PM566-TP-ETH

/ 4.9
1001 reviews | Need a Specific Revision?
ABB PM566-TP-ETH 1SAP121500R0071 is an AC500-eCo programmable logic controller with Ethernet, integrated digital and analog I/O, and 24 V DC supply.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for PM566-TP-ETH
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PM566-TP-ETH

  • Manufacturer:
    ABB
  • Part Number:
    PM566-TP-ETH
  • Product Family:
    ABB AC500
  • Product Type:
    AC500-eCo Programmable Logic Controller
  • Stock:
    1
  • ABB Order Code:
    1SAP121500R0071
  • Integrated I/O:
    6 DI; 6 DO transistor; 2 AI; 1 AO
  • Communication:
    Ethernet; 1 RS485
  • Supply:
    24 V DC
  • Option Slots:
    2
  • Weight:
    0.282 kg
  • Tariff Code:
    85371091
  • Country of origin:
    China / Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications I/O Planning Communication Review Ordering Check

Features:

  • Integrated I/O: ABB lists 6 DI, 6 transistor DO, 2 AI, and 1 AO.
  • Communications: The controller includes Ethernet and one RS485 interface.
  • Supply and options: The documented controller uses 24 V DC and provides two option slots.
The ABB PM566-TP-ETH is an AC500-eCo programmable logic controller identified by order code 1SAP121500R0071. ABB lists Ethernet, 24 V DC supply, and integrated digital and analog I/O.

The ABB PM566-TP-ETH provides six digital inputs, six transistor digital outputs, two analog inputs, one analog output, one RS485 interface, and two option slots. ABB current product data lists a 0.282 kg net weight.

Before ordering ABB PM566-TP-ETH, verify the complete R0071 code, firmware and project requirements, I/O signal plan, power supply, Ethernet configuration, serial communication, and required terminal blocks.

The ABB PM566-TP-ETH 1SAP121500R0071 controller is available for quotation and configuration support from Apter Power, subject to current inventory and sourcing confirmation.
ABB PM566-TP-ETH 1SAP121500R0071 Manuals and Resources Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB PM566-TP-ETH 1SAP121500R0071 AC500-eCo Programmable Logic Controller Specs

General

  • ManufacturerABB
  • ModelPM566-TP-ETH 1SAP121500R0071
  • ConditionNew Original ready stock
  • Product FamilyABB AC500-eCo
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Digital inputs: Map all six documented input channels.
  • Digital outputs: Confirm transistor-output load requirements.
  • Analog inputs: Preserve signal type and scaling for both channels.
  • Analog output: Record the connected output loop.
  • Ethernet: Document addressing, switch port, and cable label.
  • RS485: Record protocol, baud rate, and termination.
  • Option slots: Identify installed option hardware.
  • Project: Back up communication configuration before replacement.
  • Order code: Match 1SAP121500R0071 in full.
  • Power: Confirm the 24 V DC supply.
  • Terminal blocks: List required detachable terminals separately.
  • Acceptance: Verify I/O, communication, and application startup.
Description
ABB PM566-TP-ETH 1SAP121500R0071 is an AC500-eCo CPU module that combines controller execution, mixed local signal handling, onboard communication, and option-module support in the R0071 configuration.

ABB PM566-TP-ETH 1SAP121500R0071 processes the assigned digital and analog signals while exchanging controller data through the configured Ethernet and RS-485 connections within the approved AC500-eCo project.

Before ordering ABB PM566-TP-ETH 1SAP121500R0071, confirm the firmware and project requirements, I/O signal plan, output-load and analog-range requirements, 24 V DC supply, Ethernet and serial settings, option modules, terminal blocks, and complete order code.
Alternative Names
ABB PM566-TP-ETH PM566-TP-ETH PM566 TP ETH PM566TPETH 1SAP121500R0071 1SAP121500 R0071 ABB AC500-eCo PM566 AC500 PM566 Ethernet PLC
Technical notes
ABB PM566-TP-ETH 1SAP121500R0071 is a ac500-eco programmable logic controller documented for ABB AC500-eCo. Verify the complete model, part number, installed system, and connector layout before ordering.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How should PM566-TP-ETH 1SAP121500R0071 be selected for an AC500-eCo project?
Match the order code, 24 V DC supply, required six digital inputs, six transistor outputs, two analog inputs, one analog output, Ethernet, RS485, option hardware, and project requirements.
Can PM566-TP-ETH 1SAP121500R0071 remain system-compatible after migration to ABB-listed successor controllers without project changes?
ABB lists PM5052-T-ETH and PM5072-T-2ETH as migration devices, but terminal blocks, I/O mapping, memory, firmware, network settings, libraries, and the application must be reviewed before migration.
What should be saved before replacing PM566-TP-ETH 1SAP121500R0071?
Back up the project, IP settings, RS485 parameters, I/O configuration, retained data, firmware record, option-board details, and terminal wiring schedule.
What should be checked if PM566-TP-ETH 1SAP121500R0071 will not enter normal operation?
Check the 24 V DC supply, terminal connections, run or stop state, project download, fault indications, I/O configuration, and option-board seating.
What commonly causes PM566-TP-ETH 1SAP121500R0071 communication problems during commissioning?
Check duplicate IP addresses, subnet settings, Ethernet cabling, RS485 protocol, baud rate, node address, polarity, shielding, and termination.
How should PM566-TP-ETH 1SAP121500R0071 I/O be tested safely?
Keep machinery in a safe state, test channels in a controlled sequence, verify analog scaling and transistor-output loads, and record the acceptance results.
Which installation conditions matter for PM566-TP-ETH 1SAP121500R0071?
Confirm cabinet temperature, ventilation, grounding, shielding, supply quality, vibration, humidity, and clearance against ABB installation guidance.
What should an RFQ for PM566-TP-ETH 1SAP121500R0071 include?
Provide quantity, condition, destination, required date, order-code photographs, project version, network requirements, option boards, and required terminal accessories.
