6ES7222-1HF22-0XA0

/ 4.9
1001 reviews | Need a Specific Revision?
Eight contact-switched control points are added to an S7-22X station by Siemens 6ES7222-1HF22-0XA0, the 2 A EM 222 relay-output module.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 6ES7222-1HF22-0XA0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7222-1HF22-0XA0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7222-1HF22-0XA0
  • Product Family:
    Siemens Simatic S7-200
  • Product Type:
    SIMATIC S7-200 EM 222 Digital Output Module
  • Stock:
    1
  • Module designation:
    EM 222
  • Compatible CPU family:
    S7-22X
  • Output type:
    Relay contacts
  • Digital outputs:
    8
  • Maximum current per output:
    2 A
  • Lifecycle:
    Product cancelled
  • Cancellation date:
    1 October 2017
  • Weight:
    0.143 kg
  • Estimated shipping dimensions:
    7.1 x 10.1 x 6.1 cm
  • Tariff Code:
    85389091
  • Country of origin:
    China
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Relay Output Design S7-200 Integration Legacy Service Product Applications

Features:

  • Eight relay outputs: the EM 222 adds contact-switched digital control points.
  • 2 A channel rating: each output operates within the module’s published load limits.
  • S7-22X assignment: the expansion module is tied to the installed S7-200 CPU family.
This module expands an S7-200 controller where relay contacts are required for the field-load interface.

AC or DC switching flexibility comes from the contact output, while protection and relay-life calculations remain load dependent.

Its cancelled lifecycle makes exact MLFB control and preserved wiring records especially important during legacy maintenance.
Apter Power can review 6ES7222-1HF22-0XA0 MLFB identity, condition, documentation, and legacy S7-200 sourcing requirements.
Siemens 6ES7222-1HF22-0XA0 SIMATIC S7-200 EM 222 Digital Output Module Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Channel count: eight digital outputs are provided.
  • Contact interface: relay switching separates the control command from the field load.
  • Current rating: the published maximum is 2 A per output within applicable limits.
  • Load planning: voltage, inrush, switching rate, and relay life must be evaluated together.
  • CPU scope: the EM 222 is intended only for S7-22X CPUs.
  • Expansion role: it adds output points rather than executing the user program.
  • Terminal continuity: retain the original channel and common mapping during replacement.
  • Program alignment: the hardware configuration and field labels must remain synchronized.
  • Lifecycle: Siemens lists the product as cancelled from 1 October 2017.
  • Spare control: use the complete MLFB rather than EM 222 wording alone.
  • Isolation: remove logic and field power before accessing relay wiring.
  • Restart: test each commanded output with the real load under controlled conditions.
  • Legacy machine control: maintain relay-switched actuators on installed S7-200 equipment.
  • Mixed-voltage outputs: use isolated contacts where the documented load circuit requires them.
  • Maintenance stock: support S7-22X systems that cannot yet be migrated to a current controller family.
Description
For relay-switched field loads on a SIMATIC S7-200 station, 6ES7222-1HF22-0XA0 adds eight digital output channels. The EM 222 is designed for S7-22X CPUs, and its relay contacts can switch AC or DC field circuits within the published contact limits.

Each output of 6ES7222-1HF22-0XA0 is rated up to 2 A within the published relay and grouping limits. That contact-based architecture can switch AC or DC loads, but load voltage, inrush current, duty cycle, and relay life remain part of the cabinet design rather than interchangeable channel details.

Because 6ES7222-1HF22-0XA0 has been cancelled by Siemens, its value is in maintaining installed S7-200 systems with an exact MLFB match. A replacement plan should preserve CPU family, terminal assignment, supply grouping, output-load characteristics, and the saved program documentation.
Alternative Names
6ES72221HF220XA0 Siemens EM 222 8 relay outputs SIMATIC S7-200 relay output module
Technical notes
6ES7222-1HF22-0XA0 is an eight-channel relay-output EM 222 for S7-22X CPUs, not a 24 V DC transistor module. Relay contacts have load, inrush, switching-frequency, and life limits; de-energize both logic and field circuits before wiring, and preserve the original terminal map when servicing a cancelled S7-200 station.
