6AV6647-0AH11-3AX0

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6AV6647-0AH11-3AX0 is a SIMATIC HMI KP300 Basic mono PN key-operated panel with a 3.6-inch FSTN display and PROFINET interface.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6AV6647-0AH11-3AX0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6AV6647-0AH11-3AX0

  • Manufacturer:
    Siemens
  • Part Number:
    6AV6647-0AH11-3AX0
  • Product Family:
    Siemens Simatic HMI
  • Product Type:
    KP300 Basic Mono PN Key-Operated HMI
  • Stock:
    1
  • Product line:
    SIMATIC HMI Basic Panel
  • Commercial name:
    KP300 Basic mono PN
  • Display:
    3.6-inch FSTN, 240 x 80 pixels
  • Backlight:
    Four colors
  • Operation:
    Keyboard; 10 function keys; no touch screen
  • Communication:
    PROFINET
  • Rated supply:
    24 V DC
  • Permitted supply range:
    19.2–28.8 V DC
  • Typical input current:
    0.1 A
  • Power consumption:
    3 W
  • Weight:
    0.375 kg
  • Estimated shipping dimensions:
    13.9x19.5x5cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    China
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Panel Fit PROFINET Setup Key Operation Product Applications

Features:

  • Key-operated panel: ten function keys and no touch layer
  • Compact display: 3.6-inch 240 x 80 FSTN screen
  • Industrial networking: PROFINET communication on a 24 VDC panel
KP300 Basic mono PN provides a compact operator interface where physical keys are preferred.

Its four-color backlight can support machine-state cues within the configured HMI project.

A replacement plan must preserve both the mechanical panel fit and the original automation project.

Apter Power can review the Siemens 6AV6647-0AH11-3AX0 KP300 Basic Mono PN Key-Operated HMI identity, condition, project requirements, and shipment evidence.
Siemens 6AV6647-0AH11-3AX0 KP300 Basic Mono PN Key-Operated HMI Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Mechanical check: compare the installed cutout, mounting hardware, and enclosure clearances.
  • Protection boundary: front and rear protection depend on correct mounting in a suitable enclosure.
  • Network record: preserve device name, IP settings, and controller relationship before removal.
  • Project compatibility: verify the engineering-software and target-panel settings before download.
  • Input method: the panel uses physical keys rather than a touch screen.
  • Operator validation: test every configured function key and backlight state before production release.
  • Compact machine HMI: provide key-operated visualization over PROFINET.
  • Legacy panel replacement: restore an exact KP300 Basic mono PN after project and cutout verification.
Description
Siemens 6AV6647-0AH11-3AX0 combines a 240 x 80 monochrome FSTN display, four selectable backlight colors, and ten function keys in a compact keyboard-operated HMI.

The 6AV6647-0AH11-3AX0 panel communicates over PROFINET and runs from 24 VDC within the published 19.2–28.8 V range. Panel cutout, enclosure protection, wiring, and project compatibility should be verified before exchange.

Siemens lists 6AV6647-0AH11-3AX1 as the successor to 6AV6647-0AH11-3AX0, but that record alone does not prove a drop-in exchange. Project conversion, mechanical fit, and interface behavior require separate review.
Alternative Names
6AV66470AH113AX0 6AV6647 0AH11 3AX0 KP300 Basic mono PN
Technical notes
For 6AV6647-0AH11-3AX0, preserve the original HMI project and verify the panel cutout, 24 VDC supply, PROFINET settings, and ten-key operating concept before removal. Siemens identifies 6AV6647-0AH11-3AX1 as a successor, but do not treat it as a drop-in replacement until mechanical, software, and interface differences are resolved.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
The machine requires a touch interface. Can 6AV6647-0AH11-3AX0 satisfy that specification?
No. KP300 Basic mono PN is key-operated and has no touch screen. Select an approved touch-panel design instead of changing the operator requirement in the field.
The 6AV6647-0AH11-3AX0 screen lights after replacement but the machine cannot be controlled. What should be checked before another panel is tried?
Stop and verify the restored project, function-key assignments, PROFINET name and address, controller relationship, power quality, and diagnostics. A lit display alone does not prove the correct project or communication.
Is 6AV6647-0AH11-3AX1 an automatic drop-in replacement for 6AV6647-0AH11-3AX0?
No. Siemens identifies it as a successor, but mechanical fit, engineering-software support, project conversion, networking, and operator behavior still require verification.
