        Siemens 6ES5441-4UA14
        Siemens 6ES5441-4UA14
        Siemens 6ES5441-4UA14
        Siemens 6ES5441-4UA14
        Siemens 6ES5441-4UA14
        Siemens 6ES5441-4UA14
        Ask our team:
        • Phone: +86 181 0690 9650
        • E-Mail sales1@apterpower.com

        • Lifecycle status

          Discontinued / Obsolete by OEM
          Apter Power provides quotations, technical documentation, procurement support and system guidance.

        6ES5441-4UA14

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Siemens 6ES5441-4UA14 identifies the UA14 variant of the 441-4 SIMATIC S5 output family, with thirty-two floating 24 V DC channels. It addresses dense command wiring in established racks.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for 6ES5441-4UA14
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 6ES5441-4UA14

        • Manufacturer:
          Siemens
        • Part Number:
          6ES5441-4UA14
        • Product Family:
          Siemens Simatic S5
        • Product Type:
          SIMATIC S5 441-4 digital output module
        • Stock:
          1
        • Rated supply voltage:
          24 V DC (L+)
        • Number of outputs:
          32
        • Isolation:
          No
        • Supply range:
          20 to 30 V DC
        • Fuse rating:
          6.3 A slow / 7 A fast, one fuse per 8 outputs
        • Logic 1 output level:
          L+ - 1.5 V min.
        • Logic 0 output level:
          3 V max.
        • Switching current:
          5 mA to 0.5 A
        • Residual current at logic 0:
          0.5 mA max.
        • Lamp current:
          0.22 A max. (5 W)
        • Switching frequency, resistive:
          100 Hz max.
        • Switching frequency, inductive at 0.3 A:
          2 Hz max.
        • Switching frequency, inductive at 0.5 A:
          0.5 Hz max.
        • Breaking voltage:
          L+ - 55 V
        • Total switching current:
          4 A max. per 8 outputs
        • Digital section supply:
          5 V, 80 mA typical
        • 24 V current consumption:
          200 mA typical
        • Power dissipation:
          6.4 W
        • Enable input current:
          5 mA
        • Enable line length:
          200 m max.
        • Weight:
          0.99 lbs (0.45 kg)
        • Estimated shipping dimensions:
          20 mm x 255 mm x 195 mm
        • Tariff Code:
          85389091
        • Country of origin:
          Germany
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Applications Monitoring Temperature & Humidity Range Firmware & Updates

        Features:

        • Thirty-two floating 24 V DC outputs support high-density command wiring.
        • The UA14 version uses a fast-fuse arrangement for its protected output groups.
        • The compact 441-4 card is intended for existing SIMATIC S5 installations.
        Apter Power verifies sourcing against the UA14 order code and the 441-4 configuration.

        It provides distributed valve, relay, and indicator commands from one established S5 rack location.

        Verify the UA14 connector keying, point order, and DC field reference against the original cabinet drawings.

        Order review covers the UA14 variant and Apter Power's current sourcing channels.
        Product resources for Siemens 6ES5441-4UA14:
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Coordinates banks of DC solenoids, contactors, and status lamps.
        • Supports sequence output groups that require thirty-two points at one rack position.
        • Keeps the installed 441-4 topology available for legacy cabinet service.
        • Front LEDs identify a short circuit affecting one of the eight-output monitoring groups.
        • The common H+ signal provides a cabinet-level indication when the module detects the specified fault condition.
        • The output reference remains suitable for monitoring logic states on the installed S5 field interface.
        • The card is intended for the S5 operating climate rather than uncontrolled outdoor placement.
        • Keep relative humidity below the manual limit and prevent condensation during warm-up or shutdown.
        • Storage and transport require the separate low-temperature range stated for SIMATIC S5 modules.
        • This is a hardware I/O card; its behavior is selected by the module order code and wiring.
        • No user firmware package is required to expose the thirty-two output points to the S5 process image.
        • Any control-logic change must be validated in the existing STEP 5 project after the card is exchanged.
        Description
        Siemens 6ES5441-4UA14 identifies the UA14 version of the 441-4 32-output, 24 V DC SIMATIC S5 interface. Its fast-fuse arrangement and compact width support dense cabinet layouts.

        The module centralizes command points for solenoids, contactors, status lamps, and machine interlocks without changing the controller family or field-side voltage. It is a practical spare for a matching 441-4 position. The UA14 configuration uses fast 7 A protection for its output groups, supporting rapid fault clearing in dense panels.

        Check UA14 connector keying, point order, fuse grouping, supply polarity, and load protection against the cabinet drawings. Allow for the 20 mm × 255 mm × 195 mm mechanical envelope during exchange. Its 6.4 W rated dissipation is useful when checking cabinet heat balance around a tightly packed S5 rack.
        Alternative Names
        6ES5441-4UA14 6ES54414UA14 SIMATIC S5 441-4 Siemens 441-4 digital module S5 441-4 I/O module 441-4 compact module Siemens 6ES5441-4UA14
        Technical notes
        When fitting Siemens 6ES5441-4UA14, compare the UA14 connector assignment and 441-4 slot address with the cabinet drawing before enabling the DC field supply.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Where are the command points of Siemens 6ES5441-4UA14 used?
        The module provides 32 floating dc outputs for 24 v dc, 0.5 a per output.
        Which cabinet wiring should remain unchanged for Siemens 6ES5441-4UA14?
        It is matched to 441-4 ua14 variant and the established SIMATIC S5 backplane.
        What actuator bank can Siemens 6ES5441-4UA14 control?
        Coordinates banks of DC solenoids, contactors, and status lamps.
        Where can buyers obtain Siemens 6ES5441-4UA14 documentation?
        Siemens treats the legacy order as discontinued; Apter Power can support documentation and sourcing checks.
        What must be compared before exchanging Siemens 6ES5441-4UA14?
        Compare slot, connector, signal class, address map, and load protection before any exchange.
        How can a buyer request Siemens 6ES5441-4UA14 pricing?
        Send the full order code, quantity, destination, label details, and manual requirement for a matched response.
