6ES7516-3AN00-0AB0

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6ES7516-3AN00-0AB0 is a SIMATIC S7-1500 CPU 1516-3 PN/DP central processing unit that executes automation logic across two PROFINET interfaces and one PROFIBUS DP master interface.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7516-3AN00-0AB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7516-3AN00-0AB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7516-3AN00-0AB0
  • Product Family:
    Siemens Simatic S7-1500
  • Product Type:
    SIMATIC S7-1500 CPU 1516-3 PN/DP Central Processing Unit
  • Stock:
    1
  • Supply Voltage:
    24 V DC
  • Permissible Supply Range:
    19.2-28.8 V DC
  • Rated Current Consumption:
    0.85 A
  • Typical Power Loss:
    7 W
  • Program Work Memory:
    1 MB
  • Data Work Memory:
    5 MB
  • Load Memory:
    Plug-in SIMATIC Memory Card, up to 2 GB
  • Typical Bit Operation Time:
    10 ns
  • PROFINET Interfaces:
    2
  • First PROFINET Interface:
    Two RJ45 ports with integrated switch; IO controller and IO device
  • Second Ethernet Interface:
    One RJ45 port for SIMATIC, open IE, and web-server communication
  • PROFIBUS Interface:
    One RS-485 port, up to 12 Mbit/s
  • PROFIBUS Role:
    DP master
  • Integrated Connections:
    128 via integrated interfaces
  • Process Image:
    32 KB inputs and 32 KB outputs
  • Engineering Version:
    STEP 7 TIA Portal V12.0 or later
  • Horizontal Operating Temperature:
    0 to 60 °C
  • Vertical Operating Temperature:
    0 to 40 °C
  • Weight:
    2.072 lbs (0.94 kg)
  • Estimated shipping dimensions:
    15.8x15.9x8.4cm
  • Tariff Code:
    85371091
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Memory Workflow PROFINET Roles PROFIBUS Channel Protection and Access

Features:

  • Separate program and data work-memory areas keep executable code apart from live controller data.
  • The first PROFINET path provides a two-port IRT switch, while the second Ethernet path has a separate communication role.
  • A dedicated RS-485 channel supplies PROFIBUS DP master communication up to 12 Mbit/s.
The 6ES7516-3AN00-0AB0 performs the CPU 1516-3 PN/DP control role within a SIMATIC S7-1500 station.

A required SIMATIC Memory Card holds the load-memory content used with the integrated program and data work memory.

Local display, mode-selection, access-protection, and network-status functions support controller commissioning and operation.

The Siemens 6ES7516-3AN00-0AB0 SIMATIC S7-1500 CPU 1516-3 PN/DP Central Processing Unit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6ES7516-3AN00-0AB0 SIMATIC S7-1500 CPU 1516-3 PN/DP Central Processing Unit Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Program, Data, and Load Storage

  • Program area: Executable control code occupies the dedicated 1 MB work-memory partition.
  • Data area: The separate 5 MB partition holds the working data used during execution.
  • Load path: Project content is supplied through the required plug-in SIMATIC Memory Card.
  • Runtime relation: The CPU transfers the required project content from removable load storage into its execution areas.

Separated Ethernet Functions

  • First interface: Two switched RJ45 ports provide the PROFINET IRT connection.
  • IO operation: This first path can operate as both PROFINET IO controller and IO device.
  • Second interface: A single RJ45 port carries SIMATIC and open IE communication independently.
  • Service access: Web-server communication is available on both documented Ethernet paths.

DP Master Communication Path

  • Physical layer: The third communication interface uses an isolated RS-485 connection.
  • Controller role: The channel is assigned to PROFIBUS DP master operation rather than DP-slave operation.
  • Bus rate: The documented transmission ceiling is 12 Mbit/s.
  • System relation: PROFIBUS devices remain on a dedicated fieldbus path instead of sharing the two Ethernet interfaces.

Project and Controller Access Controls

  • User program: Password protection controls access to the loaded automation project.
  • Program assets: Copy protection and block protection are supported for configured content.
  • CPU access: Write, read/write, and complete protection levels can be selected.
  • Local interface: The front display can be protected with its own password.
Description
Siemens 6ES7516-3AN00-0AB0 is the CPU 1516-3 PN/DP central processing unit in the SIMATIC S7-1500 system. It executes the user program, maintains controller data, and coordinates PROFINET and PROFIBUS communication from the central controller position.

Program execution in 6ES7516-3AN00-0AB0 uses separate integrated work-memory areas: 1 MB for program code and 5 MB for data. Typical bit operations take 10 ns, while a plug-in SIMATIC Memory Card provides the required load-memory path for the project.

Three communication paths give 6ES7516-3AN00-0AB0 distinct network roles. The first PROFINET IRT interface contains a two-port switch and supports both IO-controller and IO-device operation; the second Ethernet interface carries SIMATIC, open IE, and web-server communication without PROFINET IO roles; the RS-485 interface operates as a PROFIBUS DP master up to 12 Mbit/s.

At the controller hardware boundary, 6ES7516-3AN00-0AB0 accepts 24 V DC within 19.2 to 28.8 V DC and provides local display, mode-selection, and link-status functions. Horizontal installation permits operation from 0 to 60 °C, with the display switching off at about 50 °C while the CPU remains within its documented operating range.
Alternative Names
6ES75163AN000AB0 6ES7516 3AN00 0AB0 Siemens 6ES7516-3AN00-0AB0 Siemens CPU 1516-3 PN/DP 6ES7516-3AN00-0AB0 CPU1516-3PN/DP 6ES75163AN000AB0 6ES7516-3AN00-OABO 6ES7516 3AN00 OAB0 SIMATIC S7-1500 CPU 1516-3 PN/DP
Technical notes
Siemens 6ES7516-3AN00-0AB0 combines CPU 1516-3 execution with separated PROFINET IRT, Ethernet, and PROFIBUS communication paths. A SIMATIC Memory Card is required for its load-memory function.
