124-0QC02-0AX0 operates as the SIMATIC HMI TP1500 Comfort touch panel in an industrial automation system, providing reliable human-machine interface functionality to all connected controllers within the network. It continuously processes incoming control signals via PROFINET and MPI/PROFIBUS DP interfaces, displaying real-time operational data on its 15-inch widescreen TFT display with 16 million colors to support steady state monitoring of all automated processes and machinery. Seamless integration is standard with the 6AV2124-0QC02-0AX0, however using an optional WinCC Comfort V11 SP2 or higher configuration will allow seamless visualization of complex process data and alarm management in the event of system anomalies. The 6AV2124-0QC02-0AX0 has made improvements in several areas over previous HMI designs in addition to incorporating universal communication capability within the SIMATIC ecosystem.

The 6AV2124-0QC02-0AX0 provides essential interface functions common to the entire control system, and is a critical component of the monitoring path, directly affecting the proper, normal operation of the overall automation system. One 6AV2124-0QC02-0AX0 panel is typically required per operator station depending on the desired visualization scope. The 6AV2124-0QC02-0AX0 occupies a compact installation footprint in the control cabinet and is always positioned for optimal operator accessibility (front panel mounting, the dedicated HMI location).

For expanded system applications, the SIMATIC HMI system may utilize the successor model 6AV2124-0QC02-0AX1 for enhanced configuration options. In addition to standard single panel operation, the successor configuration also performs advanced visualization capabilities. The 6AV2124-0QC02-0AX1 successor system executes configuration using WinCC V14 SP1 as specified in the software compatibility options. Using this method, the upgraded HMI system continually provides improved performance and extended support. If the system requires migration from the primary 6AV2124-0QC02-0AX0, it will automatically adapt to the successor model 6AV2124-0QC02-0AX1 and ensure continuity in the System Event List.

The 6AV2124-0QC02-0AX0 SIEMENS SIMATIC HMI TP1500 Comfort touch panel may still be available for purchase and support from authorized distributors beyond the introduction of its successor model 6AV2124-0QC02-0AX1 by the manufacturer (OEM).

6AV2124-0QC02-0AX0 SIEMENS SIMATIC HMI TP1500 Comfort touch panel Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
SIEMENS 6AV2124-0QC02-0AX0 SIMATIC HMI TP1500 COMFORT

General

  • Manufacturer SIEMENS
  • Model 6AV2124-0QC02-0AX0
  • Condition New Original ready stock
  • Product Family 6AV2124-0QC02-0AX1,6AV2124-6QJ00-0AX1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Description
The 6AV2124-0QC02-0AX0 is a high-performance touch screen Human Machine Interface (HMI) device from Siemens' SIMATIC HMI series, belonging to the TP1500 Comfort product line. This model features a 15-inch widescreen TFT display with support for 16 million colors, delivering clear and refined visual experience to users. As a Comfort Panel, the 6AV2124-0QC02-0AX0 is specifically designed for industrial automation environments, equipped with an advanced touch operation interface that ensures intuitive and convenient operation.

In terms of communication interfaces, the 6AV2124-0QC02-0AX0 integrates both a PROFINET interface and an MPI/PROFIBUS DP interface, ensuring seamless connectivity and data exchange with Siemens PLCs and other industrial equipment. This model comes with 24 MB configuration memory, providing ample storage space for complex HMI projects. The operating system utilizes Windows CE 6.0, guaranteeing system stability and reliability.

The 6AV2124-0QC02-0AX0 supports configuration using WinCC Comfort V11 SP2 and higher versions, allowing users to flexibly customize according to specific application requirements. It is important to note that the 6AV2124-0QC02-0AX0 has a successor model, the 6AV2124-0QC02-0AX1. The new version 6AV2124-0QC02-0AX1 can be configured starting from WinCC V14 SP1. For new projects, it is recommended to prioritize the successor model 6AV2124-0QC02-0AX1 to ensure longer-term technical support.

Alternative Names
6AV2124-0UC02-0AX0 6AV2124-0XC02-0AX0 6AV2124 0QC02 0AX0 6AV2124-0QC02-OAXO
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What type of operation does the 6AV2124-0QC02-0AX0 support?
The 6AV2124-0QC02-0AX0 supports touch operation for intuitive user interaction.
What are the display specifications of the 6AV2124-0QC02-0AX0?
The 6AV2124-0QC02-0AX0 features a 15-inch widescreen TFT display with 16 million colors for high-quality visualization.
What communication interfaces are available on the 6AV2124-0QC02-0AX0?
The 6AV2124-0QC02-0AX0 is equipped with a PROFINET interface and an MPI/PROFIBUS DP interface for versatile industrial connectivity.
How much configuration memory does the 6AV2124-0QC02-0AX0 have?
The 6AV2124-0QC02-0AX0 comes with 24 MB configuration memory for storing HMI projects.
What operating system does the 6AV2124-0QC02-0AX0 use?
The 6AV2124-0QC02-0AX0 runs on Windows CE 6.0 operating system.
